This research proposes integrating a combined system from a supercritical Brayton cycle (SBC) at extremely high temperatures and pressures and a conventional ORC cycle. The ORC cycle was evaluated with three working fluids: acetone, toluene, and cyclohexane. Of these, the cyclohexane, thanks to its dry fluid condition, obtained the best result in the sensitivity analysis for the energetic and exergetic evaluations with the most relevant (net power and exergy destruction) for the variation in the most critical performance parameter of the system for both the configuration with reheat and the configuration with recompression. Between the two proposed configurations, the most favorable performance was obtained with a binary system with reheat and recompression; with reheat, the SBC obtained first- and second-law efficiencies of 45.8% and 25.2%, respectively, while the SBC obtained values of 54.8% and 27.9%, respectively, with reheat and recompression. Thus, an increase in overall system efficiency of 30.3% is obtained. In addition, the destroyed exergy is reduced by 23% due to the bypass before the evaporation process. The SBC-ORC combined hybrid system with reheat and recompression has a solar radiation of 950 W/m² K, an exhaust heat recovery efficiency of 0.85, and a turbine inlet temperature of 1008.15 K. The high pressure is 25,000 kPa, the isentropic efficiency of the turbines is 0.8, the pressure ratio is 12, and the pinch point of the evaporator is initially 20 °C and reaches values of 45 °C in favorable supercritical conditions. Full article

Due to increasing emissions and global warming, in parallel with the increasing world population and energy needs, IMO has introduced severe rules for ships. Energy efficiency on ships can be achieved using the organic and inorganic Rankine cycle (RC) driven by exhaust heat from marine diesel engines. In this study, toluene, R600, isopentane, and n-hexane as dry fluids; R717 and R718 as wet fluids; and R123, R142b, R600a, R245fa, and R141b as isentropic fluids are selected as the working fluid because they are commonly used refrigerants, with favorable thermal properties, zero ODP, low GWP and are good contenders for this application. The cycle and exergy efficiencies, net power, and irreversibility of marine diesel engine exhaust-driven simple RC and RC with a recuperator are calculated. For dry fluids, the most efficient fluid at low turbine inlet temperatures is n-hexane at 39.75%, while at high turbine inlet temperatures, it is toluene at 41.20%. For isentropic fluids, the most efficient fluid at low turbine inlet temperatures is R123 with 23%, while at high turbine inlet temperatures it is R141b with 23%. As an inorganic fluid, R718 is one of the most suitable working fluids at high turbine inlet temperatures of 300 °C onboard ships with a safety group classification of A1, ODP of 0, and GWP100 of 0, with a cycle efficiency of 33%. This study contributes to significant improvements in fuel efficiency and reductions in greenhouse gas emissions, leading to more sustainable and cost-effective maritime operations. Full article

The cogeneration of power and heat was investigated for Biomass Boiler–Organic Rankine Cycle (BB–ORC) plants with the characteristics of typical units, such as the 1 MW_el Turboden ORC 10 CHP. The thermodynamic analysis of the ORC unit was undertaken considering forty-two (42) dry and isentropic candidate pure working fluids. Only subcritical Rankine cycles were considered, and the pinch point temperature differences for the evaporation and condensation heat exchangers were kept constant at 10 °C in all cases. The study provides an original and unique screening of almost all pure working fluids that are considered appropriate in the literature under the same operation and optimization conditions and compiles them into a single reference. In its conclusions, the study provides useful fluid selection and design guidelines, which may be easily followed depending on the optimization objective of the ORC designer or operator. In general, hydrocarbons are found to lie in the optimum middle range of the fluid spectrum, between the siloxanes that maximize the production of mechanical power and the refrigerants that maximize the production of heat. Specific hydrocarbon fluids, such as cyclopentane, heptane, hexane, benzene, and toluene, are found as rational options for maximum mechanical efficiency when operating with practically feasible condensation pressures between 10 and 200 kPa. At condensation pressures below 10 kPa, ethylbenzene, o-xylene, m-xylene, p-xylene, and nonane are also found to be feasible options. Finally, cyclopentane, hexane, and MM (hexamethyldisiloxane) are selected as the most appropriate options for cogeneration plants aiming simultaneously at high mechanical power and maximum temperature water production. Full article

