Accurate determination of elastic properties, especially Poisson’s ratio, is crucial for the design and modeling of composite materials. Traditional methods often struggle with low strain measurements and non-uniform strain distributions inherent in these anisotropic materials. This research work introduces a novel methodology that integrates Digital Image Correlation (DIC) with frequency analysis techniques to improve the precision of Poisson’s ratio determination during tensile tests, particularly at low strain ranges. The focus is on the evaluation of two distinct frequency-based approaches: Phase-Based Motion Magnification (PBMM) and Lock-in filtering. DIC + PBMM, while promising for motion amplification, encountered specific challenges in this application, particularly at very low strain amplitudes, leading to increased variability and computational demands. In contrast, the DIC + Lock-in filtering method proved highly effective. It provided stable, filtered strain distributions, significantly reducing measurement uncertainty compared to traditional DIC and other conventional methods like strain gauges and Video Extensometers. This study demonstrates the robust potential of Lock-in filtering for characterizing subtle periodic mechanical behaviors leading to a reduction of approximately 70% in the standard deviation of the measurement. This work lays a strong foundation for more precise and reliable material characterization, crucial for advancing composite design and engineering applications. Full article

In recent years, the development of computer vision technology has led to significant implementations of non-contact structural identification. This study investigates the performance offered by the Phase-Based Motion Magnification (PBMM) algorithm, which employs video acquisitions to estimate the displacements of target pixels and amplify vibrations occurring within a desired frequency band. Using low-cost acquisition setups, this technique can potentially replace the pointwise measurements provided by traditional contact sensors. The main novelty of this experimental research is the validation of PBMM-based experimental modal analyses on multi-storey frame structures with different stiffnesses, considering six structural layouts with different configurations of diagonal bracings. The PBMM results, both in terms of time series and identified modal parameters, are validated against benchmarks provided by an array of physically attached accelerometers. In addition, the influence of pixel intensity on estimates’ accuracy is investigated. Although the PBMM method shows limitations due to the low frame rates of the commercial cameras employed, along with an increase in the signal-to-noise ratio in correspondence of bracing nodes, this method turned out to be effective in modal identification for structures with modest variations in stiffness in terms of height. Moreover, the algorithm exhibits modest sensitivity to pixel intensity. An open access dataset containing video and sensor data recorded during the experiments, is available to support further research at the following https://doi.org/10.5281/zenodo.10412857. Full article

Oral capillaroscopy is a critical and non-invasive technique used to evaluate microcirculation. Its ability to observe small vessels in vivo has generated significant interest in the field. Capillaroscopy serves as an essential tool for diagnosing and prognosing various pathologies, with anatomic–pathological lesions playing a crucial role in their progression. Despite its importance, the utilization of videocapillaroscopy in the oral cavity encounters limitations due to the acquisition setup, encompassing spatial and temporal resolutions of the video camera, objective magnification, and physical probe dimensions. Moreover, the operator’s influence during the acquisition process, particularly how the probe is maneuvered, further affects its effectiveness. This study aims to address these challenges and improve data reliability by developing a computerized support system for microcirculation analysis. The designed system performs stabilization, enhancement and automatic segmentation of capillaries in oral mucosal video sequences. The stabilization phase was performed by means of a method based on the coupling of seed points in a classification process. The enhancement process implemented was based on the temporal analysis of the capillaroscopic frames. Finally, an automatic segmentation phase of the capillaries was implemented with the additional objective of quantitatively assessing the signal improvement achieved through the developed techniques. Specifically, transfer learning of the renowned U-net deep network was implemented for this purpose. The proposed method underwent testing on a database with ground truth obtained from expert manual segmentation. The obtained results demonstrate an achieved Jaccard index of 90.1% and an accuracy of 96.2%, highlighting the effectiveness of the developed techniques in oral capillaroscopy. In conclusion, these promising outcomes encourage the utilization of this method to assist in the diagnosis and monitoring of conditions that impact microcirculation, such as rheumatologic or cardiovascular disorders. Full article

