Surface albedo measures the proportion of incoming solar radiation reflected by the Earth’s surface. Accurate albedo retrieval from remote sensing data usually requires sufficient multi-angular observations to account for the surface reflectance anisotropy. However, most middle and high-resolution remote sensing satellites lack the capability to acquire sufficient multi-angular observations. Existing algorithms for retrieving surface albedo from single-direction reflectance typically rely on land cover types and vegetation indices to extract the corresponding prior knowledge of surface anisotropic reflectance from coarse-resolution Bidirectional Reflectance Distribution Function (BRDF) products. This study introduces an algorithm for retrieving albedo from directional reflectance based on a 3 × 3 BRDF archetype database established using the 2015 global time-series Moderate Resolution Imaging Spectro-radiometer (MODIS) BRDF product. For different directions, BRDF archetypes are applied to the simulated MODIS directional reflectance to retrieve albedo. By comparing the retrieved albedos with the MODIS albedo, the BRDF archetype that yields the smallest Root Mean Squared Error (RMSE) is selected as the prior BRDF for the direction. A lookup table (LUT) that contains the optimal BRDF archetypes for albedo retrieval under various observational geometries is established. The impact of the number of BRDF archetypes on the accuracy of albedo is analyzed according to the 2020 MODIS BRDF. The LUT is applied to the MODIS BRDF within specific BRDF archetype classes to validate its applicability under different anisotropic reflectance characteristics. The applicability of the LUT across different data types is further evaluated using simulated reflectance or real multi-angular measurements. The results indicate that (1) for any direction, a specific BRDF archetype can retrieve a high-accuracy albedo from directional reflectance. The optimal BRDF archetype varies with the observation direction. (2) Compared to the prior BRDF knowledge obtained through averaging method, the BRDF archetype LUT based on the 3 × 3 BRDF archetype database can more accurately retrieve the surface albedo. (3) The BRDF archetype LUT effectively eliminates the influence of surface anisotropic reflectance characteristics in albedo retrieval across different scales and types of data. Full article

Land surface albedo inversion based on satellite data requires multiple consecutive (generally greater than or equal to 7) observations. Due to weather reasons such as cloud occlusion, it is difficult to obtain sufficient observation data, which leads to low inversion accuracy and even unsuccessful inversion. The anisotropic flat index (AFX) index was used to classify the 5-year multiangle observation data set of reflectance and eight bidirectional reflectance distribution function (BRDF) archetypes were obtained in Hefei, Anhui, China. The eight obtained BRDF archetypes in the Hefei area were applied to FY-2G satellite data for land surface albedo retrieval, and the retrieved land surface albedo was compared with MODIS land surface albedo products. The results show that the land surface albedo can be retrieved well using FY-2G data by BRDF archetypes. Full article

The land surface albedo reflects the ability of the surface to reflect solar radiation and is a critical physical variable in the study of the Earth’s energy budget and global climate change. Algorithms for the retrieval of albedo usually require multi-angle measurements due to surface anisotropy. However, most of the satellites cannot currently provide sufficient and well-distributed observations; therefore, the accuracy of remotely sensed albedo is constrained. Based on the Moderate-Resolution Imaging Spectroradiometer (MODIS) Bidirectional Reflectance Distribution Function (BRDF) and albedo product (MCD43A1), this study proposed a method to further subdivide reflectance anisotropy and build an updated database of BRDF archetype, using both the Anisotropic Flat Index (AFX) and Perpendicular Anisotropic Flat Index (PAFX). The BRDF archetypes were used to fit the corresponding MODIS BRDF, and the optimal number of BRDF archetype categories was determined according to the tendency of fitting error. The effect of surface anisotropy and observation noise on albedo retrieval were explored based on simulated MODIS reflectance. Finally, the BRDF archetype A2P2 was taken as prior knowledge to retrieve albedo from a different number of MODIS observations, and the result was validated by the high-quality MODIS albedo product. The results show that the fitting error between BRDF archetypes and MODIS BRDF shows a rapid decline when introducing the PAFX in the classification process. A 3-by-3 matrix of BRDF archetypes, which occupy 73.44% and 70.13% of the total decline in the red and NIR band, can be used to represent the characteristics of reflectance anisotropy. The archetype A2P2 may be used as prior knowledge to improve the albedo retrieval from insufficient observations. The validation results based on MODIS observations show that the archetype A2P2-based albedo can reach root-mean-square errors (RMSEs) of no more than 0.03. Full article

