Based on the finite element method, the modulation of the bending wave bandgap and bending waveguide of locally resonant phononic crystal (PnC) plates via a thermal environment is investigated. First, the finite element model of the PnC subjected to a thermal field is introduced; then, the modulation behavior of the bending wave bandgap of the PnC under thermal flux is illustrated; finally, the tunable waveguide of the bending waveguide of the PnC supercell is proposed to be realized by setting up a local heat source. The results show that the injected heat flux causes the PnC unit cell band structure to move toward the low-frequency region while the relative bandgap width increases. The linear defect state of the PnC supercell structure is realized by introducing a local heat source, and a new band is added to the bending wave bandgap of the original supercell. The transmission loss of the bending wave is significantly higher than that of the bending wave bandgap of the supercell in the frequency interval of the linear defect of the supercell, and the frequency response vibrational modes of the supercell structure validate the feasibility of the thermally controlled bending waveguide. This method provides a flexible and efficient control strategy for the frequency tuning of the bending wave bandgap and waveguide. Full article

As a type of locally resonant phononic crystal, alloy steel phononic crystals have achieved notable advancements in vibration and noise reduction, particularly in the realm of low-frequency noise. Their exceptional band gap characteristics enable the efficient reduction of vibration and noise at low frequencies. However, the conventional transmission loss (TL) simulation of finite structures remains the benchmark for plate structure TL experiments. In this context, the TL in the XY-direction of phononic crystal plate structures has been thoroughly investigated and analyzed. Given the complexity of sound wave incident directions in practical applications, the conventional TL simulation of finite structures often diverges from reality. Taking tungsten steel phononic crystals as an example, this paper introduces a novel finite element method (FEM) simulation approach for analyzing the TL of alloy steel phononic crystal plates. By setting the Z-direction as the excitation source, the tungsten steel phononic crystal plate exhibits distinct responses compared to excitation in the XY-direction. By combining energy band diagrams and modes, the impact of various excitation source directions on the TL simulations is analyzed. It is observed that the tungsten steel phononic crystal plate exhibits a more pronounced energy response under longitudinal excitation. The TL map excited in the Z-direction lacks the flat region present in the XY-direction TL map. Notably, the maximum TL in the Z-direction is 131.5 dB, which is significantly lower than the maximum TL of 298 dB in the XY-direction, with a more regular peak distribution. This indicates that the TL of alloy steel phononic crystals in the XY-direction is closely related to the acoustic wave propagation characteristics within the plate, whereas the TL in the Z-direction aligns more closely with practical sound insulation and noise reduction engineering applications. Therefore, future research on alloy steel phononic crystal plates should not be confined to the TL in the XY-direction. Further investigation and analysis of the TL in the Z-direction are necessary. This will provide a novel theoretical foundation and methodological guidance for future research on alloy steel phononic crystals, enhancing the completeness and systematicness of studies on alloy steel phononic crystal plates. Simultaneously, it will advance the engineering application of alloy steel phononic crystal plates. Full article

Ion implantation in diamond crystals is widely used both for producing conducting microstructures in the bulk of the material and for creating isolated photon emitters in quantum optics, photonics, cryptography, and biosensorics. The photoluminescence (PL) spectra of helium ion-implanted diamonds are dominated by two sharp emission lines, HR1 and HR2 (from Helium-Related), at ~536 and 560 nm. Here, we report on PL studies of helium-related optical centers in diamonds. Experiments have been carried out on a (110) plate of natural single-crystal type IIa diamonds. The uniform distribution of radiation defects in a 700 nm-thick layer was obtained by ten cycles of multiple-energy (from 24 to 350 kV) helium ion implantation with a total dose of 5 × 10¹⁶ cm⁻². The diamonds were annealed in steps in a vacuum oven at temperatures from 200 to 1040 °C. It is demonstrated that helium ion implantation in diamonds followed by annealing gives rise to more than a dozen various centers that are observed in the PL spectra in the range of 530–630 nm. The transformations of the PL spectra due to annealing are investigated in detail. The spectral shapes of phonon sidebands are determined for the HR1, HR2, and HR3 bands with ZPLs at ~536, 560, and 577 nm, respectively, and it is shown that these bands are attributed to interstitial-related centers in diamonds. The reported results are important for understanding the structure and properties of helium-related defects in diamonds. Full article

