A Hz level narrow linewidth all-optical microwave oscillator based on the torsional radial acoustic modes (TR_2,m) of a single-mode fiber (SMF) is proposed and validated. The all-optical microwave oscillator consists of a 20 km SMF main ring cavity and a 5 km SMF sub ring cavity. The main ring cavity provides forward stimulated Brillouin scattering gain and utilizes a nonlinear polarization rotation effect to achieve TR_2,7 mode locking. By combining the sub ring cavity with the main ring cavity and utilizing the Vernier effect, the TR_2,7 mode microwave photonic single longitudinal mode (SLM) output can be ensured. Meanwhile, the 6.281 Hz narrow linewidth of the TR_2,7 mode is achieved by reducing the intrinsic linewidth of the passive resonant cavity. The acoustic mode suppression ratio and side mode suppression ratio of the TR_2,7 mode were 43 dB and 54 dB, respectively. The power and frequency fluctuations of within 40 min were approximately ±0.49 dB and ±0.187 kHz, indicating good stability. At a frequency offset of 10 kHz, the TR_2,7 mode had a low phase noise value of −110 dBc/Hz. This solution can be used in various fields, such as high-precision radar detection, long-distance optical communication, and high-performance fiber optic sensing. Full article

Major space agencies such as NASA and the ESA have long reported the growing dangers caused by resident space objects orbiting our planet. These objects continue to grow in number as satellites are imploded and space debris impacts each other, causing fragmentation. As a result, significant efforts by both the public and private sectors are geared towards enhancing space domain awareness capabilities to protect future satellites and astronauts from impact by these orbiting debris. Current approaches and standards implement very large radar arrays, telescopes, and laser ranging systems to detect and track such objects. These systems are very expensive, may take significant amounts of time to develop, and are still only sparingly able to efficiently track debris targets less than 10 cm in diameter. This work proposes a theoretical passive-radar-based method using illuminators of opportunity for detecting space debris while estimating motion direction and Doppler. We show that by using a signal processing chain based on the self-mixing technique and digital filters, Doppler information can be extracted and continuously tracked by a uniform linear receiver array. This can be achieved by a passive sensor system, which has the advantage of lower cost without the need to emit signals that constrain the spectrum sharing issues. Full article

The Soil Moisture Active–Passive (SMAP) mission has greatly contributed to the use of remote sensing technologies for monitoring the Earth’s land surface and estimating geophysical parameters that influence the climate system. Since the SMAP mission switched its radar receiver to allow the reception of Global Positioning System (GPS) signals, Global Navigation Satellite System Reflectometry (GNSS-R) configuration has been enabled, providing full polarimetric forward scattering measurements of the Earth’s surface, also known as SMAP Reflectometry or SMAP-R. Polarimetric GNSS-R is beneficial for sensing land surface properties, especially for more accurate estimations of soil moisture (SM) in densely vegetated areas. In this study, we explore the opportunity to enhance SMAP mission soil moisture estimates using reflected GNSS signals. We achieve this by interpolating the sparse reflectivity data with terrain information to disaggregate radiometer brightness temperatures. Our main objective is to present a novel algorithm based on Graph Signal Processing (GSP) that uses reflectometry data to enhance SMAP radiometer observations and ultimately improve SM retrievals. By implementing methods from the GSP field, we formulate the reflectivity interpolation problem as a signal reconstruction on a graph, where the weights of the edges between the nodes are chosen as a function of geophysical information. Subsequently, using the retrieved reflectivity maps, we increase the resolution of the brightness temperature data, leading to an improvement in the SM estimates. Initial findings indicate that our GSP method presents a promising alternative for analyzing sparse remote sensing observations, leveraging Earth’s surface geophysical information. This approach results in a notable improvement, with a reduced Root Mean Square Error (RMSE) of 11.8% compared to SMAP data and a reduction in unbiased RMSE (uRMSE) by 14.7% over vegetated areas. Full article

