In this study, we present a novel design methodology for unit cells in chessboard metasurfaces with the aim of reducing the radar cross-section (RCS) for linearly polarized waves. The design employs rotational symmetry and incorporates ten continuous parameters to define the metasurface units, enabling the creation of flexible 2D structures. The geometrical parameters of the two units are then optimized using a simulated annealing (SA) algorithm to achieve a low RCS chessboard metasurface. Following optimization, the properties of the metasurface were experimentally verified. The experimental results show a significant RCS reduction of 10 dB within the 7.6–15.5 GHz range, with the peak reduction reaching-28 dB at normal incidence. For a bistatic RCS, the metasurface effectively scatters incident waves into four distinct lobes. The proposed method offers an alternative strategy for the inverse design of low RCS metasurfaces and can be extended to applications in polarization control, phase gradient manipulation, and transmissive metasurfaces. Full article

A wideband polarization-insensitive bistatic radar cross-section (RCS) reduction design under linear and circular polarization incidence is proposed based on spherical-chessboard metasurfaces. A new metasurface element with wideband characteristics was designed, including a double split-ring structure, single-layer media, and metal board. In the proposed RCS-reduction design, the Pancharatnam–Berry (P-B) phase theory is applied with the designed metasurface element to realize phase distribution mimicking the low-scattering sphere, and thus realizing RCS reduction. In addition, the chessboard configuration is combined with spherical phase distribution to further improve the performance of monostatic and bistatic RCS reduction. Finally, the proposed RCS reduction design can not only realize wideband RCS reduction but also exhibit polarization-insensitive characteristics. It realized 10 dB monostatic and bistatic RCS reduction in a frequency band ranging from 8.5 to 21 GHz (84.8% relative bandwidth) under linear polarization (LP) and circular polarization (CP) incidence. The straightforward and efficient design method of the hybrid spherical chessboard can effectively avoid the complex and time-consuming optimization process in RCS-reduction design. Full article

This work focused on the novel and compact 1-bit symmetrical coding-based metamaterial for radar cross section reduction in terahertz frequencies. A couple of coding particles were constructed to impersonate the elements ‘0′ and ‘1′, which have phase differences of 180°. All the analytical simulations were performed by adopting Computer Simulation Technology Microwave Studio 2019 software. Moreover, the transmission coefficient of the element ‘1′ was examined as well by adopting similar software and validated by a high-frequency structure simulator. Meanwhile, the frequency range from 0 to 3 THz was set in this work. The phase response properties of each element were examined before constructing various coding metamaterial designs in smaller and bigger lattices. The proposed unit cells exhibit phase responses at 0.84 THz and 1.54 THz, respectively. Meanwhile, the analysis of various coding sequences was carried out and they manifest interesting monostatic and bistatic radar cross section (RCS) reduction performances. The Coding Sequence 2 manifests the best bistatic RCS reduction values in smaller lattices, which reduced from −69.8 dBm² to −65.5 dBm² at 1.54 THz. On the other hand, the monostatic RCS values for all lattices have an inclined line until they reach a frequency of 1.0 THz from more than −60 dBm². However, from the 1.0 THz to 3.0 THz frequency range the RCS values have moderate discrepancies among the horizontal line for each lattice. Furthermore, two parametric studies were performed to examine the RCS reduction behaviour, for instance, multi-layer structures and as well tilt positioning of the proposed coding metamaterial. Overall it indicates that the integration of coding-based metamaterial successfully reduced the RCS values. Full article

Wavefront-modulated beams such as vortex beams have attracted much attention in the field of target recognition due to the introduced degrees of freedom. However, traditional wavefront-modulated beams are doughnut shaped, and are not suitable for radar detection or tracking. To solve this problem, a linear wavefront phase-modulated beam with a maximum radiation intensity in the center was proposed in a previous study. In this paper, we continue to study target characteristics under the linear wavefront phase-modulated beam. Through analysis of the target scattering based on the physical optics (PO) method, we find that a part of the monostatic or bistatic radar cross-section (RCS) of the target could be obtained by changing the phase gradient of the modulated beam. Taking this part of RCS for feature extraction, we recognize the plates and trihedral corner reflectors through the support vector machine (SVM) method. For data visualization, we use the t-distributed stochastic neighbor embedding (t-SNE) method for data dimensionality reduction. The results show that the recognition probability of the plates and trihedral corner reflectors can reach 91% with an antenna array having an aperture of 20 wavelengths when the signal-to-noise ratio (SNR) is 20 dB, while the traditional plane beam cannot classify these two targets directly. Full article

The development of diffusion metasurfaces created new opportunities to elevate the stealthiness of combat aircraft. Despite the potential significance of metasurfaces, their rigorous design methodologies are still lacking, especially in the context of meticulous control over the scattering of electromagnetic (EM) waves through geometry parameter tuning. Another practical issue is insufficiency of the existing performance metrics, specifically, monostatic and bistatic evaluation of the reflectivity, especially at the design stage of metasurfaces. Both provide limited insight into the RCS reduction properties, with the latter being dependent on the selection of the planes over which the evaluation takes place. This paper introduces a novel performance metric for evaluating scattering characteristics of a metasurface, referred to as Normalized Partial Scattering Cross Section (NPSCS). The metric involves integration of the scattered energy over a specific solid angle, which allows for a comprehensive assessment of the structure performance in a format largely independent of the particular arrangement of the scattering lobes. We demonstrate the utility of the introduced metric using two specific metasurface architectures. In particular, we show that the integral-based metric can be used to discriminate between the various surface configurations (e.g., checkerboard versus random), which cannot be conclusively compared using traditional methods. Consequently, the proposed approach can be a useful tool in benchmarking radar cross section reduction performance of metamaterial-based, and other types of scattering structures. Full article

A novel non-planar coding metasurface optimized by discrete particle swarm algorithm (DPSO) is proposed in terms of the property of wideband radar cross-section (RCS) and diffuse scattering. The design consists of two unit cells, “0” and “1”, which have a 180° ± 37° phase difference for phase interference cancellation. The 10 dB monostatic RCS reduction frequency range of the metasurface is from 6.4 to 29.6 GHz, and its bandwidth ratio is 4.62:1, under normal incidence of the two polarizations. Compared to the planar surface, the non-planar surface has a greater bandwidth with respect to the monostatic and bistatic RCS reduction. The results declare its properties of ultra-wideband, angle insensitivity, and polarization insensitivity. Finally, the theoretical analysis, simulation, and experimental results match perfectly, indicating that the metasurface can be used in the RCS reduction or other microwave applications with wider RCS reduction and diffuse scattering. Full article

This paper presents a radar cross-section (RCS) reduction technique by using the coding diffusion metasurface, which is optimised through a random optimization algorithm. The design consists of two unit cells, which are elements ‘1’ and ‘0’. The reflection phase between the two-unit cells has a 180° ± 37° phase difference. It has a working frequency band from 8.6 GHz to 22.5 GHz, with more than 9 dB RCS reduction. The monostatic RCS reduction has a wider bandwidth of coding diffusion metasurface as compared to the traditional chessboard metasurface. In addition, the bistatic performance of the designed metasurfaces is observed at 15.4 GHz, which shows obvious RCS reduction when compared to a metallic plate of the same size. The simulated and measured result shows the proficiency of the designed metasurface. Full article
