In a diesel engine, piston slap commonly occurs concurrently with fuel combustion and serves as the main source of excitation. Although combustion pressure can be measured using sensors, determining the slap force is difficult without conducting tests. In this study, we propose a method to identify the slap force of the piston to solve this difficult problem. The traditional VMD algorithm easily receives noise interference, which affects the value of parameter combination [k, α] and thus affects the extraction accuracy of the algorithm. First, we obtain the transfer function between the incentive and vibration response through percussion tests. Secondly, a variational modal decomposition method based on whale algorithm optimization is used to separate the slap response from the surface acceleration of the block. Finally, we calculated the slap force using the deconvolution method. Deconvolution is a typical inverse problem of mathematics, often prone to ill-conditioning, and the singular value decomposition and regularization method is used to overcome this flaw and improve accuracy. The proposed method provides an important means to evaluate the angular distribution of the slap force, identify the shock positions on the piston liner, and determine the peak value of the waveform which helps us analyze the vibration characteristics of the piston and optimize the structural design of the engine. Full article

Internal combustion engines take up the major position in the power facility market and still encounter some challenges; one key issue is liner cavitation erosion. The impact vibration between piston and cylinder generates pressure fluctuation on the wet liner surface and leads to the occurrence of cavitation in the case that coolant pressure falls below its vapor pressure. Piston slap methodology has been improved by considering the dynamic characteristics of the piston. Water coolant passage acoustic features were investigated and the Helmholtz effect between cylinders was confirmed. In order to address the cavitation erosion potential of the engine cylinder, acoustic pressure in the cooling water passage was investigated by boundary element method analysis with the acceleration of the cylinder liner which was obtained from the piston slap program. This study revealed that a certain acoustic mode of the cooling water passage had a dominant effect on the amplitude of water coolant dynamic pressure induced by liner vibration. Measures of eliminating the acoustic mode are believed to be able to suspend pressure fluctuation and furthermore the potential of cavitation. Full article

In recent years, biodiesel has been demonstrated to offer a suitable level of reliability and attracted the attention of many researchers. Accordingly, various studies have been carried out to account for the biodiesel production and application, producing valuable reports and findings. In this research study, the effects of biodiesel on engine noise were studied on the basis of a time–frequency analysis. To do so, the acquired acoustic signal was initially filtered and denoised. Then the signal was transferred to the time–frequency SPL domain using short-time Fourier transform. In the A weighted signal, the SPL of all treatments were compared using an innovative visual technique. In this novel approach, the values of area percentages of the obtained SPL in the time–frequency domain were used to compare the propagated noise due to variables. The method revealed a consistent trend for all fuel blends at all engine rotational speeds. The analysis results showed that B10 (10% methyl/ethyl ester and 90% diesel fuel) and B30 had the lowest and highest A-Weighted SPL, respectively. Additionally, it was found that the engine had a maximum sensitivity for all fuel blends at an engine rotation speed of 1600 RPM. Moreover, Z-weighted (linear) signal processing was used to investigate what happens in a complete thermodynamic cycle at 1600 RPM. The developed time–frequency methodology successfully exposed all of the important acoustic events of the engine. The results of this study showed that the most effective acoustic events in engine noise were combustion, piston slap, and outlet valve closing. Furthermore, higher percentages of biodiesel blends resulted in longer combustion duration. Full article

The present study aims to analyze the secondary movement of the piston considering the deformations present in the piston skirt, the hydrodynamic lubrication, and the effects of the clearances in the connecting rod bearings. The analysis of the piston movement is performed by developing a mathematical model, which was used to evaluate the dynamic characteristics of the piston movement, the slap force on the piston skirt, the effect of the secondary piston movement on the connecting rod, and the influence of clearances in the connecting rod bearings and in the piston. For the study, the geometric of the crankshaft-connecting rod–piston system of a single-cylinder diesel engine is taken as a reference. The deformation model of the piston was carried out by means of a symmetric finite element model (FEM), which was integrated into the mathematical model of the piston. MATLAB^® software (The MathWorks Inc., Natick, MA, USA) is used for the development of model simulations. The obtained results show that during the combustion cycle, there are six changes of direction in the secondary movement of the piston with lateral and angular velocities that can reach a magnitude of 0.13 m/s and 4 rad/s. The lateral and angular movement of the piston during its travel causes the appearance of impacts on the piston skirt with the cylinder liner, which produces an increase of approximately 500 N in the hydrodynamic forces in the connecting rod bearings. The force analysis shows that the range of the maximum magnitudes of these forces is between 1900 N and 3480 N. The increase in clearance between the cylinder liner and the piston skirt (Cpc) causes a greater lateral displacement and an increase in the angle of inclination of the piston. Analysis of the change in connecting rod bearing clearance shows that there are critical values in relation to clearance Cpc. The model presented allows us to analyze the different characteristics of the secondary movement of the piston, which involve the interaction between the piston skirt and the cylinder liner. Additionally, the influence of this movement on the connecting rod bearings is considered. The foregoing can be used as an analysis tool for the study of designs and/or modifications in the engine in such a way that greater durability of the components, reductions in acoustic emissions, and reduction in friction losses are achieved. Full article

The friction pair of piston rings and cylinder liner is one of the most important friction couplings in an internal combustion engine. It influences engine efficiency and service life. Under the excitation of piston slaps, the dynamic deformation of cylinder liner is close to the surface roughness magnitudes, which can affect the friction and lubrication performance between the piston rings and cylinder assemblies. To investigate the potential influences of structural deformations to tribological behaviours of cylinder assemblies, the dynamic deformation of the inner surface due to pistons slaps is obtained by dynamic simulations, and then coupled into an improved lubrication model. Different from the traditional lubrication model which takes the pressure stress factor and shear stress factor to be constant, the model proposed in this paper calculated these factors in real time using numerical integration to achieve a more realistic simulation. Based on the improved piston rings and cylinder liner lubrication model, the minimum oil film thickness and friction force curves are obtained for an entire work cycle. It shows that the friction force obtained from the improved model manifests clear oscillations in each stoke, which is different from the smoothed profiles predicted traditionally. Moreover, the average amplitude of the friction forces also shows clear reduction. Full article

The paper presents a study of the relationship between the combustion behavior and vibration response of internal combustion (IC) engines fueled with biodiesel based on finite element modelling along with experimental evaluation. An improved finite element (FE) model is established and validated to predict the dynamic responses of cylinder liners with respect to two main sources: combustion shock and piston side thrust. Based on the validated FE model, the response characteristics of the cylinder liner in an IC engine fueled with biodiesel and its causal relationship with excitation sources have been predicted. Due to the lower calorific value of biodiesel, a greater amount of fuel is injected into the combustion chamber to maintain power outputs, which results in a prolonged combustion duration and subsequent higher overall vibration levels, compared with that of diesel. The advanced ignition of biodiesel is the main cause to the compound effect on the coupling of piston side-thrust force, thereby resulting in a nonlinear increase in the root mean square (RMS) of local vibration response close to the combustion top dead center (TDC). These key findings provides insight understandings for not only biodiesel combustion diagnostics but also more accurate diagnostics of fossil diesel based on nonintrusive vibrations. Full article
