Energy management strategies are one of the key factors affecting the working efficiency of electric vehicle energy power systems. At present, electric vehicles will develop real-time and efficient energy management strategies according to the topology of on-board energy power system to improve the driving performance of vehicles. In this paper, a new electromechanical flywheel hybrid system is studied. Firstly, the characteristics of the topological scheme of the electromechanical flywheel hybrid system are analyzed, and the working modes are designed. Secondly, in order to improve the efficiency of vehicles’ energy utilization and ensure the real-time performance of the management strategy, an energy management strategy based on fuzzy rules is designed with the flywheel’s state of energy (SOE) as the key reference parameter. Then, considering the directional stability in the braking process, the braking force distribution strategy between the front axle and the rear axle is designed. In order to improve the braking energy recovery efficiency, the secondary distribution strategy consisting of a mechanical braking force and regenerative braking force on the front and rear axles is designed. Finally, the bench test of a electromechanical flywheel hybrid system is carried out. Experiments show that compared with the original dual-motor four-wheel drive scheme, the electromechanical flywheel hybrid four-wheel drive system scheme developed in this paper can reduce the current variation range of lithium batteries by 43.16%, increase the average efficiency by 1.04%, and increase the braking energy recovery rate by 40.61% under the Japan urban cycle conditions. In addition, taking advantage of the energy and power regulation advantages of the electromechanical flywheel device, the power consumption of the lithium battery is reduced by 1.82% under cycling conditions. Full article

The paper presents a novel configuration of an axial hybrid magnetic bearing (AHMB) for the suspension of steel flywheels applied in power-intensive energy storage systems. The combination of a permanent magnet (PM) with excited coil enables one to reduce the power consumption, to limit the system volume, and to apply an effective control in the presence of several types of disturbances. The electromagnetic design of the AHMB parts is carried out by parametric finite element analyses with the purpose to optimize the force performances as well as the winding inductance affecting the electrical supply rating and control capability. Such investigation considers both the temperature dependence of the PM properties and the magnetic saturation effects. The electrical parameters and the force characteristics are then implemented in a control scheme, reproducing the electromechanical behavior of the AHMB-flywheel system. The parameter tuning of the controllers is executed by a Matlab/Simulink code, examining the instantaneous profiles of both the air-gap length and the winding ampere-turns. The results of different dynamic tests are presented, evidencing the smooth air-gap changes and the optimized coil utilization, which are desirable features for a safe and efficient flywheel energy storage. Full article

In this paper, a hybrid storage system solution consisting of flywheels and batteries with a Lithium-manganese oxide cathode and a graphite anode is proposed, for supporting the electrical network primary frequency regulation. The aim of the paper is to investigate the benefits of flywheels in mitigation of the accelerating aging that li-ion batteries suffer during the grid frequency regulation operation. For this purpose, experimental aging tests have been performed on a lithium-manganese oxide battery module and an electrical battery model which takes into account the battery aging has been developed in a Simulink environment. Then, a flywheel electrical model has been implemented, taking into account the thermal and the electromechanical phenomena governing the electrical power exchange. This more complete model of a hybrid storage system enables us to simulate the same aging cycles of the battery-based storage system and to compare the performances of the latter with the hybrid storage system. The simulation results suggest that suitable control of the power shared between the batteries and the flywheels could effectively help in countering Li-ion battery accelerated aging due to the grid frequency regulation service. Full article
