The meridional distribution of the flow parameters inside the centrifugal compressor is of great importance to its overall performance, as well as its matching performance under a thermal cycle. A time-marching throughflow method for the off-design performance analysis of the centrifugal compressor is described. The method is based on the strictly conservative throughflow-governing equations, and an improved method of boundary-condition enforcement is developed based on Newton’s method to achieve a robust and fast throughflow simulation. An inviscid blade force model was adopted to obtain the flow deflection inside the blade passage. Empirical loss models were integrated into the throughflow model to simulate the viscous force effects in the real three-dimensional flow. Two test cases are presented to validate the throughflow method by comparisons with the experimental data or CFD results, including the NASA low-speed centrifugal compressor (LSCC) and the Allison high-performance centrifugal compressor (HPCC). The simulation indicated that the developed enforcement method for the inlet and outlet boundary conditions significantly improves the computational robustness. For both the LSCC and HPCC cases, reasonable flow-parameter distribution was obtained and accurate overall characteristics were also predicted under the off-design conditions. The results indicated that the developed time-marching throughflow method is effective and efficient for the performance analysis of centrifugal compressors. Full article

Gas turbine engines are highly intricate machines, and every component of them is closely associated with one another. In the traditional engine developing process, vast experiment tests are needed. To reduce unnecessary trials, a whole gas turbine engine simulation is extremely needed. For this purpose, a compressor simulation tool is now developed. Considering the inherent drawbacks of 0D analysis and 3D CFD (Computational Fluid Dynamics) calculation, the 2D throughflow method is an indispensable tool. Based on the circumferential average method (CAM), 3D Navier–Stokes is transformed into a 2D method. One phenomenon arising is that the lack of description about circumferential motion leads to the need for the blade force modeling in compressor simulation. Previous models are based on the assumption that flow passes through the average stream surface without entropy increasing, which is not applicable in the CAM. An improved model is proposed based on the result analysis from CAM and NUMECA method in a linear cascade. Whereafter, the model is applied in a highly loaded and low-speed fan, which has been tested for its performance characteristics. Utilizing the new model, the error of the adiabatic efficiency between CAM and experiment decreases from 4.0% to 1.0% and the accuracy of the mass flow, and pressure ratio remains unchanged. The time involved in the CAM simulation is nearly 70 times faster than that of the 3D simulation. Full article

In the present work, a comparison between the results obtained by a panel code with a Reynolds-averaged Navier-Stokes (RANS) code is made to obtain a better insight on the viscous effects of the ducted propeller and on the limitations of the inviscid flow model, especially near bollard pull conditions or low advance ratios, which are important in the design stage. The analysis is carried out for propeller Ka4-70 operating inside duct 19A. From the comparison, several modelling aspects are studied for improvement of the inviscid (potential) flow solution. Finally, the experimental open-water data is compared with the panel method and RANS solutions. A strong influence of the blade wake pitch, especially near the blade tip, on the ducted propeller force predictions is seen. A reduction of the pitch of the gap strip is proposed for improvement of the performance prediction at low advance ratios. Full article
