This study aimed to simulate curved excavation using a tunnel boring machine (TBM) steering system based on the proposed mathematical methodology applied in a TBM simulator. We introduce the concept and mechanism of the TBM steering system and describe the mathematical formulae used for simulating curved excavation. Curved excavation in the top- right direction was simulated using a Python program to verify the mathematical formulae. In addition, Python simulations were undertaken to determine the effects of horizontal and vertical articulation angles on pitching and yawing angles. Finally, the proposed mathematical formulae were applied in the TBM operation simulator, and tested based on the mechanism of the TBM steering system. Full article

With the continuous development of road transport of goods, the issue of safety risks related to the movement of trucks and road trains remains an essential element of the overall road safety system. One of the persistent problems is the braking of such kits, especially in emergencies on the road. The work aims to show how typical changes in operating conditions can affect the basic indicators illustrating the safety of braking (effectiveness indicators, stability symptoms). A simulation method was applied for the analysis, which used a relatively simple (quasi-static) model of the tractor-semitrailer set’s rectilinear motion and models of the braking system and the longitudinal forces in the tyre-road surface contact. Calculations were made for the selected truck-trailer set in nominal condition and for several deviations from the nominal state, such as loading the trailer (load value, location of the semi-trailer’s centre of gravity), reduced surface adhesion, and selected faults of the semitrailer braking system. The results were compared for several qualitative and quantitative criteria for the evaluation of braking safety. Attention was drawn to the problem of the forces in the coupling (which determine the possibility of jack-knifing phenomena), the order of axle locking, and the braking distance. The presented results show that the change of operating conditions as above compared to the nominal condition visibly deteriorates the effectiveness of the braking process. The greatest threat, both related to the braking efficiency and the increase in the force in the coupling, is associated with the lack of braking of the semitrailer axle or a significant reduction in its load. The weight and location of the load’s centre of gravity considerably impact braking safety. In addition to the negative impact on the braking distance or increase in the horizontal force in the coupling, it changes the order of locking the axle. ABS reduces the risk associated with braking safety but does not eliminate it. At the same time, it has been shown that using relatively simple calculation tools makes it possible to indicate the risks related to the braking safety of such articulated vehicles. Full article

In conservative, mostly Malay-Muslim Malaysia, transgender people are frequently articulated in mainstream Muslim and Christian discourses as gendered anomalies and recalcitrant religious dissidents. Due to the fact that normative gender identities and expressions are generally indexed as valid and, thus, ‘successful’ indicators of social and religious coherence among Malaysians, transgender people who are unable and/or unwilling to abide by regimes of gendered and religious normativity are regarded with scorn as simultaneous failures in gender and religion. By framing my analysis and theorising of selected narratives from two Malaysian Roman Catholic transgender men through Judith/Jack Halberstam’s concept of the queer art of failure, I argue that some transgender men of faith actively repudiate such disdainful perceptions by embracing gendered and religious failures, an intellectual resolution which they then translate into strategic customisations of their own spirituality and ethical living. These customisations, anchored in an unshakeable belief in God’s loving support and their inherent value in God’s eyes despite ecclesiastical disapproval, are acts of subversion that respond impertinently to and defy hegemonic ideologies of gender and religion, and re-imagine alternative knowledges, values, powers, and pleasures towards meaningful forms of liveability. Full article

Underground mining machines, such as wheel-tyre drilling rigs, are articulated and equipped with booms that project far beyond the undercarriage. Such a structure makes these machines prone to losing stability. Hence, it is necessary to analyse the distribution of masses and geometry as well as their broadly understood stability during the entire design process, taking into account many factors resulting from the manner and conditions of their operation. However, there are no appropriate computational models that would enable analytical tests to be carried out for machines with this kind of construction. This article is concerned with the author’s computational model, which allows the stability of single- and twin-boom drilling rigs to be quickly assessed. The model makes it possible to perform analyses without having to solve differential equations that are present in dynamic models or using specialist software based on CAD and CAE tools. The developed model allows determination of the pressure of wheels and jacks as a function of many important parameters and variables. Additionally, the distances of the centre of gravity from the tipping edge are calculated. The developed computational model was verified by comparing the obtained results with the results of the full dynamic model, the results of model tests carried out in the CAD/CAE program, and the results of empirical tests of wheel and jack pressures on the ground for the selected drilling rig. The model was subjected to verification and validation, which proved that it was fully correct and useful. The model was used to prepare a practical and user-friendly calculation sheet. Apart from the numerical values, the calculation sheet contains a graphical representation of the machine, the location of the centre of gravity, the tipping edges, as well as graphs of the wheel and jack pressures. Next, analytical tests of the stability of the selected drilling rig were carried out. The obtained calculation results are consistent with the results of empirical research. The computational model and the spreadsheet provide handy tools used during the design process by one of the Polish company’s producing drilling rigs. Full article

