Search Results (3)

Search Parameters:
Keywords = equivalent magnetic circuit model (EMCM)

Order results
Result details
Results per page
Show export options expand_more Show export options expand_less
Select all
Export citation of selected articles as:
33 pages, 12739 KiB
Article
An Equivalent Magnetic-Circuit-Modeling Approach for Analysis of Conical Permanent Magnet Synchronous Motor
by Fengrui Cui, Junquan Chen, Pengfei Hu, Xingyu Wu and Fangxu Sun
Sensors 2025, 25(6), 1788; https://doi.org/10.3390/s25061788 - 13 Mar 2025
Cited by 1 | Viewed by 623
Abstract
Shaftless propulsion technology delivers high efficiency and low noise for subsea installations and marine vessels. To enhance thrust performance, the streamlined aft-body contour imposes stringent demands on geometric compatibility between the rim-driven thruster (RDT) motor and hull. This necessitates advanced electromagnetic characterization of [...] Read more.
Shaftless propulsion technology delivers high efficiency and low noise for subsea installations and marine vessels. To enhance thrust performance, the streamlined aft-body contour imposes stringent demands on geometric compatibility between the rim-driven thruster (RDT) motor and hull. This necessitates advanced electromagnetic characterization of conical motors. This paper proposes an equivalent magnetic circuit model (EMCM) that accounts for end effects and magnetic saturation in both the stator and rotor cores for the magnetic field analysis of conical permanent magnet synchronous motor (CPMSM). A 3D EMCM is developed by decomposing the air-gap flux into radial/axial/tangential components. End-field nonlinearities are addressed via lumped-parameter network modeling. Innovatively, a trapezoidal expanded magnet layout and magnet-pole-trimming technology are adopted to ensure sinusoidal flux distribution. Finally, a 10.5 kW prototype with a conical angle of 6.7 degrees is designed using the EMCM and verified through a finite-element analysis (FEA) and experiments. This research provides a theoretical framework for the rapid electromagnetic analysis of the CPMSM. Full article
(This article belongs to the Section Electronic Sensors)
►▼ Show Figures

Figure 1

13 pages, 1692 KiB
Article
Novel Magnetic Field Modulation Concept Using Multiferroic Heterostructure for Magnetoresistive Sensors
by Long Pan, Mengchun Pan, Jiafei Hu, Yueguo Hu, Yulu Che, Yang Yu, Nan Wang, Weicheng Qiu, Peisen Li, Junping Peng and Jianzhong Jiang
Sensors 2020, 20(5), 1440; https://doi.org/10.3390/s20051440 - 6 Mar 2020
Cited by 10 | Viewed by 4037
Abstract
The low frequency magnetic field detection ability of magnetoresistive (MR)sensor is seriously affected by 1/f noise. At present, the method to suppress the influence of low frequency noise is mainly to modulate the measured magnetic field by mechanical resonance. In this paper, a [...] Read more.
The low frequency magnetic field detection ability of magnetoresistive (MR)sensor is seriously affected by 1/f noise. At present, the method to suppress the influence of low frequency noise is mainly to modulate the measured magnetic field by mechanical resonance. In this paper, a novel modulation concept employing a magnetoelectric coupling effect is proposed. A design method of modulation structure based on an equivalent magnetic circuit model (EMCM) and a single domain model of in-plane moment was established. An EMCM was established to examine the relationship between the permeability of flux modulation film (FMF) and modulation efficiency, which was further verified through a finite element simulation model (FESM). Then, the permeability modulated by the voltage of a ferroelectric/ferromagnetic (FE/FM) multiferroic heterostructure was theoretically studied. Combining these studies, the modulation structure and the material were further optimized, and a FeSiBPC/PMN-PT sample was prepared. Experimental results show that the actual magnetic susceptibility modulation ability of FeSiBPC/PMN-PT reached 150 times, and is in good agreement with the theoretical prediction. A theoretical modulation efficiency higher than 73% driven by a voltage of 10 V in FeSiBPC/PMN-PT can be obtained. These studies show a new concept for magnetoelectric coupling application, and establish a new method for magnetic field modulation with a multiferroic heterostructure. Full article
(This article belongs to the Section Physical Sensors)
►▼ Show Figures

Figure 1

18 pages, 9902 KiB
Article
Analytical Calculation of the Magnetic Field Distribution in a Linear and Rotary Machine with an Orthogonally Arrayed Permanent Magnet
by Lei Xu, Mingyao Lin, Xinghe Fu, Kai Liu and Baocheng Guo
Energies 2017, 10(4), 493; https://doi.org/10.3390/en10040493 - 6 Apr 2017
Cited by 9 | Viewed by 4637
Abstract
In this paper, an analytical model is proposed to analyze and predict the characteristics of a double stator linear and rotary permanent magnet machine (DSLRPMM). In order to simplify the magnetic field calculation, the DSLRPMM is cut along the axial direction (z [...] Read more.
In this paper, an analytical model is proposed to analyze and predict the characteristics of a double stator linear and rotary permanent magnet machine (DSLRPMM). In order to simplify the magnetic field calculation, the DSLRPMM is cut along the axial direction (z direction) and transferred into a planar one. Hence, an analytical model of the machine considered the orthogonal effect (OE) is proposed based on the combined solution of Maxwell’s equation, conformal mapping, and equivalent magnetic circuit model (EMCM). The magnetic field distributions of the DSLRPMM are calculated with and without considering the OE, and some important electromagnetic parameters, including the back electromotive force (EMF), detent force, cogging torque, and output torque and thrust, are also predicted and compared to the 3D finite element analysis (FEA). The results show that the errors between the proposed analytical model and the 3D FEA results are less than 0.2% and even less than 0.1% for certain parameters, that is, the results obtained from the proposed analytical model agree well with that of the FEA. Moreover, the analyzed and predicted results are also verified by the experimental results on the prototype of the DSLRPMM. Full article
►▼ Show Figures

Figure 1
