Enhancing thermal efficiency and minimizing weight are prevailing issues in aero engines. Owing to its hollow structure, the twin-web turbine disc exhibits remarkable weight reduction properties, while its enhanced cooling constitutes a novel challenge. In this study, a twin-web turbine disc cavity system is numerically investigated. To enhance the cooling effect and minimize pressure loss, a multi-objective genetic algorithm and Kriging surrogate model are employed to optimize the radial height of the pre-swirl nozzle and receiver hole in the disc cavity system. The results indicate that the overall performance of Opt-3, derived from the Technique for Order Preference by Similarity to the Ideal Solution method within the Pareto frontier, is superior. This configuration achieves a uniform low distribution of rotor temperatures while maintaining moderate pressure losses. Notably, the maximum temperature is reduced by 21.1 K compared to the basic model, with pressure losses remaining largely unchanged. Additionally, an increase in the flow ratio leads to a reduction in both the maximum temperature and average temperature of the back web while simultaneously increasing the temperature of the front web and augmenting pressure losses. However, it is important to note that the degree of variation in these parameters diminishes with increasing flow ratios. Full article

The article concerns the possibility of the automation and robotization of the process of deburring jet engine components. The paper presents the construction of a laboratory stand enabling the automation of selected production operations of typical low-pressure turbine blades. The work identifies important parameters and results of the technological process related to the removal of burrs that affect the exactness of the process. The results of the analysis of the impact of individual process parameters on the magnitude of forces and moments occurring during deburring were carried out and presented. The results of initial and detailed tests were presented. Based on the results obtained, it was noticed that doubling the rotational speed of the brush results in a linear increase in torque and an increase in the engagement of the detail in the disc brush, leading to a non-linear increase in torque. It has also been shown that with tool wear, the value of the torque generated by the rotating tool decreases. Based on the results of a comparison of manual and automated process and histogram analysis, results from an automated stand are centered more correctly inside of the required radius range. This means that the repeatability of the process is higher for an automated test stand, which is one of the key aspects of large-scale aviation component manufacturing. Additionally, it was confirmed by visual inspection that all burs had been removed correctly—the deburring operation for all tested work pieces was successful. Based on the results obtained, it was proven that introduction of an automated stand can improve working conditions (by the elimination of the progressive fatigue of employees and the possibility for injury) and allows for the elimination of the negative impact of the machining process on workers. Further areas in which the optimization of the process parameters of the edge deburring can be developed in order to reduce unit costs have also been indicated. Full article

In combined cycle power plants (CCPPs), the bypass butterfly valve is a key component to facilitate regulation of exhaust gas energy available at the turbine and to not produce too much boost pressure. The conventional damper valve causes leakage, back flow into the turbine, and damage of the blade, and the existing dual-layered seal with polytetrafluoroethylene (PTFE) and metal should be frequently replaced owing to its low durability and deterioration of mechanical properties under a high temperature. This study devised a triple offset butterfly valve with a new type of seal by alternatively laminating stainless steel and graphite to improve valve performance at the high temperature (350 °C). The slope angles of the seal contact surface to prevent friction were calculated using the mathematical models of the triple offset. Thermal-structure coupled analyses by varying the number of graphite and thickness were conducted, and the seven-layer model with the graphite thickness of 0.8 mm, which shows airtightness and smooth operation, was chosen. The contact stresses behaviors of the graphite at 350 °C and at −196 °C were investigated, and it was found that the graphite is in charge of improving driving performance of the disc at the high temperature and sealing performance at the cryogenic temperature. The performance tests and the field tests of the suggested model verified its performance at the working temperature. Full article

Manufacturing more efficient low pressure turbines has become a topic of primary importance for aerospace companies. Specifically, wire electrical discharge machining of disc turbine fir-tree slots has attracted increasing interest in recent years. However, important issues must be still addressed for optimum application of the WEDM process for fir-tree slot production. The current work presents a novel approach for tolerance monitoring based on unsupervised machine learning methods using distribution of ionization time as a variable. The need for time-consuming experiments to set-up threshold values of the monitoring signal is avoided by using K-means and hierarchical clustering. The developments have been tested in the WEDM of a generic fir-tree slot under industrial conditions. Results show that 100% of the zones classified into Clusters 1 and 2 are related to short-circuit situations. Further, 100% of the zones classified in Clusters 3 and 5 lie within the tolerance band of ±15 μm. Finally, the 9 regions classified in Cluster 4 correspond to situations in which the wire is moving too far away from the part surface. These results are strongly in accord with tolerance distribution as measured by a coordinate measuring machine. Full article

Stress corrosion cracks (SCC) in low-pressure steam turbine discs are serious hidden dangers to production safety in the power plants, and knowing the orientation and depth of the initial cracks is essential for the evaluation of the crack growth rate, propagation direction and working life of the turbine disc. In this paper, a method based on phased array ultrasonic transducer and artificial neural network (ANN), is proposed to estimate both the depth and orientation of initial cracks in the turbine discs. Echo signals from cracks with different depths and orientations were collected by a phased array ultrasonic transducer, and the feature vectors were extracted by wavelet packet, fractal technology and peak amplitude methods. The radial basis function (RBF) neural network was investigated and used in this application. The final results demonstrated that the method presented was efficient in crack estimation tasks. Full article