The publication examines one of the most effective ways to decarbonize marine transport, specifically the secondary heat sources utilization in the cogeneration cycle of the main engines. The research focuses on the optimization of Organic Rankine Cycle (ORC) performance parameters by combining them with the exhaust energy potential of a medium speed four-stroke main diesel engine in ISO8178 (E3) load cycle modes. Significant advantages were not found between the evaluated Wet-, Isentropic-, and Dry-type liquids (R134a, R141b, R142b, R245fa, Isopentane) in terms of ORC energy performance with a 10% difference. The use of a variable geometry turbogenerator turbine with Dry-type (R134a) working fluid is characterized by the highest ORC energy efficiency up to 15% and an increase in power plant (including turbogenerator generated mechanical) by 6.2%. For a fixed geometry turbine, a rational control strategy of the working fluid flow ($G_{d.sk}$ − ${\pi }_T$) is determined by the priorities of the power plant in certain load modes. The influence of the overboard water temperature on the ORC energy indicators does not exceed ±1%; however, it influences the thermodynamic saturation parameters of the working fluid condensation and, in connection with that, the fluid selection. Full article

The shape of the temperature vs. specific entropy diagram of a working fluid is very important to understanding the behavior of fluid during the expansion phase of the organic Rankine cycle or similar processes. Traditional wet-dry-isentropic classifications of these materials are not sufficient; several materials remain unclassified or misclassified, while materials listed in the same class might show crucial differences. A novel classification, based on the characteristic points of the T–s diagrams was introduced recently, listing eight different classes. In this paper, we present a map of these classes for a model material, namely, the van der Waals fluid in reduced temperature (i.e., reduced molecular degree of freedom) space; the latter quantity is related to the molar isochoric specific heat. Although van der Waals fluid cannot be used to predict material properties quantitatively, the model gives a very good and proper qualitative description. Using this map, some peculiarities related to T–s diagrams of working fluids can be understood. Full article

A novel method proposed to choose the optimal working fluid—solely from the point of view of expansion route—for a given heat source and heat sink (characterized by a maximum and minimum temperature). The basis of this method is the novel classification of working fluids using the sequences of their characteristic points on temperature-entropy space. The most suitable existing working fluid can be selected, where an ideal adiabatic (isentropic) expansion step between a given upper and lower temperature is possible in a way, that the initial and final states are both saturated vapour states and the ideal (isentropic) expansion line runs in the superheated (dry) vapour region all along the expansion. Problems related to the presence of droplets or superheated dry steam in the final expansion state can be avoided or minimized by using the working fluid chosen with this method. Results obtained with real materials are compared with those gained with model (van der Waals) fluids; based on the results obtained with model fluids, erroneous experimental data-sets can be pinpointed. Since most of the known working fluids have optimal expansion routes at low temperatures, presently the method is most suitable to choose working fluids for cryogenic cycles, applied for example for heat recovery during LNG-regasification. Some of the materials, however, can be applied in ranges located at relatively higher temperatures, therefore the method can also be applied in some limited manner for the utilization of other low temperature heat sources (like geothermal or waste heat) as well. Full article

One of the most crucial challenges of sustainable development is the use of low-temperature heat sources (60–200 °C), such as thermal solar, geothermal, biomass, or waste heat, for electricity production. Since conventional water-based thermodynamic cycles are not suitable in this temperature range or at least operate with very low efficiency, other working fluids need to be applied. Organic Rankine Cycle (ORC) uses organic working fluids, which results in higher thermal efficiency for low-temperature heat sources. Traditionally, new working fluids are found using a trial-and-error procedure through experience among chemically similar materials. This approach, however, carries a high risk of excluding the ideal working fluid. Therefore, a new method and a simple rule of thumb—based on a correlation related to molar isochoric specific heat capacity of saturated vapor states—were developed. With the application of this thumb rule, novel isentropic and dry working fluids can be found applicable for given low-temperature heat sources. Additionally, the importance of molar quantities—usually ignored by energy engineers—was demonstrated. Full article
