Forest structural parameters are key indicators for forest growth assessment, and play a critical role in forest resources monitoring and ecosystem management. Terrestrial laser scanning (TLS) can obtain three-dimensional (3D) forest structures with ultra-high precision without destruction, whereas some shortcomings such as non-portability and cost-consuming can limit the quick and broad acquisition of forest structure. Structure from motion (SfM) and backpack laser scanning (BLS) technology have the advantages of low-cost and high-portability while obtaining 3D structure information of forests. In this study, the high-overlapped images and the BLS point cloud, combined with the point cloud registration and individual tree segmentation to extract the forest structural parameters and compared with the TLS for assessing the accuracy and efficiency of low-cost SfM and portable BLS point clouds. Three plots with different forest structural complexity (coniferous, broadleaf and mixed plot) in the northern subtropical forests were selected. Firstly, portable photography camera, BLS and TLS were used to acquire 3D SfM and LiDAR point clouds, and spatial co-registration of different-sourced point cloud datasets were carried out based on the understory markers. Secondly, the point clouds of individual tree trunk and crown were segmented by the comparative shortest-path algorithm (CSP), and then the height and position of individual tree were extracted based on the tree crown point cloud. Thirdly, the trunk diameter at different heights were calculated by point cloud slices using the density-based spatial clustering of applications with noise (DBSCAN) algorithm, and combined with the stem curve of individual tree which was constructed using four Taper equations to estimate the individual tree volume. Finally, the extraction accuracy of forest structural parameters based on SfM and BLS point clouds were verified and comprehensively compared with field-measured and TLS data. The results showed that: (1) the individual tree segmentation based on SfM and BLS point clouds all performed quite well, among which the segmentation accuracy (F) of SfM point cloud was 0.80 and the BLS point cloud was 0.85; and (2) the accuracy of DBH and tree height extraction based on the SfM and BLS point clouds in comparison with the field-measured data were relatively high. The root mean square error (RMSE) of DBH and tree height extraction based on SfM point cloud were 2.15 cm and 4.08 m, and the RMSE of DBH and tree height extraction based on BLS point cloud were 2.06 cm and 1.63 m. This study shows that with the adopted image capture method, terrestrial SfM photogrammetry can be applied quite well in extracting DBH. Full article

Long-term and high-intensity coal mining has led to the increasingly serious surface subsidence and environmental problems. Surface subsidence monitoring plays an important role in protecting the ecological environment of the mining area and the sustainable development of modern coal mines. The development of surveying technology has promoted the acquisition of high-resolution terrain data. The combination of an unmanned aerial vehicle (UAV) point cloud and the structure from motion (SfM) method has shown the potential of collecting multi-temporal high-resolution terrain data in complex or inaccessible environments. The difference of the DEM (DoD) is the main method to obtain the surface subsidence in mining areas. However, the obtained digital elevation model (DEM) needs to interpolate the point cloud into the grid, and this process may introduce errors in complex natural topographic environments. Therefore, a complete three-dimensional change analysis is required to quantify the surface change in complex natural terrain. In this study, we propose a quantitative analysis method of ground subsidence based on three-dimensional point cloud. Firstly, the Monte Carlo simulation statistical analysis was adopted to indirectly evaluate the performance of direct georeferencing photogrammetric products. After that, the operation of co-registration was carried out to register the multi-temporal UAV dense matching point cloud. Finally, the model-to-model cloud comparison (M3C2) algorithm was used to quantify the surface change and reveal the spatio-temporal characteristics of surface subsidence. In order to evaluate the proposed method, four periods of multi-temporal UAV photogrammetric data and a period of airborne LiDAR point cloud data were collected in the Yangquan mining area, China, from 2020 to 2022. The 3D precision map of a sparse point cloud generated by Monte Carlo simulation shows that the average precision in X, Y and Z directions is 44.80 mm, 45.22 and 63.60 mm, respectively. The standard deviation range of the M3C2 distance calculated by multi-temporal data in the stable area is 0.13–0.19, indicating the consistency of multi-temporal photogrammetric data of UAV. Compared with DoD, the dynamic moving basin obtained by the M3C2 algorithm based on the 3D point cloud obtained more real surface deformation distribution. This method has high potential in monitoring terrain change in remote areas, and can provide a reference for monitoring similar objects such as landslides. Full article

Grasslands and shrublands exhibit pronounced spatial and temporal variability in structure and function with differences in phenology that can be difficult to observe. Unpiloted aerial vehicles (UAVs) can measure vegetation spectral patterns relatively cheaply and repeatably at fine spatial resolution. We tested the ability of UAVs to measure phenological variability within vegetation functional groups and to improve classification accuracy at two sites in Montana, U.S.A. We tested four flight frequencies during the growing season. Classification accuracy based on reference data increased by 5–10% between a single flight and scenarios including all conducted flights. Accuracy increased from 50.6% to 61.4% at the drier site, while at the more mesic/densely vegetated site, we found an increase of 59.0% to 64.4% between a single and multiple flights over the growing season. Peak green-up varied by 2–4 weeks within the scenes, and sparse vegetation classes had only a short detectable window of active phtosynthesis; therefore, a single flight could not capture all vegetation that was active across the growing season. The multi-temporal analyses identified differences in the seasonal timing of green-up and senescence within herbaceous and sagebrush classes. Multiple UAV measurements can identify the fine-scale phenological variability in complex mixed grass/shrub vegetation. Full article

