Mode division multiplexing (MDM) techniques provide significant enhancement of the capacity of optical intensity modulation and direct detection (IM/DD) short-reach communication systems, like the datacenter interconnection scenarios. While the introduction of multiple modes leads to mode coupling that will extremely deteriorate the received signals, two approaches have been explored to address this issue: one involves the application of all-link weakly coupled components to suppress modal crosstalk, while the other utilizes optical multiple-input–multiple-output (MIMO) equalizers based on optical devices for signal decoupling. However, pure digital signal processing (DSP)-based schemes for mode decoupling in IM/DD MDM systems with strong mode coupling remain unexplored. In this paper, we propose to use a frequency-domain MIMO equalizer for compensating the modal interference in the strong-coupling linear-polarized (LP) MDM IM/DD system. The signal recovery capability of the proposed method is verified through numerical simulation. Finally, we successfully experimentally demonstrate the transmission of on–off-key (OOK) signals in a six-LP-mode strong-coupling MDM IM/DD system over a 10 km few-mode fiber, employing a pair of strong-coupling mode multiplexers/demultiplexers. The experimental results indicate that, with the frequency-domain MIMO equalizer, OOK signals from all modes can be recovered with an 11% hard-decision forward error correction threshold of 8.3 × ${10}^{-3}$. The proposed method facilitated by flexible DSP software offers an alternative for short-reach communication systems and has the potential to advance the practical application of MDM techniques in the future. Full article

We propose a design method for few-mode erbium-doped fiber (FM-EDF) incorporating stratified doping. In the simulation design, the FM-EDF effectively reduces the differential mode gain (DMG) through the utilization of stratified doping. Simulations indicate that at an input signal power of −30 dBm, the designed fiber achieves a DMG of less than 0.5 dB across five spatial modes spanning the entire C-band (1530–1570 nm) and exceeds 20 dB gain within the range of 1530–1560 nm. Additionally, experiments using unidirectional pumping demonstrate that the FM-EDF achieves full-band gain greater than 20 dB, with a maximum gain approaching 30 dB and DMG <1 dB, across the C-band in three spatial modes. In summary, the proposed FM-EDF enhances the efficiency and reliability of long-distance signal transmission in optical communication networks, making it suitable for high-capacity optical fiber communication systems as well as long-distance sensing systems. Full article

In this paper, the theoretical model of spontaneous Raman scattering (SpRS) in few-mode fiber (FMF) is discussed. The influence of SpRS on quantum key distribution (QKD) in FMF is evaluated by combining wavelength division multiplexing (WDM) and space division multiplexing (SDM) techniques. On this basis, an improved ring-assisted FMF is designed and characterized; the transmission distance can be increased by up to 54.5% when choosing different multi-channels. The effects of forward and backward SpRS on QKD are also discussed. Full article

High-order transverse-mode lasers have important potential application value in many fields. To address the current issue of the limited controllability of modes in high-order transverse-mode lasers, we have designed a self-matching photonic lantern (SMPL). The SMPL is formed by introducing a few-mode fiber into the input fiber array of the traditional photonic lantern. The parameters of the few-mode fiber match those of the tapered few-mode port of the SMPL; thus, it can transmit high-order modes in a closed loop. The designed SMPL exhibits dual-band multiplexing characteristics at 980/1550 nm, manifesting specifically as high-order mode selectivity excitation at 980 nm and mode preservation at 1550 nm. These characteristics have been validated through simulation and preliminary experiments. The SMPL is designed for constructing all few-mode fiber ring cavity lasers, enabling the pumping of the 980 nm fundamental mode to high-order modes and the transmission of multiple high-order transverse-mode lasers at 1550 nm in a closed loop. The proposed SMPL extends the configuration and functionality of the photonic lantern family, offering a flexible and effective approach to facilitate the generation of multiple high-order transverse-mode lasers. The SMPL combined with fiber laser systems could effectively broaden communication channels and enhance communication bandwidth. It also holds significant value in optical sensing, high-resolution imaging, laser micro-processing, and other fields. Full article

