Micro electro-mechanical systems (MEMS) combining sensing and microfluidics functionalities, as are common in Lab-on-Chip (LoC) devices, are increasingly based on polymers. Benefits of polymers include tunable material properties, the possibility of surface functionalization, compatibility with many micro and nano patterning techniques, and optical transparency. Often, additional materials, such as metals, ceramics, or silicon, are needed for functional or auxiliary purposes, e.g., as electrodes. Hybrid patterning and integration of material composites require an increasing range of fabrication approaches, which must often be newly developed or at least adapted and optimized. Here, a microfabrication process concept is developed that allows one to implement attenuated total reflection Fourier transform infrared spectroscopy (ATR-FTIR) and electrochemistry on an LoC device. It is designed to spatially resolve chemical sensitivity and selectivity, which are instrumental for the detection of chemical distributions, e.g., during on-flow chemical and biological reaction chemistry. The processing sequence involves (i) direct-write and soft-contact UV lithography in SUEX dry resist and replication in polydimethylsiloxane (PDMS) elastomers as the fluidic structure; (ii) surface functionalization of PDMS with oxygen plasma, 3-aminopropyl-triethoxysilane (APTES), and a UV-curable glue (NOA 73) for bonding the fluidic structure to the substrate; (iii) double-sided patterning of silicon nitride-coated silicon wafers serving as the ATR-FTIR-active internal reflection element (IRE) on one side and the electrode-covered substrate for microfluidics on the back side with lift-off and sputter-based patterning of gold electrodes; and (iv) a custom-designed active vacuum positioning and alignment setup. Fluidic channels of 100 μm height and 600 μm width in 5 mm thick PDMS were fabricated on 2” and 4” demonstrators. Electrochemistry on-chip functionality was demonstrated by cyclic voltammetry (CV) of redox reactions involving iron cyanides in different oxidation states. Further, ATR-FTIR measurements of laminar co-flows of H₂O and D₂O demonstrated the chemical mapping capabilities of the modular fabrication concept of the LoC devices. Full article

Hybrid membranes with three different thicknesses, PMDS_C1, PMDS_C2, and PMDS_C3 (0.21 ± 0.03 mm, 0.31 ± 0.05 mm, and 0.48 ± 0.07 mm), were synthesized by the sol–gel method using polydimethylsiloxane, hydroxy-terminated, and cyanopropyltriethoxysilane. The presence of cyano, methyl, and silicon-methyl groups was confirmed by FTIR analysis. Contact angle analysis revealed the membranes’ hydrophilic nature. Solvent resistance tests conducted under vortex and ultrasonic treatments (45 and 60 min) demonstrated a preference order of acetonitrile > methanol > water. Furthermore, the membranes exhibited stability over 48 h when exposed to different pH conditions (1, 3, 6, and 9), with negligible mass losses below 1%. The thermogravimetric analysis showed that the material was stable until 400 °C. Finally, the sorption analysis showed its capacity to detect furfural, 2-furylmethylketone, 5-methylfurfural, and 2-methyl 2-furoate. The thicker membrane was able to adsorb and slightly desorb a higher concentration of furanic compounds due to its high polarity provided by the addition of the cyano groups. The results indicated that the membranes may be suitable for sorbent materials in extracting and enriching organic compounds. Full article

The micro-oxygenation (MOX) of aged wine in contact with pieces of wood is a technique widely used for aging wines as an alternative to barrels. The available range of passive MOX systems is very wide and offers a behavior closer to that of barrels because it uses materials with a similar permeability to oxygen. The aim of this work has been to age the same red wine for 6 months using the main passive MOX systems and compare them with the classic MOX in stainless steel tanks and with barrels as a reference, in order to evaluate phenolic composition and establish its influence. The quantity and the way in which oxygen is incorporated into wine have been found to determine its evolution and final properties. Wine from barrels could be distinguished throughout the aging period since a better level of individualized anthocyanins was maintained, whereas stainless steel + MOX and PMDS (polydimethylsiloxane) wines presented more bluish hues. Full article

The publication presents a comparative study of two fibre-optic sensors in the application of heart rate (HR) and respiratory rate (RR) monitoring of the human body. After consultation with clinical practitioners, two types of non-invasive measuring and analysis systems based on fibre Bragg grating (FBG) and fibre-optic interferometer (FOI) have been designed and assembled. These systems use probes (both patent pending) that have been encapsulated in the bio-compatible polydimethylsiloxane (PMDS). The main advantage of PDMS is that it is electrically non-conductive and, as well as optical fibres, has low permeability. The initial verification measurement of the system designed was performed on four subjects in a harsh magnetic resonance (MR) environment under the supervision of a senior radiology assistant. A follow-up comparative study was conducted, upon a consent of twenty volunteers, in a laboratory environment with a minimum motion load and discussed with a head doctor of the Radiodiagnostic Institute. The goal of the laboratory study was to perform measurements that would simulate as closely as possible the environment of harsh MR or the environment of long-term health care facilities, hospitals and clinics. Conventional HR and RR measurement systems based on ECG measurements and changes in the thoracic circumference were used as references. The data acquired was compared by the objective Bland–Altman (B–A) method and discussed with practitioners. The results obtained confirmed the functionality of the designed probes, both in the case of RR and HR measurements (for both types of B–A, more than 95% of the values lie within the ±1.96 SD range), while demonstrating higher accuracy of the interferometric probe (in case of the RR determination, 95.66% for the FOI probe and 95.53% for the FBG probe, in case of the HR determination, 96.22% for the FOI probe and 95.23% for the FBG probe). Full article

Several efforts have been made on the development of bioscaffolds including the polydimethylsiloxane (PDMS) elastomer for supporting cell growth into stable sheets. However, PDMS has several disadvantages, such as intrinsic surface hydrophobicity and mechanical strength. Herein, we generated a novel PDMS-based biomimetic membrane by sequential modifications of the PMDS elastomer with graphene oxide (GO) and addition of a hexagonal micropillar structure at the bottom of the biomembrane. GO was initially homogenously mixed with pure PDMS and then was further coated onto the upper surface of the resultant PDMS. The elastic modulus and hydrophilicity were significantly improved by such modifications. In addition, the development of hexagonal micropillars with smaller diameters largely improved the ion permeability and increased the motion resistance. We further cultured retinal pigment epithelial (RPE) cells on the surface of this modified PDMS biomembrane and assayed its biocompatibility. Remarkably, the GO incorporation and coating exhibited beneficial effect on the cell growth and the new formation of tight junctions in RPE cells. Taken together, this GO-modified PDMS scaffold with polyhexagonal micropillars may be utilized as an ideal cell sheet and adaptor for cell cultivation and can be used in vivo for the transplantation of cells such as RPE cells. Full article
