Research on Signal Feature Extraction of Natural Gas Pipeline Ball Valve Based on the NWTD-WP Algorithm

by Lingxia Yang, Shuxun Li, Zhihui Wang, Jianjun Hou and Xuedong Zhang

Sensors 2023, 23(10), 4790; https://doi.org/10.3390/s23104790 - 16 May 2023

Cited by 4 | Viewed by 1563

The measured signals of internal leakage detection of the large-diameter pipeline ball valve in natural gas pipeline systems usually contain background noise, which will affect the accuracy of internal leakage detection and sound localization of internal leakage points due to the interference of noise. Aiming at this problem, this paper proposes an NWTD-WP feature extraction algorithm by combining the wavelet packet (WP) algorithm and the improved two-parameter threshold quantization function. The results show that the WP algorithm has a good feature extraction effect on the valve leakage signal, and the improved threshold quantization function can avoid the defects of the traditional soft threshold function and hard threshold function, such as discontinuity and the pseudo-Gibbs phenomenon, when reconstructing the signal. The NWTD-WP algorithm is effective in extracting the features of the measured signals with low signal/noise ratio. The denoise effect is much better than that of the traditional soft and hard threshold quantization functions. It proved that the NWTD-WP algorithm can be used for studying the existing safety valve leakage vibration signals in the laboratory and the internal leakage signals of the scaled-down model of the large-diameter pipeline’s ball valve. Full article

(This article belongs to the Section Industrial Sensors)

► Show Figures

Figure 1

19 pages, 15998 KiB

Open AccessArticle

Investigation of the Fluid Flow in a Large Ball Valve Designed for Natural Gas Pipelines

by Laurențiu-Ioan Ivancu and Daniela Popescu

Appl. Sci. 2023, 13(7), 4247; https://doi.org/10.3390/app13074247 - 27 Mar 2023

Cited by 5 | Viewed by 4258

Abstract

Natural gas pipeline networks used for long-distance transportation are expanding quickly, and the construction of special valves with large diameters has especially increased since 2022. The design and manufacturing of the flow control equipment is carried out on a case-by-case basis, in accordance with the parameters required by the beneficiary. In this paper, results obtained by fluid flow simulation with SolidWorks2023 software for a 500 mm diameter trunnion ball valve lead to important information regarding how the fluid flow develops in the intermediary and fully closed positions. The large inner space of the ball allows the development of high-amplitude vortices; thus, the simulation demonstrates that the shut-on/off operation of large-diameter ball valves is mandatory to avoid fast destruction following partial opening. This paper also demonstrates why the metal–metal (MM) sealing with a double-piston effect (DPE) design for seats produces low leakage rates, including for the shut-off position; the pressure field reveals that few gas particles succeed in crossing the upstream sealing zone, and even fewer cross the downstream sealing zone. Additionally, the interpretation of the results explains and highlights the importance of using seats with a DPE design to achieve fire safety, which is required for natural gas pipeline applications. Full article

(This article belongs to the Topic Computational Fluid Dynamics (CFD) and Its Applications)

► Show Figures

Figure 1
