The Janus Helmholtz transducer (JHT) is known for high transmission voltage response (TVR) over a wide bandwidth by its dual-resonance characteristics. It is usually required to design matching circuits for wideband power transmission of JHT. However, conventional matching circuit designs can neither easily cover wide bandwidth nor deliver maximum active power to load. To address this limitation, we propose a novel impedance matching circuit design method to maximize overall power transfer efficiency. The method is based on objective functions of both input and load power factors. The proposed method achieves better active power transfer to load than methods using commonly used input power factor alone. To prove feasibility of the proposed method, we consider equivalent circuit models of cable and JHT and adopt a compact matching circuit of resonant components and a coupling capacitor. By considering three JHTs, two power driving systems, and two frequency bands, we show that the proposed method can achieve a significant improvement in active power transfer to load. By conducting experiments of equivalent JHT circuit, cable, and matching circuit, we also show that input power factor increases by 73.2%, while active power delivered to load increases by 2.03 mW with 1 V_rms input voltage. Full article

Achieving the simultaneity of ventilation and soundproofing is a significant challenge in applied acoustics. Ventilated soundproofing relies on the interplay between local resonance and nonlocal coupling of acoustic waves within a sub-wavelength structure. However, previously studied structures possess limited types of fundamental resonators and lack modifications from the basic arrangement. These constraints often force the specified position of each attenuation peak and low absorption performance. Here, we suggest the in-duct-type sound barrier with dual Helmholtz resonators, which are positioned around the symmetry-breaking waveguides. The numerical simulations for curated dimensions and scattered fields show the aperiodic migrations and effective amplifications of the two absorptive domains. Collaborating with the subsequent reflective domains, the designed structure holds two effective attenuation bands under the first Fabry–Pérot resonance frequency. This study would serve as a valuable example for understanding the local and non-local behaviors of sub-wavelength resonating structures. Additionally, it could be applied in selective noise absorption and reflection more flexibly. Full article

Resonant elements can generate small amounts of energy that make them pertinent for feeding miniaturized accelerometers with the energy needed. Suitable oscillator candidates are Helmholtz resonators, which have been, for a long time, analyzed and designed within the context of linear vibration. This study focuses on extracting nonlinear characteristics of a dual Helmholtz resonator (HR), with a neck-cavity–neck-cavity configuration, mounted on an acoustic waveguide with harmonically oscillating pressure. The mathematical model used for describing the resonator embraces inherent nonlinear air stiffness and the damping nonlinearity of hydrodynamic origin. Numerical solutions for the resonator’s nonlinear oscillations are obtained. Bifurcation diagrams are produced, indicating that the dual HR behaves in a deterministic fashion within the engineering practical limits. Phase portraits are drawn for the system, showing a quasi-periodic motion. Frequency response curves (FRC) are found to shift to the left at the lower resonant frequency indicating a softening behavior. FRC keep generally symmetric curves at the higher resonant frequency indicating a mostly linear behavior. Full article

A high-fidelity computational analysis carefully validated against concurrently obtained experimental results is employed to examine self-noise radiation of airfoils at transitional flow regimes, with a focus on elucidating the connection between the unsteady behavior of the laminar separation bubble (LSB) and the acoustic feedback-loop (AFL) resonant interactions observed in the airfoil boundary layers. The employed parametric study examines AFL sensitivity to the changes in the upstream flow conditions and the airfoil loading. Implicit Large-Eddy Simulations are performed for a NACA-0012 airfoil in selected transitional-flow regimes for which experimental measurements recorded characteristic multiple-tone acoustic spectra with a dual ladder-type frequency structure. The switch between the tone-producing and no-tone-producing regimes is traced to the LSB size and position as a function of the flow Reynolds number and the airfoil angle of attack, and further substantiated by the linear stability analysis. The results indicate a strong multi-tonal airfoil noise radiation associated with the AFL and attributed to the switch from the slowly-growing Tollmien–Schlichting to the fast-growing Kelvin–Helmholtz instabilities occurring in thin LSB regions when those are localized near the trailing-edge (TE) on either side of the airfoil. Such a process eventually results in the nonlinearly saturated flapping vortical modes (“rollers”) that scatter into acoustic waves at the TE. Full article

An enhanced quarter-spherical acoustic energy harvester (AEH) with dual Helmholtz resonators was designed in this work. Compared with the previous research, this AEH can harvest multi-directional acoustic energy, has a widened resonance frequency band, and has an improved energy conversion efficiency. When the length of resonator’s neck is changed, the acoustic resonant frequency of the two resonators is different. The theoretical models of output voltage and output power were studied, and the relationship of output performance with frequency was obtained. The results showed that this AEH can operate efficiently in a frequency band of about 470 Hz. Its output voltage was found to be about 28 mV, and its output power was found to be about 0.05 μW. The power density of this AEH was found to be about 12.7 µW/cm². Therefore, this AEH could be widely used in implantable medical devices such as implantable cardiac pacemakers, cochlear implants, and retinal prosthesis. Full article