The reflectance anisotropy effect on albedo retrieval was evaluated using the Moderate Resolution Imaging Spectroradiometer (MODIS) bidirectional reflectance distribution functions (BRDFs) product, and archetypal BRDFs. Shortwave-band archetypal BRDFs were established, and validated, based on the Anisotropy Flat indeX (AFX) and time series MODIS BRDF over tile h11v03. To generate surface albedo, archetypal BRDFs were used to fit simulated reflectance, based on the least squares method. Albedo was also retrieved based on the least root-mean-square-error (RMSE) method or normalized difference vegetation index (NDVI) based prior BRDF knowledge. The difference between those albedos and the MODIS albedo was used to quantify the reflectance anisotropy effect. The albedo over tile h11v03 for day 185 in 2009 was retrieved from single directional reflectance and the third archetypal BRDF. The results show that six archetypal BRDFs are sufficient to represent the reflectance anisotropy for albedo estimation. For the data used in this study, the relative uncertainty caused by reflectance anisotropy can reach up to 7.4%, 16.2%, and 20.2% for sufficient, insufficient multi-angular and single directional observations. The intermediate archetypal BRDFs may be used to improve the albedo retrieval accuracy from insufficient or single observations with a relative uncertainty range of 8–15%. Full article

Many previous studies have attempted to extract prior reflectance anisotropy knowledge from the historical MODIS Bidirectional Reflectance Distribution Function (BRDF) product based on land cover or Normalized Difference Vegetation Index (NDVI) data. In this study, the feasibility of the method is discussed based on MODIS data and archetypal BRDFs. The BRDF is simplified into six archetypal BRDFs that represent different reflectance anisotropies. Five-year time series of MODIS BRDF data over three tiles are classified into six BRDF archetype classes according to the Anisotropy Flat indeX (AFX). The percentage of each BRDF archetype class in different land cover classes or every 0.1-NDVI interval is determined. Nadir BRDF-Adjusted Reflectances (NBARs) and NDVIs simulated from different archetypal BRDFs and the same multi-angular observations are compared to MODIS results to study the effectiveness of the method. The results show that one land cover type, or every 0.1-NDVI interval, contains all the potential BRDF shapes and that one BRDF archetypal class makes up no more than 40% of all data. Moreover, the differences between the NBARs and NDVIs simulated from different archetypal BRDFs are insignificant. In terms of the archetypal BRDF method and MODIS BRDF product, this study indicates that the land cover or NDVI is not necessarily related to surface reflectance anisotropy. Full article

Bidirectional reflectance distribution function (BRDF) archetypes extracted from the Moderate Resolution Imaging Spectroradiometer (MODIS) BRDF/Albedo product over the global Earth Observing System Land Validation Core Sites can be used to simplify BRDF models. The present study attempts to evaluate the representativeness of BRDF archetypes for surface reflectance anisotropy. Five-year forward-modeled MODIS multi-angular reflectance (MCD-ref) and aditional actual MODIS multi-angular observations (MCD-obs) in four growing periods in 2008 over three tiles were taken as validation data. First, BRDF archetypes in the principal plane were qualitatively compared with the time-series MODIS BRDF product of randomly sampled pixels. Secondly, BRDF archetypes were used to fit MCD-ref, and the average root-mean-squared errors (RMSEs) over each tile were examined for these five years. Finally, both BRDF archetypes and the MODIS BRDF were used to fit MCD-obs, and the histograms of the fit-RMSEs were compared. The consistency of the directional reflectance between the BRDF archetypes and MODIS BRDFs in nadir-view, hotspot and entire viewing hemisphere at 30° and 50° solar geometries were also examined. The results confirm that BRDF archetypes are representative of surface reflectance anisotropy for available snow-free MODIS data. Full article

A land-cover-based linear BRDF (bi-directional reflectance distribution function) unmixing (LLBU) algorithm based on the kernel-driven model is proposed to combine the compact airborne spectrographic imager (CASI) reflectance with the moderate resolution imaging spectroradiometer (MODIS) daily reflectance product to derive the BRDF/albedo of the two sensors simultaneously in the foci experimental area (FEA) of the Heihe Watershed Allied Telemetry Experimental Research (HiWATER), which was carried out in the Heihe River basin, China. For each land cover type, an archetypal BRDF, which characterizes the shape of its anisotropic reflectance, is extracted by linearly unmixing from the MODIS reflectance with the assistance of a high-resolution classification map. The isotropic coefficients accounting for the differences within a class are derived from the CASI reflectance. The BRDF is finally determined by the archetypal BRDF and the corresponding isotropic coefficients. Direct comparisons of the cropland archetypal BRDF and CASI albedo with in situ measurements show good agreement. An indirect validation which compares retrieved BRDF/albedo with that of the MCD43A1 standard product issued by NASA and aggregated CASI albedo also suggests reasonable reliability. LLBU has potential to retrieve the high spatial resolution BRDF/albedo product for airborne and spaceborne sensors which have inadequate angular samplings. In addition, it can shorten the timescale for coarse spatial resolution product like MODIS. Full article
