Cylindrical clearance joints are commonly employed in mechanisms that involve the rotation of a shaft spindle within a cylindrical sliding bearing. The intensity of the friction process in such joints is governed by several factors, including the clearance size between components, the materials of the interacting surfaces, the properties and characteristics of the lubricant, the surface roughness (asperities), and the magnitude of the relative velocity between the joint’s components. To experimentally determine the friction coefficient in cylindrical clearance joints, a custom device was designed and implemented. This device is adaptable to a universal lathe and enables the measurement of the friction coefficient under varying normal forces and relative movement speeds between the joint components. The experimental data were subjected to mathematical analysis, leading to the development of an empirical model. This model effectively characterizes the direction and intensity of the influence of various factors on the friction coefficient, accounting for the use of different lubricants. The findings provide valuable insights into optimizing cylindrical clearance joints for improved performance in practical applications. Full article

Surface accuracy is one of the most crucial indicators for evaluating the performance of a large deployable antenna. It depends on the accuracy of the truss structure of the truss antenna. This paper presents a novel method for accurate analysis of a large deployable truss antenna with 3D joint clearances. The proposed method does not depend on the structure’s style, which is suitable for general multi-closed-loop structures. Firstly, the clearance model of the truss structure is established using a vector description. Then, an error transfer path analysis method is proposed for the multi-closed-loop structure. The distribution probability of the truss antenna’s surface accuracy is also obtained. The efficiency of the method is validated through a numerical example of a planar mechanism with a multi-closed loop. The proposed method is also applied to analyze the surface accuracy of the large deployable antenna with a parabolic cylindrical truss. Full article

Nowadays, FDM technology permits obtaining functional prototypes or even end parts. The process parameters, such as layer thickness, building orientation, fill density, type of support, etc., have great influence on the quality, functionality and behavior of the obtained parts during their lifetime. In this paper, we present a study concerning the possibilities of obtaining certain values for clearance in revolute joints of non-assembly mechanisms manufactured by FDM 3D Printing. To ensure the functioning of the assembly, one must know the relationship between the imposed and measured clearances by taking into account the significant input data. One way is to use the automat learning method with an artificial neuronal network (ANN). The data necessary for the training, testing, and validation of ANN were experimentally obtained, using a complete L 27 Taguchi experimental plan. A total of 27 samples were printed with different values of the following parameters: the infill density, the imposed clearance between the shaft and the hole, and the layer thickness. ANN architecture corresponds to the Hecht–Kolmogorov theorem. Genetic algorithms (GA) were used for the optimization of the output. The Neural Network Toolbox from MATLAB was used for training the network and a hybrid tool genetic algorithm artificial neural network (GA-ANN) was used to minimize the value of the absolute relative clearance (arc). The minimum value of the absolute relative clearance established by GA-ANN was 0.0385788. This value was validated experimentally, with a relative difference of 4%. We also introduced a rational function to approximate the correlation between the input and output parameters. This function fulfills some frontier conditions resulted from practice. In addition, the function may be used to establish the designed clearance in order to obtain an imposed one. Full article