As a promising alternative to conventional contact sensors, vision-based technologies for a structural dynamic response measurement and health monitoring have attracted much attention from the research community. Among these technologies, Eulerian video magnification has a unique capability of analyzing modal responses and visualizing modal shapes. To reduce the noise interference and improve the quality and stability of the modal shape visualization, this study proposes a hybrid motion magnification framework that combines linear and phase-based motion processing. Based on the assumption that temporal variations can represent spatial motions, the linear motion processing extracts and manipulates the temporal intensity variations related to modal responses through matrix decomposition and underdetermined blind source separation (BSS) techniques. Meanwhile, the theory of Fourier transform profilometry (FTP) is utilized to reduce spatial high-frequency noise. As all spatial motions in a video are linearly controllable, the subsequent phase-based motion processing highlights the motions and visualizes the modal shapes with a higher quality. The proposed method is validated by two laboratory experiments and a field test on a large-scale truss bridge. The quantitative evaluation results with high-speed cameras demonstrate that the hybrid method performs better than the single-step phase-based motion magnification method in visualizing sound-induced subtle motions. In the field test, the vibration characteristics of the truss bridge when a train is driving across the bridge are studied with a commercial camera over 400 m away from the bridge. Moreover, four full-field modal shapes of the bridge are successfully observed. Full article

Advancements in optical imaging devices and computer vision algorithms allow the exploration of novel diagnostic techniques for use within engineering systems. A recent field of application lies in the adoption of such devices for non-contact vibrational response recordings of structures, allowing high spatial density measurements without the burden of heavy cabling associated with conventional technologies. This, however, is not a straightforward task due to the typically low-amplitude displacement response of structures under ambient operational conditions. A novel framework, namely Magnified Tracking (MT), is proposed herein to overcome this limitation through the synergistic use of two computer vision techniques. The recently proposed phase-based motion magnification (PBMM) framework, for amplifying motion in a video within a defined frequency band, is coupled with motion tracking by means of particle tracking velocimetry (PTV). An experimental campaign was conducted to validate a proof-of-concept, where the dynamic response of a shear frame was measured both by conventional sensors as well as a video camera setup, and cross-compared to prove the feasibility of the proposed non-contact approach. The methodology was explored both in 2D and 3D configurations, with PTV revealing a powerful tool for the measurement of perceptible motion. When MT is utilized for tracking “imperceptible” structural responses (i.e., below PTV sensitivity), via the use of PBMM around the resonant frequencies of the structure, the amplified motion reveals the operational deflection shapes, which are otherwise intractable. The modal results extracted from the magnified videos, using PTV, demonstrate MT to be a viable non-contact alternative for 3D modal identification with the benefit of a spatially dense measurement grid. Full article

Recent advances in computer vision techniques allow to obtain information on the dynamic behaviour of structures using commercial grade video recording devices. The advantage of such schemes lies in the non-invasive nature of video recording and the ability to extract information at a high spatial density utilizing structural features. This creates an advantage over conventional contact sensors since constraints such as cabling and maximum channel availability are alleviated. In this study, two such schemes are explored, namely Particle Tracking Velocimetry (PTV) and the optical flow algorithm. Both are validated against conventional sensors for a lab-scale shear frame and compared. In cases of imperceptible motion, the recently proposed Phase-based Motion Magnification (PBMM) technique is employed to obtain modal information within frequency bands of interest and further used for modal analysis. The optical flow scheme combined with (PBMM) is further tested on a large-scale post-tensioned concrete beam and validated against conventional measurements, as a transition from lab- to outdoor field applications. Full article

Industrial combustion processes are an important source of particulate matter, causing significant pollution problems that affect human health, and are a major contributor to global warming. The most common method for analyzing the soot emission propensity in flames is the Smoke Point Height (SPH) analysis, which relates the fuel flow rate to a critical flame height at which soot particles begin to leave the reactive zone through the tip of the flame. The SPH and is marked by morphological changes on the flame tip. SPH analysis is normally done through flame observations with the naked eye, leading to high bias. Other techniques are more accurate, but are not practical to implement in industrial settings, such as the Line Of Sight Attenuation (LOSA), which obtains soot volume fractions within the flame from the attenuation of a laser beam. We propose the use of Video Magnification techniques to detect the flame morphological changes and thus determine the SPH minimizing observation bias. We have applied for the first time Eulerian Video Magnification (EVM) and Phase-based Video Magnification (PVM) on an ethylene laminar diffusion flame. The results were compared with LOSA measurements, and indicate that EVM is the most accurate method for SPH determination. Full article
