Many kinds of panel structures are proposed in aircraft design. This study presents a topology optimization method to improve the buckling resistance of panel structures. It should be noted that a popular configuration of the present panel structure is that with ribs and frames. Stiffening characteristics (i.e., effects of increasing structural stiffness of a panel structure with ribs and frames) are thus included during analysis of panel structures. After studying the coupling relationship between the dynamic characteristics and buckling behavior of the panel, a developed MMC (moving morphable component) method is proposed for topology optimization to improve the buckling resistance of the panel. It is seen that the coupling relationship between the dynamic characteristics and buckling behavior of the panel is mainly reflected when the compression force acts on the panel, corresponding that dynamic characteristics will vary with the load. If the load acts on the structure, the first-order natural frequency of the panel with ribs and frames in this study decreases with the increase in the load, with the optimization objective of maximizing the first-order natural frequency. Based on the coupling relationship between dynamic characteristics and buckling behavior, the critical buckling load of the panel increases as the first-order natural frequency increases. The present optimization method can reduce computational complexity without changing the accuracy of the calculation. At the same time, the coupling relationship between dynamic characteristics and buckling behavior is applied in topology optimization, which is of great significance to improve the comprehensive performance of panel structures in the engineering design process. This paper improves the dynamic characteristics and buckling resistance of panels with ribs and frames based on the improved MMC method. The proposed method effectively meets the design requirements of flight vehicle design in complex environments. Full article

To enhance the mechanics and self-healing properties of the self-healing composite, this study introduces an innovative optimization method for variable-angle fiber-reinforced self-healing composites with microtubule network carriers. The study aims to minimize macroscopic structural compliance and carrier head loss. Firstly, a topological description function (TDF) for the self-healing composite was introduced, taking into account the configuration and geometry of the macroscopic structure and microtubule network carrier as design variables. Secondly, the relationship between the fiber laying angle and component spindle direction was established. An element stiffness matrix for variable-angle fibers was derived to determine the compliance of the self-healing composite. Then, the microtubule network head loss was calculated based on the Hardy Cross method. Finally, by integrating the Moving Morphable Component (MMC) method and the enumeration method, a dual-scale collaborative optimization framework was developed. The set of double-objective Pareto non-inferior solutions of the self-healing composite was obtained by iteration. Numerical examples show that (1) under the same optimization conditions, the non-inferior solution set of variable-angle fiber design is superior to those of fixed-angle fiber designs (0°, 45°, and 90°). (2) Compared with single-objective (compliance) optimization of the carrier-free composite, the Pareto solution set of the variable-angle dual-scale collaborative optimization can provide a better compliance optimization solution, and the maximum compliance solution of the solution set is only 10.64% higher. This paper proposes a method combining variable-angle and dual-scale collaborative optimization, which provides a useful reference for the topology design of a self-healing composite. Full article

Porous hierarchical structures are extensively utilized in engineering for their high specific strength, enhanced corrosion resistance, and multifunctionality. Over the past two decades, multiscale topology optimization for these structures has garnered significant attention. This paper introduces a novel hybrid MMCs (Moving Morphable Components)–density topology optimization method for quasi-periodic cellular structures. The term ‘quasi-periodic’ refers to microstructures whose different macroscopic points exhibit similar topologies with varying parameters. The primary concept involves using the MMC method to describe microstructural topology, while employing variable density to depict macro layouts. This approach leverages the advantage of MMCs in explicitly describing structural topology alongside the variable density of arbitrary microstructures. Sensitivity analyses of the optimization functions concerning design variables are shown, and a gradient optimization solver is employed to solve the optimization model. The examples effectively show the efficacy of the proposed method, illustrating that quasi-periodic cellular structures outperform single-scale solid structures. Full article

Hypersonic vehicles or engines usually employ complex thermal protecting shells. This sometimes brings multi-physics difficulties, e.g., thermal-aeroelastic problems like panel flutter etc. This paper aims to propose a novel optimization method versus thermal dynamic influence on panel vibration. A traditional panel structure was modelled and analyzed. After analyzing its dynamic characteristics of panel flutter, thermal effects were also included to propose thermal-aeroelastic analysis results of the present hypersonic panel. Then, a MMC (Moving Morphable Component) method was proposed to suggest dynamic optimization for such panel structures. The proposed method can provide arbitrary frequency control result in order to suggest a newly generated panel structure. Based on the optimal structures, dynamic analysis was presented again to verify the effectiveness of the optimization method. So aero-thermo-dynamic characteristics of the optimal panel structures could be investigated. It can be seen that the computational results presented significantly improved panel flutter results. The proposed dynamic optimization method can be employed for the design of panel structures versus high combustion temperatures or hypersonic aerodynamics. Full article

Topology optimization holds great potential to achieve the best performance for various fluid-related applications like aircraft components and microfluidic mixers. This paper reviews comprehensively the technical progress of this field over the last decade from the viewpoint of structural expression. The density-based approach has been widely adopted to design structures due to its simple concept, ease of implementation, and robustness. Different designs using such a pointwise method for systems under Stokes, laminar Navier–Stokes, turbulent, non-Newtonian, and steady-state/unsteady-state fluid flows are reviewed and discussed in depth. Both isogeometric analysis and the moving morphable components/voids methods will demonstrate their advantages regarding integration with computer-aided design. The moving morphable components/voids method also significantly reduces computing costs. From the viewpoint of boundary smoothness, we are most concerned about whether smoother boundaries can reduce objective functions such as energy dissipation even lower. Therefore, this work also concentrates on level set and spline expression methods. Furthermore, we identify isogeometric analysis and machine learning in shaping the field’s future. In addition, the review highlights the following two challenges: achieving accurate fluid model construction and the relatively limited experimental validation of fluid topology optimization outcomes. Full article
