Due to the increasing demand for lithium resources, the efficient exploitation and utilization of low-grade hard-rock deposits has become an inevitable trend. This study conducted comprehensive heavy liquid separation (HLS), numerical simulation, and dense medium separation (DMS) tests using a laboratory dense medium cyclone (DMC) on a low-grade spodumene ore to demonstrate the potential role of DMS technology in this task. HLS tests verified the feasibility of directly producing qualified concentrate and rejecting waste under different separation densities. A two-stage DMS circuit was then proposed, with the influence of key parameters investigated by numerical simulations using the two-fluid model and dispersed model. The optimized set of structural and operational parameters was finally identified by DMS tests. A continuously operated test conducted on −8 + 0.5 mm ore produced a spodumene concentrate grading 5.68% Li₂O with over 80% lithium recovery while rejecting 0.13% Li₂O waste to tailings with ~70% disposal rate but only 7.44% lithium losses. The middling with a yield of 12.66% can be further subjected to a traditional grinding-flotation process. The findings underscore the importance of parameter matching in the DMS and demonstrate the application potential of DMS in the development of low-grade spodumene from other hard-rock occurrences. Full article

This paper investigated pre-concentration of a low-grade Upper Group 2 (UG2) ore to assess the possibility of rejecting waste at a typical discard Platinum Group Metals (PGMs) grade of <0.4 g/t at mass rejection to floats greater than 16% by comparing feed prepared by High pressure grinding rolls (HPGR) to Conventional crushers (Cone crushers). Heavy Liquid Separation (HLS) was conducted as a benchmark test to Dense Medium Separation (DMS) to determine the expected grade, recovery, and mass yield for various size classes and crusher. The comparison between fine size classes −9.5 + 1.18 mm and −6.7 + 1.18 mm crushed by HPGR and conventional crushing showed that, under the conditions tested, the conventional crusher outperformed HPGR in terms of high sinks grade and a higher percentage of material exposed to pre-concentration. Looking at coarser size fractions (+12 mm), HLS results showed that under the conditions tested, size fraction −20 + 1.18 mm crushed by a conventional crusher at an optimum density of 3.4 g/cm³ is an optimized size fraction to run the DMS plant. The pilot DMS cyclone testwork showed that 61.1% by mass could be rejected to the floats stream based on Run of Mine (ROM) feed at 1.12% Cr₂O₃ and 0.42 g/t Total PGMs + Au grade, a typical discardable PGMs grade. Full article

A semi-industrial scale hydrocyclone with a 250 mm internal diameter was used to concentrate medium-grade celestine ore (75%–85% celestine) from the Montevive deposit of Granada (Spain) using a dense ferrosilicon (FeSi) medium. For this purpose, a Box–Behnken factorial design (BBD) was carried out, with the response variable being the Sr concentration measured by X-ray fluorescence (XRF), as well as the concentration of celestine measured by X-ray diffraction (XRD) of the mineral collected from the under (sunk) stream of the hydrocyclone. The experimental factors to be optimised were the density of the medium in the mixing tank (water, FeSi, and feed mineral) varying from 2.7 to 2.9 kg/L, the hydrocyclone inlet pressure from 0.8 to 1.2 bar, and the hydrocyclone inclination (from 15° to 25° from the horizontal). The range of densities of the dense medium to be tested was determined from previous sink–float experiments using medium-grade ore, in which the distribution of mineral phases with different particle size fractions was determined. To evaluate the separation behaviour, the following parameters were considered: the enrichment ratio (E), the tailings discarding ratio (R), and the mineral processing recovery (ε). From the factorial design and the response surface, the optimum parameters maximising celestine concentration in the under stream (78%), were determined. These optimised parameters were: a density of 2.75 kg/L for the dense medium, an inlet pressure of 1.05 bar, and a hydrocyclone inclination varying from 18° to 20°. Under these conditions, a 94% recovery of celestine (68% Sr) can be achieved. These results show that medium-grade celestine ore, accumulated in mine tailings dumps, can be effectively concentrated using DMS hydrocyclones and that the operating parameters can be optimised using a factorial experiment design. This study can contribute to reducing overexploitation of strategic mineral resources, avoiding blasting and environmentally damaging clearing, by applying a simple and sustainable technique. Full article

The separation of fine coal has been widely discussed in the coal preparation industry due to its high economic potential. Dense medium cyclone (DMC) is the most efficient equipment available for fine coal separation. However, the industrial application of DMC is far from satisfactory due to operational difficulties and maintenance. In this research, particle settling behavior in a dense medium cyclone was analyzed for improved separation. The calculation result about feed pressure and separation lower limit, which fits the experimental data well, might be a guidance for industrial DMC design and operation. According to the calculation result, it is highly recommended that the separation lower limit be set at 0.2 mm rather than 0.1 mm, because the feed pressure head required for the latter (50 D) is three times higher than the former (15 D). Full article

This paper presents the CRBeDaSet—a new benchmark dataset designed for evaluating close range, image-based 3D modeling and reconstruction techniques, and the first empirical experiences of its use. The test object is a medium-sized building. Diverse textures characterize the surface of elevations. The dataset contains: the geodetic spatial control network (12 stabilized ground points determined using iterative multi-observation parametric adjustment) and the photogrammetric network (32 artificial signalized and 18 defined natural control points), measured using Leica TS30 total station and 36 terrestrial, mainly convergent photos, acquired from elevated camera standpoints with non-metric digital single-lens reflex Nikon D5100 camera (ground sample distance approx. 3 mm), the complex results of the bundle block adjustment with simultaneous camera calibration performed in the Pictran software package, and the colored point clouds (ca. 250 million points) from terrestrial laser scanning acquired using the Leica ScanStation C10 and post-processed in the Leica Cyclone™ SCAN software (ver. 2022.1.1) which were denoized, filtered, and classified using LoD3 standard (ca. 62 million points). The existing datasets and benchmarks were also described and evaluated in the paper. The proposed photogrammetric dataset was experimentally tested in the open-source application GRAPHOS and the commercial suites ContextCapture, Metashape, PhotoScan, Pix4Dmapper, and RealityCapture. As the first experience in its evaluation, the difficulties and errors that occurred in the software used during dataset digital processing were shown and discussed. The proposed CRBeDaSet benchmark dataset allows obtaining high accuracy (“mm” range) of the photogrammetric 3D object reconstruction in close range, based on a multi-image view uncalibrated imagery, dense image matching techniques, and generated dense point clouds. Full article