This paper presents a soil moisture retrieval scheme from Cyclone Global Navigation Satellite System (CYGNSS) delay-Doppler maps (DDMs) over land. The proposed inversion method consists of a hybrid global and local optimization method and a physics-based bistatic scattering forward model. The forward model was developed for bare-to-densely vegetated terrains, and it predicts the circularly polarized bistatic radar cross section DDM of the land surface. This method was tested on both simulated DDMs and CYGNSS DDMs over the Soil Moisture Active Passive (SMAP) Yanco core validation site in Australia. About 250 CYGNSS DDMs from 2019 and 2020 over the Yanco site were used for validation. The simulated DDMs were for grassland and forest vegetation types. The vegetation type of the Yanco validation site was grassland. The vegetation water content (VWC) was $0.19 \mathrm{kg}$${\mathrm{m}}^{-2}$ and $4.89 \mathrm{kg}$${\mathrm{m}}^{-2}$ for the grassland and forest terrains, respectively. For the case when the surface roughness is known to the algorithm, the unbiased root mean square error (ubRMSE) of soil moisture estimates was less than $0.03 {\mathrm{m}}^3$${\mathrm{m}}^{-3}$ while it was approximately $0.06 {\mathrm{m}}^3$${\mathrm{m}}^{-3}$ and $0.09 {\mathrm{m}}^3$${\mathrm{m}}^{-3}$ for the validation results from 2019 and 2020, respectively. The retrieval algorithm generally had enhanced performance for smaller values of soil moisture. For the case when both the soil moisture and surface roughness are unknown to the algorithm and only a single DDM is used for retrieval, the validation results showed an expected reduced performance, with an an ubRMSE of less than $0.12 {\mathrm{m}}^3$${\mathrm{m}}^{-3}$. Full article

The problem of single-channel reception of global positioning system (GPS) communication waveforms makes passive sensing of aerial target difficult because of forward scatter. This paper proposes a novel aerial target passive sensing method based on linear canonical transformation (LCT) using the forward scattered satellite communication waveforms. The proposed method firstly preprocesses the received signal based on the characteristics of the traditional satellite tracking loop and the forward scattered satellite communication waveforms to effectively suppress the interference of the direct wave through DC removal. Then, the Gaussian noise and multipath interference in the channel are suppressed by applying a rectangular window to its linear canonical domain. Finally, aerial target sensing is performed based on the peak value of signals in the linear canonical transform domain. The characteristic signal is constructed by analyzing the satellite communication waveforms. Combining the linear canonical transform with the matched filter (MF) to estimate the target parameter. Simulation results show that the proposed method can effectively perform the aerial target sensing by using satellite communication waveforms in the forward scatter scenario. Full article

Passive radar based on the global navigation satellite positioning system (GNSS) has become the focus of attention in the field of radar. A parameter estimation method is proposed in the forward scatter radar (FSR) network based on GNSS to extend the application scenarios. For uniformly accelerating moving targets, only the instant times when the target crosses the individual baselines are used to retrieve the target motion parameters. The target position, velocity, and acceleration information can be obtained. Firstly, the minimum network configuration is derived theoretically. Then, the effects of crossing time error, station location error, transmitting/receiving station deployment, and target height on the accuracy are analyzed through Monte Carlo simulations. Finally, the simulation results indicate that the target position estimation error is in the order of 100 m. This paper provides the fundamental theory of aerial target positioning with a GNSS-based FSR network. Full article

This paper presents a passive radar system using a signal of opportunity from Digital Video Broadcasting Satellite (DVB-S). The ultimate purpose of the system is to be used as an air traffic monitoring and surveillance system. However, the work focuses on drone detection as a proof of the concept. Detecting a drone by using satellite-based passive radar possess inherent challenges, such as the small radar cross section and low speed. Therefore, this paper proposes a unique method by leveraging the advantage of forward-scattering radar (FSR) topology and characteristics to detect a drone; in other words, the system is known as a passive FSR (p-FSR) system. In the signal-processing algorithm, the empirical mode decomposition (EMD) is applied to the received signal to extract the unique feature vector of the micro-Doppler frequency from the drone’s rotating blades. The paper highlights the p-FSR experimental setup and experiment campaign to detect drones. The experimental results show the feasibility of the p-FSR using a signal transmitted from a satellite to detect flying drone crossing the forward-scatter baseline between the satellite and ground station. Full article

