The active sound navigation and ranging (SONAR) transmission system emits acoustic pulses underwater using a wave generator, a SONAR power amplifier (SPA), and a projector. The acoustic pulse travel in the direction of the target and return as an echo to a hydrophone to learn the range or speed of the object. Often the same device is used as a hydrophone and a projector; in this context, it is known as a transducer. In order to obtain a maximum range of detection in the SONAR, it is desirable to generate the maximum amount of acoustic power until the point in which the echo can be detectable in an atmosphere with non-wished noise. Therefore, a high value of source level (SL) is required that depends largely on the value of electrical power applied to the transducer ($P_e$). However, when trying to obtain the maximum range of detection in the SONAR system there are the following three peculiar limitations that affect performance: The cavitation, the reverberation, and the effect of interaction in the near field. In this paper, an experimental measurement methodology is presented to detect the cavitation effects in a tonpilz-type transducer for an active SONAR transmission system using a transducer as a projector and a calibrated hydrophone in a hydroacoustic tank by measuring the parameters of total harmonic distortion of the fundamental waveform (THD-F) of the generated acoustic pulse, transmitting voltage response (TVR) to characterize the system and sound pressure level (SPL) that indicates the intensity of sound at a given distance. Whereas the reverberation and the interaction effect in the near field are objects of other study cases. A 570.21 W and THD-F < $5\%$ switched-mode power amplifier (SMPA) prototype was developed to excite the electroacoustic transducer employing a full-bridge inverter (FBI) topology and a digital controller using a field-programmable gate array (FPGA) for unipolar sine pulse width modulation (SPWM) to generate a continuous wave (CW) acoustic pulse at a frequency 11.6 kHz. The results obtained show that from the level of $P_e=196.05$ W with the transducer at 1 $\mathrm{m}$ of depth, the value of THD-F increases significantly while the behavior of the TVR and SPL parameters is affected since it is not as expected and is attributed when cavitation occurs. Full article

Tonpilz is a popular transducer for underwater projector arrays for sonar systems. For low-frequency transmission, a larger axial dimension of the conventional Tonpilz transducer is required. However, a bulky and heavy Tonpilz element is not suitable due to limitations in terms of the space and payload of the array platform. To address this problem, we developed a rear-mounted Tonpilz transducer to generate a sub-fundamental resonance in addition to the common longitudinal resonance. For this purpose, we developed a new equivalent circuit model that can reflect all the effects of the key design parameters of the transducer, such as suspension thickness (stiffness), tail mass thickness, and head mass thickness. The impedance and transmitting voltage response were evaluated as performance factors at both resonance frequencies. The validity of the circuit was verified by comparing the analysis results with those from the finite element analysis of the same transducer. Based on the results, the transducer structure was designed to have comparable transmitting performance at both resonance frequencies by employing relatively high suspension stiffness, light tail mass, and heavy head mass. The novel design can permit the dual-band operation of the transducer so that the transducer can operate as a wideband projector. Full article