Phononic crystals based on lattice structures provide important wave dispersion characteristics as band structures, showing excellent compatibility with additive manufacturing. Although the lattice structures have shown the potential for vibration suppression, a design guideline to control the frequency range of the bandgap has not been well established. This paper studies the dispersion characteristics of plane wave propagation in lattice-based mechanical metamaterials to realize effective vibration suppression for potential aerospace applications. Triangular and hexagonal periodic lattice structures are mainly studied in this paper. The influence of different geometric parameters on the bandgap characteristics is investigated. A finite element approach with Floquet–Bloch’s principles is implemented to effectively evaluate the dispersion characteristics of waves in lattice structures, which is validated numerically and experimentally with a 3D-printed lattice plate. Based on numerical studies with the developed analysis framework, the influences of the geometric parameters of lattice plate structures on dispersion characteristics can mainly be categorized into three patterns: change in specific branches related to in-plane or out-of-plane vibrations, upward/downward shift in frequency range, and drastic change in dispersion characteristics. The results obtained from the study provide insight into the design of band structures to realize vibration suppression at specific frequencies for engineering applications. Full article

Focusing on the bending wave characteristic of plate–shell structures, this paper derives the complex band curve of piezoelectric phononic crystal based on the equilibrium differential equation in the plane stress state using COMSOL PDE 6.2. To ascertain the computational model’s accuracy, the computed complex band curve is then cross-validated against real band curves obtained through coupling simulations. Utilizing this model, this paper investigates the impact of structural and electrical parameters on the bandgap range and the attenuation coefficient in the bandgap. Results indicate that the larger surface areas of the piezoelectric sheet correspond to lower center bands in the bandgap, while increased thickness widens the attenuation coefficient range with increased peak values. Furthermore, the influence of inductance on the bandgap conforms to the variation law of the electrical LC resonance frequency, and increased resistance widens the attenuation coefficient range albeit with decreased peak values. The incorporation of negative capacitance significantly expands the low-frequency bandgap range. Visualized through vibration transfer simulations, the vibration-damping ability of the piezoelectric phononic crystal is demonstrated. Experimentally, this paper finds that two propagation modes of bending waves (symmetric and anti-symmetric) result in variable voltage amplitudes, and the average vibration of the system decreases by 4–5 dB within the range of 1710–1990 Hz. The comparison between experimental and model-generated data confirms the accuracy of the attenuation coefficient calculation model. This convergence between experimental and computational results emphasizes the validity and usefulness of the proposed model, and this paper provides theoretical support for the application of piezoelectric phononic crystals in the field of plate–shell vibration reduction. Full article

Aiming to address the vibration noise problems on ships, we constructed a piezoelectric phononic crystal (PC) plate structure model, solved the governing equations of the structure using the partial differential equations module (PDE) in the finite element softwareCOMSOL6.1, and obtained the corresponding energy band structure, transmission curves, and vibration modal diagrams. The application of this method to probe the structural properties of two-dimensional piezoelectric PCs is described in detail. The calculation results obtained using this method were compared with the structures obtained using the traditional plane wave expansion method (PWE) and the finite element method (FE). The results were found to be in perfect agreement, which verified the feasibility of this method. To safely and effectively adjust the bandgap within a reasonable voltage range, this paper explored the order of magnitude of the plate thickness, the influence of the voltage on the bandgap, and the dependence between them. It was found that the smaller the order of magnitude of the plate thickness, the smaller the order of magnitude of the band in which the bandgap was located. The magnitude of the driving voltage that made the bandgap change became smaller accordingly. The new idea of attaching the PC plate to the conventional plate structure to achieve a vibration damping effect is also briefly introduced. Finally, the effects of lattice constant, plate width, and thickness on the bandgap were investigated. Full article

This paper proposes a local resonance-type pentagonal phononic crystal beam structure for practical engineering applications to achieve better vibration and noise reduction. The energy band, transmission curve, and displacement field corresponding to the vibration modes of the structure are calculated based on the finite element method and Bloch-Floquet theorem. Furthermore, an analysis is conducted to understand the mechanism behind the generation of bandgaps. The numerical analysis indicates that the pentagonal unit oscillator creates a low-frequency bandgap between 60–70 Hz and 107–130 Hz. Additionally, the pentagonal phononic crystal double-layer beam structure exhibits excellent vibration damping, whereas the single-layer beam has poor vibration damping. The article comparatively analyzes the effects of different parameters on the bandgap range and transmission loss of a pentagonal phononic crystal beam. For instance, increasing the thickness of the lead layer leads to an increase in the width of the bandgap. Similarly, increasing the thickness of the rubber layer, intermediate plate, and total thickness of the phononic crystals results in a bandgap at lower frequencies. By adjusting the parameters, the beam can be optimized for practical engineering purposes. Full article