In this study, a new rig for investigating the static and dynamic stability of agricultural machines was conceived: its architecture was studied and its layout was designed following a specific conceptual approach. The first part of the proposed design process specifically addresses the test equipment and follows a ‘top-down’ logic starting from the requisites of the tests to perform. This approach alternates analysis and synthesis phases and exploits two important principles of the creative design process: functional analysis and decomposition, and kinematic inversion. During this process, many solutions (kinematic mechanisms, actuators) were proposed and discussed based on their advantages and disadvantages towards the definition of an optimal configuration. Therefore, the layout of a new mechanical system has been developed, which is supposed to steer subsequent and more detailed design-phases appropriately. The proposed facility has many innovative features compared to traditional test systems, in which vehicles are tested for lateral overturning under static conditions with the steering components (wheels/central joint for conventional/articulated vehicles) usually in a configuration corresponding only to a straight-path trajectory. Indeed, the present test rig is a mechanical installation with three degrees of freedom. It presents a wide plane, which can be tilted, composed by two semi-platforms connected by a central articulation hinge, operated by hydraulic jacks which allow the different angulations of the semi-platforms. It is specifically thought for performing dynamic stability tests of vehicles, especially on circular trajectories. An additional subsystem embedded in one of the two semi-platforms, configured as a rotating platform (‘turntable’), can test the global (static) stability of motionless vehicles placed on it. Full article

The objective of this study was to specify, parameterize, and evaluate an acoustic-based inferential framework for estimating commercially-relevant wood attributes within standing jack pine (Pinus banksiana Lamb) trees. The analytical framework consisted of a suite of models for predicting the dynamic modulus of elasticity (m_e), microfibril angle (m_a), oven-dried wood density (w_d), tracheid wall thickness (w_t), radial and tangential tracheid diameters (d_r and d_t, respectively), fibre coarseness (c_o), and specific surface area (s_a), from dilatational stress wave velocity (v_d). Data acquisition consisted of (1) in-forest collection of acoustic velocity measurements on 61 sample trees situated within 10 variable-sized plots that were established in four mature jack pine stands situated in boreal Canada followed by the removal of breast-height cross-sectional disk samples, and (2) given (1), in-laboratory extraction of radial-based transverse xylem samples from the 61 disks and subsequent attribute determination via Silviscan-3. Statistically, attribute-specific acoustic prediction models were specified, parameterized, and, subsequently, evaluated on their goodness-of-fit, lack-of-fit, and predictive ability. The results indicated that significant (p ≤ 0.05) and unbiased relationships could be established for all attributes but d_t. The models explained 71%, 66%, 61%, 42%, 30%, 19%, and 13% of the variation in m_e, w_t, s_a, c_o, w_d, m_a, and d_r, respectively. Simulated model performance when deploying an acoustic-based wood density estimate indicated that the expected magnitude of the error arising from predicting d_t, c_o, s_a, w_t, m_e, and m_a prediction would be in the order of ±8%, ±12%, ±12%, ±13%, ±20%, and ±39% of their true values, respectively. Assessment of the utility of predicting the prerequisite w_d estimate using micro-drill resistance measures revealed that the amplitude-based w_d estimate was inconsequentially more precise than that obtained from v_d (≈ <2%). A discourse regarding the potential utility and limitations of the acoustic-based computational suite for forecasting jack pine end-product potential was also articulated. Full article