Acquired imagery by unmanned aerial vehicles (UAVs) has been widely used for three-dimensional (3D) reconstruction/modeling in various digital agriculture applications, such as phenotyping, crop monitoring, and yield prediction. 3D reconstruction from well-textured UAV-based images has matured and the user community has access to several commercial and opensource tools that provide accurate products at a high level of automation. However, in some applications, such as digital agriculture, due to repetitive image patterns, these approaches are not always able to produce reliable/complete products. The main limitation of these techniques is their inability to establish a sufficient number of correctly matched features among overlapping images, causing incomplete and/or inaccurate 3D reconstruction. This paper provides two structure from motion (SfM) strategies, which use trajectory information provided by an onboard survey-grade global navigation satellite system/inertial navigation system (GNSS/INS) and system calibration parameters. The main difference between the proposed strategies is that the first one—denoted as partially GNSS/INS-assisted SfM—implements the four stages of an automated triangulation procedure, namely, imaging matching, relative orientation parameters (ROPs) estimation, exterior orientation parameters (EOPs) recovery, and bundle adjustment (BA). The second strategy— denoted as fully GNSS/INS-assisted SfM—removes the EOPs estimation step while introducing a random sample consensus (RANSAC)-based strategy for removing matching outliers before the BA stage. Both strategies modify the image matching by restricting the search space for conjugate points. They also implement a linear procedure for ROPs’ refinement. Finally, they use the GNSS/INS information in modified collinearity equations for a simpler BA procedure that could be used for refining system calibration parameters. Eight datasets over six agricultural fields are used to evaluate the performance of the developed strategies. In comparison with a traditional SfM framework and Pix4D Mapper Pro, the proposed strategies are able to generate denser and more accurate 3D point clouds as well as orthophotos without any gaps. Full article

Rapid developments in the field of underwater photogrammetry have given scientists the ability to produce accurate 3-dimensional (3D) models which are now increasingly used in the representation and study of local areas of interest. This paper addresses the lack of systematic analysis of 3D reconstruction and navigation fusion strategies, as well as associated error evaluation of models produced at larger scales in GPS-denied environments using a monocular camera (often in deep sea scenarios). Based on our prior work on automatic scale estimation of Structure from Motion (SfM)-based 3D models using laser scalers, an automatic scale accuracy framework is presented. The confidence level for each of the scale error estimates is independently assessed through the propagation of the uncertainties associated with image features and laser spot detections using a Monte Carlo simulation. The number of iterations used in the simulation was validated through the analysis of the final estimate behavior. To facilitate the detection and uncertainty estimation of even greatly attenuated laser beams, an automatic laser spot detection method was developed, with the main novelty of estimating the uncertainties based on the recovered characteristic shapes of laser spots with radially decreasing intensities. The effects of four different reconstruction strategies resulting from the combinations of Incremental/Global SfM, and the a priori and a posteriori use of navigation data were analyzed using two distinct survey scenarios captured during the SUBSAINTES 2017 cruise (doi: 10.17600/17001000). The study demonstrates that surveys with multiple overlaps of nonsequential images result in a nearly identical solution regardless of the strategy (SfM or navigation fusion), while surveys with weakly connected sequentially acquired images are prone to produce broad-scale deformation (doming effect) when navigation is not included in the optimization. Thus the scenarios with complex survey patterns substantially benefit from using multiobjective BA navigation fusion. The errors in models, produced by the most appropriate strategy, were estimated at around $1\%$ in the central parts and always inferior to $5\%$ on the extremities. The effects of combining data from multiple surveys were also evaluated. The introduction of additional vectors in the optimization of multisurvey problems successfully accounted for offset changes present in the underwater USBL-based navigation data, and thus minimize the effect of contradicting navigation priors. Our results also illustrate the importance of collecting a multitude of evaluation data at different locations and moments during the survey. Full article

Three-dimensional (3D) reconstruction of a tree canopy is an important step in order to measure canopy geometry, such as height, width, volume, and leaf cover area. In this research, binocular stereo vision was used to recover the 3D information of the canopy. Multiple images were taken from different views around the target. The Structure-from-motion (SfM) method was employed to recover the camera calibration matrix for each image, and the corresponding 3D coordinates of the feature points were calculated and used to recover the camera calibration matrix. Through this method, a sparse projective reconstruction of the target was realized. Subsequently, a ball pivoting algorithm was used to do surface modeling to realize dense reconstruction. Finally, this dense reconstruction was transformed to metric reconstruction through ground truth points which were obtained from camera calibration of binocular stereo cameras. Four experiments were completed, one for a known geometric box, and the other three were: a croton plant with big leaves and salient features, a jalapeno pepper plant with median leaves, and a lemon tree with small leaves. A whole-view reconstruction of each target was realized. The comparison of the reconstructed box’s size with the real box’s size shows that the 3D reconstruction is in metric reconstruction. Full article