This paper provides an overview of latest progress on the novel advanced digital signal processing (DSP) techniques for long-haul mode division multiplexing (MDM) systems with high capacity. Space-division multiplexing (SDM) techniques have been developed for a period to increase the capacity of optical communication system by at least one order of magnitude through MDM techniques using few-mode fibers (FMFs) or multi-core multiplexing (MCM) using multi-core fibers (MCFs). The signals in MDM links are mainly impaired by the linear and nonlinear effects in FMFs, making DSP techniques become necessary to undo these impairments. In this paper, we not only review the advanced multiple-input multiple-output (MIMO) DSP techniques for compensating linear impairments in FMFs, but also enclose the state of the art of novel DSP techniques to deal with nonlinear effects. Firstly, we introduce the MIMO schemes for equalizing modal crosstalk and modal dispersion. Then, we focus on the fast tracking of time-varying (TV) channels in FMF links through frequency-domain (FD) recursive least square (RLS) algorithm. Besides, we also cover the mainstream DSP solutions for mode-dependent loss (MDL) and several possible methods to compensate nonlinearity in FMF. Moreover, artificial intelligence (AI) technologies are also discussed for its high nonlinearity tolerance and may bring a revolution in MDM systems on the process of channel equalization, link monitoring, etc. In the end, a brief conclusion and perspective will be provided. Full article

In this paper, we provide an overview of recent progress on advanced digital signal processing (DSP) techniques for high-capacity long-haul coherent optical fiber transmission systems. Not only the linear impairments existing in optical transmission links need to be compensated, but also, the nonlinear impairments require proper algorithms for mitigation because they become major limiting factors for long-haul large-capacity optical transmission systems. Besides the time domain equalization (TDE), the frequency domain equalization (FDE) DSP also provides a similar performance, with a much-reduced computational complexity. Advanced DSP also plays an important role for the realization of space division multiplexing (SDM). SDM techniques have been developed recently to enhance the system capacity by at least one order of magnitude. Some impressive results have been reported and have outperformed the nonlinear Shannon limit of the single-mode fiber (SMF). SDM introduces the space dimension to the optical fiber communication. The few-mode fiber (FMF) and multi-core fiber (MCF) have been manufactured for novel multiplexing techniques such as mode-division multiplexing (MDM) and multi-core multiplexing (MCM). Each mode or core can be considered as an independent degree of freedom, but unfortunately, signals will suffer serious coupling during the propagation. Multi-input–multi-output (MIMO) DSP can equalize the signal coupling and makes SDM transmission feasible. The machine learning (ML) technique has attracted worldwide attention and has been explored for advanced DSP. In this paper, we firstly introduce the principle and scheme of coherent detection to explain why the DSP techniques can compensate for transmission impairments. Then corresponding technologies related to the DSP, such as nonlinearity compensation, FDE, SDM and ML will be discussed. Relevant techniques will be analyzed, and representational results and experimental verifications will be demonstrated. In the end, a brief conclusion and perspective will be provided. Full article

The equalization enhanced phase noise (EEPN), caused by the interaction of the chromatic dispersion (CD) with the phase noise of the local oscillator (LO), has been extensively studied for single-mode optical communication systems. Few-mode fiber (FMF) transmission systems introduce a new channel impairment, the differential mode delay (DMD), which also creates EEPN and hence limits the maximum transmission distance of those systems. In this work, we numerically investigate the optical signal to noise ratio (OSNR) penalties caused by the EEPN in a 3-mode FMF transmission system at 25 GBd for quadrature phase-shift keying (QPSK), 16-quadrature amplitude modulation (QAM), 32-QAM and 64-QAM modulation formats when using the blind phase search (BPS) carrier phase recovery (CPR) algorithm, which has been demonstrated to be both robust and suitable for optical communication systems. Our numerical study assumes a short-span of FMF, modeled in the weakly-coupled regime, and includes two cases; the use of ideal mode-selective de/multiplexers at both ends of the FMF span (model A), and the use of ideal non-mode-selective de/multiplexers (model B). The results show that the EEPN has almost no effect in model A. However, EEPN produces a severe penalty in model B with the onset of the OSNR degradation starting for a DMD spread of the impulse response of about 100 symbols for all modulation formats investigated. The distribution ratio of the amount of phase noise between the transmitter and receiver lasers is also assessed for model B and we confirm that the degradation is mainly due to the phase noise of the LO. Full article
