Search Results (3)

Search Parameters:
Keywords = interlocking microdome

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
13 pages, 3933 KiB
Article
Microdome-Tunable Graphene/Carbon Nanotubes Pressure Sensors Based on Polystyrene Array for Wearable Electronics
by Xingjie Su, Chunli Luo, Weiguo Yan, Junyi Jiao and Dongzhou Zhong
Materials 2021, 14(23), 7385; https://doi.org/10.3390/ma14237385 - 2 Dec 2021
Cited by 20 | Viewed by 3231
Abstract
Resistive pressure sensors are appealing due to having several advantages, such as simple reading mechanisms, simple construction, and quick dynamic response. Achieving a constantly changeable microstructure of sensing materials is critical for the flexible pressure sensor and remains a difficulty. Herein, a flexible, [...] Read more.
Resistive pressure sensors are appealing due to having several advantages, such as simple reading mechanisms, simple construction, and quick dynamic response. Achieving a constantly changeable microstructure of sensing materials is critical for the flexible pressure sensor and remains a difficulty. Herein, a flexible, tunable resistive pressure sensors is developed via simple, low-cost microsphere self-assembly and graphene/carbon nanotubes (CNTs) solution drop coating. The sensor uses polystyrene (PS) microspheres to construct an interlocked dome microstructure with graphene/CNTs as a conductive filler. The results indicate that the interlocked microdome-type pressure sensor has better sensitivity than the single microdome-type and single planar-type without surface microstructure. The pressure sensor’s sensitivity can be adjusted by varying the diameter of PS microspheres. In addition, the resistance of the sensor is also tunable by adjusting the number of graphene/CNT conductive coating layers. The developed flexible pressure sensor effectively detected human finger bending, demonstrating tremendous potential in human motion monitoring. Full article
Show Figures

Figure 1

11 pages, 5111 KiB
Article
A Triple-Mode Flexible E-Skin Sensor Interface for Multi-Purpose Wearable Applications
by Sung-Woo Kim, Youngoh Lee, Jonghwa Park, Seungmok Kim, Heeyoung Chae, Hyunhyub Ko and Jae Joon Kim
Sensors 2018, 18(1), 78; https://doi.org/10.3390/s18010078 - 29 Dec 2017
Cited by 33 | Viewed by 15539
Abstract
This study presents a flexible wireless electronic skin (e-skin) sensor system that includes a multi-functional sensor device, a triple-mode reconfigurable readout integrated circuit (ROIC), and a mobile monitoring interface. The e-skin device’s multi-functionality is achieved by an interlocked micro-dome array structure that uses [...] Read more.
This study presents a flexible wireless electronic skin (e-skin) sensor system that includes a multi-functional sensor device, a triple-mode reconfigurable readout integrated circuit (ROIC), and a mobile monitoring interface. The e-skin device’s multi-functionality is achieved by an interlocked micro-dome array structure that uses a polyvinylidene fluoride and reduced graphene oxide (PVDF/RGO) composite material that is inspired by the structure and functions of the human fingertip. For multi-functional implementation, the proposed triple-mode ROIC is reconfigured to support piezoelectric, piezoresistance, and pyroelectric interfaces through single-type e-skin sensor devices. A flexible system prototype was developed and experimentally verified to provide various wireless wearable sensing functions—including pulse wave, voice, chewing/swallowing, breathing, knee movements, and temperature—while their real-time sensed data are displayed on a smartphone. Full article
(This article belongs to the Section Physical Sensors)
Show Figures

Graphical abstract

11 pages, 460 KiB
Article
Piezoresistive Tactile Sensor Discriminating Multidirectional Forces
by Youngdo Jung, Duck-Gyu Lee, Jonghwa Park, Hyunhyub Ko and Hyuneui Lim
Sensors 2015, 15(10), 25463-25473; https://doi.org/10.3390/s151025463 - 2 Oct 2015
Cited by 76 | Viewed by 12042
Abstract
Flexible tactile sensors capable of detecting the magnitude and direction of the applied force together are of great interest for application in human-interactive robots, prosthetics, and bionic arms/feet. Human skin contains excellent tactile sensing elements, mechanoreceptors, which detect their assigned tactile stimuli and [...] Read more.
Flexible tactile sensors capable of detecting the magnitude and direction of the applied force together are of great interest for application in human-interactive robots, prosthetics, and bionic arms/feet. Human skin contains excellent tactile sensing elements, mechanoreceptors, which detect their assigned tactile stimuli and transduce them into electrical signals. The transduced signals are transmitted through separated nerve fibers to the central nerve system without complicated signal processing. Inspired by the function and organization of human skin, we present a piezoresistive type tactile sensor capable of discriminating the direction and magnitude of stimulations without further signal processing. Our tactile sensor is based on a flexible core and four sidewall structures of elastomer, where highly sensitive interlocking piezoresistive type sensing elements are embedded. We demonstrate the discriminating normal pressure and shear force simultaneously without interference between the applied forces. The developed sensor can detect down to 128 Pa in normal pressure and 0.08 N in shear force, respectively. The developed sensor can be applied in the prosthetic arms requiring the restoration of tactile sensation to discriminate the feeling of normal and shear force like human skin. Full article
(This article belongs to the Section Physical Sensors)
Show Figures

Graphical abstract