In order to alleviate the structural vibrations induced by traffic loads, in this paper, a phonon crystal plate with functionally graded materials is designed based on local resonance theory. The vibration damping performance of the phonon crystal plate is studied via finite element numerical simulation and the band gap is verified via vibration transmission response analysis. Finally, the engineering application mode is simulated to make it have practical engineering application value. The results show that the phonon crystal plate has two complete bandgaps within 0~150 Hz, the initial bandgap frequency is 0.00 Hz, the cut-off frequency is 128.32 Hz, and the internal ratio of 0~100 Hz is 94.13%, which can effectively reduce the structural vibration caused by traffic loads. Finally, stress analysis of the phonon crystal plate is carried out. The results show that phonon crystals of functionally graded materials can reduce stress concentration through adjusting the band gap. The phonon crystal plate designed in this paper can effectively suppress the structural vibration caused by traffic loads, provides a new method for the vibration reduction of traffic infrastructure, and can be applied to the vibration reduction of bridges and their auxiliary facilities. Full article

For the application of low-frequency vibration damping in industry, a cylindrical cavity double-layer plate-type local resonance phononic crystal structure is proposed to solve low-frequency vibration in mechanical equipment. Initially, using COMSOL 5.4 software, the bending wave band gap is calculated in conjunction with elastic dynamics theory and the BOLOCH theorem to be 127–384 Hz. Then the mechanism of bending wave gap is analyzed by combining element mode shape and an equivalent model. Subsequently, the bending vibration transmission characteristics of the crystal plate are explained, and the vibration-damping characteristics are illustrated in combination with the time–frequency domain. An experimental system is constructed to verify the vibration-damping properties of crystal plates; the experimental results and simulation results are verified with each other. Finally, the element structural parameters are optimized using the RSM. Fifty-four sets of experiments are designed based on six structural factors and three levels, and the expressions between the bending wave band gap and six structural factors are obtained. Combining the particle swarm algorithm, the optimization is performed with the band gap width as the target. This method is shown to be more accurate than the commonly used interior point method. The structure of cylindrical-cavity-type phononic crystal and the parameter optimization method proposed in this paper provide a certain reference for the design of local-resonance-type phononic crystal. Full article

Phononic crystals and metamaterials have a unique band structure that allows for the existence of topologically protected surface states. The topologically protected edge states can guide elastic waves without significant scattering or loss of energy. One of the most promising applications of topological insulators in wave guiding is in the field of acoustics, where they can be used to design highly efficient and robust acoustic wave guides. However, the high efficiency, precision, reconfigurability, and robustness of elastic waves remains challenging. The topological insulators provide a feasible method to design high-efficiency, robust, and low-backscattering waveguides. In this work, a novel design of hexagonal metamaterial plates composed of a base plate and piezoelectric patches is proposed. The hexagonal metamaterial plate can generate robust topologically protected edge waves via active control. The paths of the topologically protected edge waves can be tuned by adjusting the control parameters. The robustness and efficiency of the proposed hexagonal metamaterial plate are testified to by the numerical examples. These findings provide systematic theoretical guidelines for designing reconfigurable wave guides, elastic wave splitters, and novel elastic wave devices and hold great promise for the development of high-performance and versatile wave guide technologies with potential applications in a wide range of fields. Full article

The finite element method (FEM) was applied to study the low frequency band gap characteristics of a designed phonon crystal plate formed by embedding a hollow lead cylinder coated with silicone rubber into four epoxy resin short connecting plates. The energy band structure, transmission loss and displacement field were analyzed. Compared to the band gap characteristics of three traditional phonon crystal plates, namely, the square connecting plate adhesive structure, embedded structure and fine short connecting plate adhesive structure, the phonon crystal plate of the short connecting plate structure with a wrapping layer was more likely to generate low frequency broadband. The vibration mode of the displacement vector field was observed, and the mechanism of band gap formation was explained based on the spring mass model. By discussing the effects of the width of the connecting plate, the inner and outer radii and height of the scatterer on the first complete band gap, it indicated that the narrower the width of the connecting plate, the smaller the thickness; the smaller the inner radius of the scatterer, the larger the outer radius; and the higher the height, the more conducive it is to the expansion of the band gap. Full article

