This paper suggests a perspective-controlled solution for an integrated Infrared micro-/nanoplastic spectroscopy/photometry-based detection, from the diffraction up to the geometry etendue, with the aim of yielding a universal spectrometer/photometer. Spectrophotometry, unlike spectroscopy that shows the interaction between matter and radiated energy, is a specific form of photometry that measures light parameters in a particular range as a function of wavelength. The solution, meant for diffraction grating and geometry etendue of the display unit, is provided by a controller that tunes the grating pitch to accommodate any emitted/transmitted wavelength from a sample made of microplastics, their degraded forms and their potential retention, and ensures that all the diffracted wavelengths are concentrated on the required etendue. The purpose is not only to go below the current Infrared limit of $20\mathsf{\mu }\mathrm{m}$ microplastic size, or to suggest an Infrared spectrophotometry geometry capable of detecting micro- and nanoplastics in the range of ($1\mathrm{nm}$–$20\mathsf{\mu }\mathrm{m}$) for integrated nano- and micro-scales, but also to transform most of the pivotal components to be directly wavelength-independent. The related controlled geometry solutions, from the controlled grating slit-width up to the controlled display unit etendue functions, are suggested for a wider generic range integration. The results from image-size characterization show that the following charge-coupled devices, nanopixel CCDs, and/or micropixel CCDs of less than $100\mathrm{nm}$ are required on the display unit, justifying the Infrared micro- and nanoplastic-integrated spectrophotometry, and the investigation conducted with other electromagnetic spectrum ranges that suggests a possible universal spectrometer/photometer. Full article

Visible Light Communication (VLC) is an important emerging choice for high-speed wireless communication. In this perspective, light-emitting diodes as illuminators will be modulated to transmit data simultaneously. However, the receivers bring severe difficulties due to cost, response time, and sensitivity with a wide Field Of View (FOV). To avoid these problems, one approach is to apply a large area photodetector; however, this solution is slow and costly. Another method is to focus light on a fast photodetector by optical components, but the photodetector’s FOV decreases, resulting from the conservation of etendue. Another option is Luminescent Solar Concentrators (LSCs). This paper demonstrates a novel shape of LSC with advantages such as inexpensive, fast response time, small antenna area for VLC purposes with significant geometrical gain, FOV, and ultra-broad bandwidth. It does not require any complex tracking system and active pointing but, due to its tiny size, it can also be adapted in integrating and mobile devices. Numerical simulation is done using Monte-Carlo raytracing, and the results are demonstrated in the spectral domain. The optical efficiency of the proposed antenna is obtained at 1.058%, which is about 0.4% better than the efficiency levels reported in other works, and the geometric gain of the antenna is reported to be 44, which is significant. Full article

We demonstrate a laser beam combiner based on four photo-patterned Pancharatnam–Berry (PB) phase gratings, which is compact and has high diffraction efficiency for incident circularly polarized light. The nematic liquid crystal mixture E7 is used as anisotropic material, and the thickness of the layer is controlled by spacers. The beam combiner can bring two parallel laser beams closer to each other while remaining parallel. This work shows the potential to realize components based on flat optical LC devices. Full article