This paper presents the application of the time-frequency (TF) reassignment technique in passive forward scattering radar (FSR) using Digital Video Broadcasting – Terrestrial (DVB-T) transmitters of opportunity operating in the Very High Frequency (VHF) band. The validation of the proposed technique was done using real-life signals collected by the passive radar demonstrator during a measurement campaign. The scenario was chosen to test detection ranges and the capability of estimating the kinematic parameters of a cooperative airborne target in passive FSR geometry. Additionally, in the experiment the possibility of utilizing FSR geometry in foliage penetration conditions taking advantage of the VHF band of a DVB-T illuminator of opportunity was tested. The results presented in this paper show that the concentrated (reassigned) energy distribution of the signal in the TF domain allows a more precise target Doppler rate to be estimated using the Hough transform. Full article

This article presents a novel approach to the estimation of motion parameters of objects in passive forward scattering radars (PFSR). In such systems, most frequency modulated signals which are used have parameters that depend on the geometry of a radar scene and an object’s motion. Worth noting is that in bistatic (or multistatic) radars forward scattering geometry is present thus in this case only Doppler measurements are available while the range measurement is unambiguous. In this article the modulation factor, also called the Doppler rate, was determined based on the chirp rate (equivalent Doppler rate) estimation concept in the time-frequency (TF) domain. This approach utilizes the idea of the complex phase of the short-time Fourier transform (STFT) and its modification known from the literature. Mathematical dependencies were implemented and verified and the simulation results were described. The accuracy of the considered estimators were also verified using the Cramer-Rao lower bound (CRLB) to which simulated data for the considered estimators was compared. The proposed method was validated using a real-life signal collected from a radar operating in PFSR geometry. The Doppler rate provided by a car crossing the baseline between the receiver and the GSM transmitter was estimated. Finally, the concept of using CR estimation, which in the case of PFSR can be understood as Doppler rate, was confirmed on the basis of both simulated and real-life data. Full article

The increase in drone misuse by civilian apart from military applications is alarming and need to be addressed. This drone is characterized as a low altitude, slow speed, and small radar cross-section (RCS) (LSS) target and is considered difficult to be detected and classified among other biological targets, such as insects and birds existing in the same surveillance volume. Although several attempts reported the successful drone detection on radio frequency-based (RF), thermal, acoustic, video imaging, and other non-technical methods, however, there are also many limitations. Thus, this paper investigated a micro-Doppler analysis from drone rotating blades for detection in a special Forward Scattering Radar (FSR) geometry. The paper leveraged the identified benefits of FSR mode over conventional radars, such as improved radar cross-section (RCS) value irrespective of radar absorbing material (RAM), direct signal perturbation, and high resolutions. To prove the concept, a received signal model for micro-Doppler analysis, a simulation work, and experimental validation are elaborated and explained in the paper. Two rotating blades aspect angle scenarios were considered, which are (i) when drone makes a turn, the blade cross-sectional area faces the receiver and (ii) when drone maneuvers normally, the cross-sectional blade faces up. The FSR system successfully detected a commercial drone and extracted the micro features of a rotating blade. It further verified the feasibility of using a parabolic dish antenna as a receiver in FSR geometry; this marked an appreciable achievement towards the FSR system performance, which in future could be implemented as either active or passive FSR system. Full article

