Search Results (4)

Search Parameters:
Keywords = planar antenna array (PAA)

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
12 pages, 8419 KB
Article
Designing a Novel THz Band 2-D Wide-Angle Scanning Phased-Array Antenna Based on a Decoupling Surface
by Bao Xiong, Wenxuan Xie and Yongzhong Zhu
Appl. Sci. 2024, 14(19), 8618; https://doi.org/10.3390/app14198618 - 24 Sep 2024
Cited by 1 | Viewed by 1765
Abstract
This paper proposes a novel THz band 2-D wide-angle scanning phased-array antenna (PAA) based on a decoupling surface. The simulated S11 bandwidth under periodic boundary conditions is 106–119 GHz, with stable gain within the bandwidth. The designed decoupling surface effectively reduces the [...] Read more.
This paper proposes a novel THz band 2-D wide-angle scanning phased-array antenna (PAA) based on a decoupling surface. The simulated S11 bandwidth under periodic boundary conditions is 106–119 GHz, with stable gain within the bandwidth. The designed decoupling surface effectively reduces the coupling between elements, and the simulated active VSWR performance and ground surface current distribution under periodic boundary conditions confirm this. An 8 × 8 (64-element) planar PAA is modeled and simulated in CST2022 to verify the beam-scanning performance of the PAA. According to the simulation results, a 2-D wide-angle scanning of ±48° is achieved in the 106–114 GHz range, while in the 115–119 GHz range, a wide-angle scanning of ±48° is achieved on the E-plane, and the beam-scanning range on the H-plane reaches ±40°. Moreover, the normal peak gain is stably maintained at 21.9–22.8 dBi, with a normalized radiation efficiency as high as 95%, and the scanning radiation efficiency is higher than 81%. Due to its stable gain and 2-D wide-angle scanning performance, the proposed PAA has a broad application prospect in terahertz wireless communication equipment. Full article
(This article belongs to the Section Electrical, Electronics and Communications Engineering)
Show Figures

Figure 1

11 pages, 4345 KB
Article
High-Conductivity MXene Film-Based Millimeter Wave Antenna for 5G Applications
by Jiannan Guo, Yunfa Si, Rongguo Song, Haoran Zu, Yitong Xin, Dong Ye, Ming Xu, Bao-Wen Li and Daping He
Crystals 2023, 13(7), 1136; https://doi.org/10.3390/cryst13071136 - 21 Jul 2023
Cited by 3 | Viewed by 3341
Abstract
Millimeter wave antennas have the advantage of high directivity, miniaturization, high resolution and data transfer speed, wide bandwidth, and lower latency. In this work, a millimeter wave planar array antenna (PAA) with the characteristics of wideband and low sidelobes, which consists of eight [...] Read more.
Millimeter wave antennas have the advantage of high directivity, miniaturization, high resolution and data transfer speed, wide bandwidth, and lower latency. In this work, a millimeter wave planar array antenna (PAA) with the characteristics of wideband and low sidelobes, which consists of eight identical linear array antenna (LAA) based on Ti3C2 MXene, is designed and fabricated. It is the first time that MXene antennas are proposed for a 5G millimeter wave antenna application. MXene PAA has a high realized gain of 22.22 dBi and a −10 dB impedance bandwidth of measurement covering the range from 24 GHz to 28 GHz, including the 5G FR2—n258 frequency band. With Chebyshev current distribution, the MXene PAA has a half-power beam width of 10.2° and 10.8° in the xoz-plane and yoz-plane radiation patterns with the sidelobes levels below −20 dB, respectively. Therefore, MXene PAA is suitable for 5G mobile communication applications. Full article
(This article belongs to the Section Materials for Energy Applications)
Show Figures

Figure 1

34 pages, 23062 KB
Article
Linear Antenna Array Sectorized Beam Scanning Approaches Using Element Position Perturbation in the Azimuth Plane
by Safaa I. Abd Elrahman, Ahmed M. Elkhawaga, Amr H. Hussein and Abd Elhameed A. Shaalan
Sensors 2023, 23(14), 6557; https://doi.org/10.3390/s23146557 - 20 Jul 2023
Cited by 4 | Viewed by 2749
Abstract
In this paper, two sector beam scanning approaches (BSAs) based on element position perturbations (EPPs) in the azimuth plane are introduced. In EPP-BSA, the elements’ excitations are kept constant and the elements’ positions in the direction normal to the array line are changed [...] Read more.
In this paper, two sector beam scanning approaches (BSAs) based on element position perturbations (EPPs) in the azimuth plane are introduced. In EPP-BSA, the elements’ excitations are kept constant and the elements’ positions in the direction normal to the array line are changed according to a predetermined EPP pattern. The magnitude and repetition rate of the selected EPP pattern determines the steering angle of the main beam. However, EPP-BSA results in a wide scanning range with a significant increase in the side lobe level (SLL). To mitigate this drawback, a reduction in the SLL of the array pattern is firstly performed using the single convolution/genetic algorithm (SC/GA) technique and then perturbing the elements’ positions in the azimuth plane. This combination between SLL reduction and EPP-BSA (SLL/EPP-BSA) results in a smaller scanning range with a relatively constant half power beamwidth (HPBW) and a much lower SLL. In addition, keeping the synthesized excitation coefficients constant without adding progressive phase shifters facilitates the manufacturing process and reduces the cost of the feeding network. Furthermore, a planar antenna array thinning approach is proposed to realize the EPP-BSA. The results are realized using the computer simulation technology (CST) microwave studio software package, which provides users with an optimized modeling environment and results in realizable and realistic designs. Full article
(This article belongs to the Topic Antennas)
Show Figures

Figure 1

16 pages, 3204 KB
Article
MOM/GA-Based Virtual Array for Radar Systems
by Kamel Sultan, Haythem Abdullah, Esmat Abdallah and Hadia El-Hennawy
Sensors 2020, 20(3), 713; https://doi.org/10.3390/s20030713 - 28 Jan 2020
Cited by 11 | Viewed by 5277
Abstract
This paper introduces a novel antenna array synthesis for radar systems based on the concept of a virtual antenna array (VAA) and the method of moments/genetic algorithm (MoM/GA) synthesis method. The VAA concept is applied to both scanning and fixed radiation pattern arrays. [...] Read more.
This paper introduces a novel antenna array synthesis for radar systems based on the concept of a virtual antenna array (VAA) and the method of moments/genetic algorithm (MoM/GA) synthesis method. The VAA concept is applied to both scanning and fixed radiation pattern arrays. The proposed VAA is introduced to simultaneously support the medium-range radar (MRR) and the long-range radar (LRR) with beam width ±7° for LRR and ±37° for MRR. The proposed VAA is distinguished by its minimum number of antenna elements, simple feeding network, high efficiency, and gain, but all of these are at the expense of a large aperture antenna size compared to the planar antenna array (PAA). The VAA has the ability to have the feeding network and the radiating elements on the same layer, as compared to the multilayer PAA. The newly proposed concept is analyzed and verified analytically and experimentally. Two orthogonal (16 elements) VAAs are designed to operate in the frequency range from 23.55 to 24.7 GHz and to support a flat-shoulder shape (FSS) radiation pattern for LRR/MRR. The antenna was fabricated and tested experimentally, and good agreements between the simulated and measured results were noticed. The proposed VAA is introduced to solve the problems of large size, low isolations, low efficiency, feeding network, low resolution, and small coverage range for the antenna arrays of automotive radars. The proposed antenna array is introduced for automotive radar applications at 24 GHz. Full article
(This article belongs to the Section Remote Sensors)
Show Figures

Figure 1