Locally resonant phononic crystals are a kind of artificial periodic composite material/structure with an elastic wave band gap that show attractive application potential in low-frequency vibration control. For low-frequency vibration control problems of ship power systems, this paper proposes a phononic crystal board structure, and based on the Bloch theorem of periodic structure, it uses a finite element method to calculate the band structure and the displacement fields corresponding to the characteristic mode and vibration transmission curve of the corresponding finite periodic sandwich plate structure, and the band gap characteristics are studied. The mechanism of band gap formation is mainly attributed to the mode coupling of the phononic crystal plate structure. Numerical results show that the sandwich plate structure has a double periodicity, so it has a multi-stage elastic wave band gap, which can fully inhibit the transmission of flexural waves and isolate the low-frequency flexural vibration. The experimental measurements of flexural vibration transmission spectra were conducted to validate the accuracy and reliability of the numerical calculation method. On this basis, the potential application of the proposed vibration isolation method in a marine power system is discussed. A vibration isolation platform mounted on a steel plate is studied by numerical simulation, which can isolate low-frequency vibration to protect electronic equipment and precision instruments. Full article

Sieving specific particles from mixed samples is of great value in fields such as biochemistry and additive manufacturing. In this study, a particle sieving method for microfluidics was proposed based on a phononic crystal plate (PCP), the mechanism of which originates from the competition between the trapping effect of the resonant PCP-induced acoustic radiation force (ARF), disturbance effect of acoustic streaming (AS), and flushing effect of the continuous inlet flow on particles suspended in microfluidic channels. Specifically, particles with different sizes could be separated under inlet flow conditions owing to ARF and AS drag forces as functions of the particle diameter, incident acoustic pressure, and driving frequency. Furthermore, a comprehensive numerical analysis was performed to investigate the impacts of ARF, AS, and inlet flow conditions on the particle motion and sieving efficiency, and to explore proper operating parameters, including the acoustic pressure and inlet flow velocity. It was found that, for each inlet flow velocity, there was an optimal acoustic pressure allowing us to achieve the maximum sieving efficiency, but the sieving efficiency at a low flow velocity was not as good as that at a high flow velocity. Although a PCP with a high resonant frequency could weaken the AS, thereby suiting the sieving of small particles (<5 μm), a low channel height corresponding to a high frequency limits the throughput. Therefore, it is necessary to design a PCP with a suitable resonant frequency based on the size of the particles to be sieved. This investigation can provide guidance for the design of massive acoustic sorting mi-crofluidic devices based on phononic crystals or acoustic metamaterials under continuous flow. Full article

Based on the concept of band topology in phonon dispersion, we designed a topological phononic crystal in a thin plate for developing an efficient elastic waveguide. Despite that various topological phononic structures have been actively proposed, a quantitative design strategy of the phononic band and its robustness assessment in an elastic regime are still missing, hampering the realization of topological acoustic devices. We adopted a snowflake-like structure for the crystal unit cell and determined the optimal structure that exhibited the topological phase transition of the planar phononic crystal by changing the unit cell structure. The bandgap width could be adjusted by varying the length of the snow-side branch, and a topological phase transition occurred in the unit cell structure with threefold rotational symmetry. Elastic waveguides based on edge modes appearing at interfaces between crystals with different band topologies were designed, and their transmission efficiencies were evaluated numerically and experimentally. The results demonstrate the robustness of the elastic wave propagation in thin plates. Moreover, we experimentally estimated the backscattering length, which measures the robustness of the topologically protected propagating states against structural inhomogeneities. The results quantitatively indicated that degradation of the immunization against the backscattering occurs predominantly at the corners in the waveguides, indicating that the edge mode observed is a relatively weak topological state. Full article

Anchor loss is usually the most significant energy loss factor in Micro-Electro-Mechanical Systems (MEMS) resonators, which seriously hinders the application of MEMS resonators in wireless communication. This paper proposes a cross-section connection phononic crystal (SCC-PnC), which can be used for MEMS resonators of various overtone modes. First, using the finite element method to study the frequency characteristics and delay line of the SCC-PnC band, the SCC-PnC has an ultra-wide bandgap of 56.6–269.6 MHz. Next, the effects of the height h and the position h₁ of the structural parameters of the small cross-connected plate on the band gap are studied, and it is found that h is more sensitive to the width of the band gap. Further, the SCC-PnC was implanted into the piezoelectric MEMS resonator, and the admittance and insertion loss curves were obtained. The results show that when the arrangement of 4 × 7 SCC-PnC plates is adopted, the anchor quality factors of the third-order overtone, fifth-order overtone, and seventh-order overtone MEMS resonators are increased by 1656 times, 2027 times, and 16 times, respectively. Full article