The Radar Vegetation Index (RVI) is a well-established microwave metric of vegetation cover. The index utilizes measured linear scattering intensities from co- and cross-polarization and is normalized to ideally range from 0 to 1, increasing with vegetation cover. At long wavelengths (L-band) microwave scattering does not only contain information coming from vegetation scattering, but also from soil scattering (moisture & roughness) and therefore the standard formulation of RVI needs to be revised. Using global level SMAP L-band radar data, we illustrate that RVI runs up to 1.2, due to the pre-factor in the standard formulation not being adjusted to the scattering mechanisms at these low frequencies. Improvements on the RVI are subsequently proposed to obtain a normalized value range, to remove soil scattering influences as well as to mask out regions with dominant soil scattering at L-band (sparse or no vegetation cover). Two purely vegetation-based RVIs (called RVII and RVIII), are obtained by subtracting a forward modeled, attenuated soil scattering contribution from the measured backscattering intensities. Active and passive microwave information is used jointly to obtain the scattering contribution of the soil, using a physics-based multi-sensor approach; simulations from a particle model for polarimetric vegetation backscattering are utilized to calculate vegetation-based RVI-values without any soil scattering contribution. Results show that, due to the pre-factor in the standard formulation of RVI the index runs up to 1.2, atypical for an index normally ranging between zero and one. Correlation analysis between the improved radar vegetation indices (standard RVI and the indices with potential improvements RVII and RVIII) are used to evaluate the degree of independence of the indices from surface roughness and soil moisture contributions. The improved indices RVII and RVIII show reduced dependence on soil roughness and soil moisture. All RVI-indices examined indicate a coupled correlation to vegetation water content (plant moisture) as well as leaf area index (plant structure) and no single dependency, as often assumed. These results might improve the use of polarimetric radar signatures for mapping global vegetation. Full article

Soil surface roughness and above-ground vegetation water content (VWC) are estimated by inverting physical models for L-band scattering and absorption at 40° incidence angle using ground, airborne and Soil Moisture Active Passive (SMAP) radar data. The spatial resolution varies from field scale (airborne and ground) to 3 km (SMAP). The temporal resolution is defined by the length and interval of observation time windows (weeks to three months for surface roughness, and three to seven days for VWC). The validation of the roughness estimates shows an accuracy of 25% (bare surface) and 29 to 46% (croplands and pasture). The correlation degrades as vegetation becomes thicker, indicating the stronger scattering and absorption by thicker vegetation. The roughness retrievals with the SMAP data are within the physical range of 0.5 cm to 4 cm. They show larger values in croplands than in natural terrain. The VWC estimate modifies a ‘first guess’ (in situ values for the airborne experiment; and 16-daily climatology for SMAP). The VWC retrievals correctly follow the full growth of crops and the RMSE is smaller than 20% in the airborne retrievals: the correlation ranges from 0.57 to 0.91. These results demonstrate that the forward model inversion has a potential to retrieve VWC for the four major crops over the entire phase of the crop growth. The VWC retrievals from the SMAP data revised the climatology first guess more in the croplands, where the climatology is more likely to depart from the contemporaneous condition than in natural landcover. The value of this work lies in the fact that the surface roughness at the footprint scale is difficult to characterize and a global VWC product at SMAP’s spatial scale from microwave observations is rare, and that this paper presents a plausible pathway towards such products. The estimates at these temporal and spatial scales derived from microwave observations will be useful for studies of climate, agriculture, and soil moisture. Full article

The passive bistatic radar (PBR) system can utilize the illuminator of opportunity to enhance radar capability. By utilizing the forward scattering technique and procedure into the specific mode of PBR can provide an improvement in target detection and classification. The system is known as passive Forward Scattering Radar (FSR). The passive FSR system can exploit the peculiar advantage of the enhancement in forward scatter radar cross section (FSRCS) for target detection. Thus, the aim of this paper is to show the feasibility of passive FSR for moving target detection and classification by experimental analysis and results. The signal source is coming from the latest technology of 4G Long-Term Evolution (LTE) base station. A detailed explanation on the passive FSR receiver circuit, the detection scheme and the classification algorithm are given. In addition, the proposed passive FSR circuit employs the self-mixing technique at the receiver; hence the synchronization signal from the transmitter is not required. The experimental results confirm the passive FSR system’s capability for ground target detection and classification. Furthermore, this paper illustrates the first classification result in the passive FSR system. The great potential in the passive FSR system provides a new research area in passive radar that can be used for diverse remote monitoring applications. Full article
