Particle detectors at accelerators generate large amounts of data, requiring analysis to derive insights. Collisions lead to signal pile-up, where multiple particles produce signals in the same detector sensors, complicating individual signal identification. This contribution describes the implementation of a deep-learning algorithm on a Versal Adaptive Compute Acceleration Platform (ACAP) device for improved processing via parallelization and concurrency. Connected to a host computer via Peripheral Component Interconnect express (PCIe), this system aims for enhanced speed and energy efficiency over Central Processing Units (CPUs) and Graphics Processing Units (GPUs). In the contribution, we will describe in detail the data processing and the hardware, firmware and software components of the system. The contribution presents the implementation of the deep-learning algorithm on a Versal ACAP device, as well as the system for transferring data in an efficient way. Full article

This article addresses a novel methodology for the utilization of Field Programmable Gate Array (FPGA) accelerators in on-board Synthetic Aperture Radar (SAR) processing routines. The methodology consists of using High-Level Synthesis (HLS) to create Intellectual property (IP) blocks and using the Reusable Integration Framework for FPGA Accelerators (RIFFA) to develop a Peripheral Component Interconnect express (PCIe) interface between the Central Processing Unit (CPU) and the FPGA, attaining transfer rates up to 15.7 GB/s. HLS and RIFFA reduce development time (between fivefold and tenfold) by using high-level programming languages (e.g., C/C++); moreover, HLS provides optimizations like pipeline, cyclic partition, and unroll. The proposed schematic also has the advantage of being highly flexible and scalable since the IPs can be exchanged to perform different processing routines, and since RIFFA allows employing up to five FPGAs, multiple IPs can be implemented in each FPGA. Since Fast Fourier Transform (FFT) is one of the main functions in SAR processing, we present a FPGA accelerator in charge of the reordering stage of VEC-FFT (an optimized version of FFT) as a proof of concept. Results are retrieved in reversed bit order, and the conventional reordering function may consume more than half of the total clock cycles. Next, to demonstrate flexibility, an IP for matrix transposition is implemented, another computationally expensive process in SAR due to memory access. Full article

Methods of increasing complexity are currently being proposed for ultrasound (US) echographic signal processing. Graphics Processing Unit (GPU) resources allowing massive exploitation of parallel computing are ideal candidates for these tasks. Many high-performance US instruments, including open scanners like ULA-OP 256, have an architecture based only on Field-Programmable Gate Arrays (FPGAs) and/or Digital Signal Processors (DSPs). This paper proposes the implementation of the embedded NVIDIA Jetson Xavier AGX module on board ULA-OP 256. The system architecture was revised to allow the introduction of a new Peripheral Component Interconnect Express (PCIe) communication channel, while maintaining backward compatibility with all other embedded computing resources already on board. Moreover, the Input/Output (I/O) peripherals of the module make the ultrasound system independent, freeing the user from the need to use an external controlling PC. Full article

It is known that the data acquisition and processing system plays an important role in radar target detection system. In order to meet the requirements of real-time processing and accurate transmission of echo signals in high-frequency ground-wave radar (HFGWR) systems, a new acquisition and transmission framework utilizing the designed acquisition card based on the PCIe (peripheral component interconnect express) has been designed and is presented in this paper. The Xilinx FPGA (Field-Programmable Gate Array) chip Kintex7-XC7K325T is adopted as a hardware carrier in acquisition card. The hardware’s composition, analog front-end circuit, the DMA (Direct Memory Access) transmission, FPGA structure, ADC (Analog-to-Digital Converter) chip, and performance test of this card are showed and discussed. Currently, the acquisition card has been accomplished and applied in the practical system of HFGWR. Full article

This paper presents a fully integrated Peripheral Component Interconnect (PCI) Express (PCIe) Gen4 physical layer (PHY) transmitter. The prototype chip is fabricated in a 28 nm low-power CMOS process, and the active area of the proposed transmitter is 0.23 mm². To enable voltage scaling across wide operating rates from 2.5 Gb/s to 16 Gb/s, two on-chip supply regulators are included in the transmitter. At the same time, the regulators maintain the output impedance of the transmitter to meet the return loss specification of the PCIe, by including replica segments of the output driver and reference resistance in the regulator loop. A three-tap finite-impulse-response (FIR) equalization is implemented and, therefore, the transmitter provides more than 9.5 dB equalization which is required in the PCIe specification. At 16 Gb/s, the prototype chip achieves energy efficiency of 1.93 pJ/bit including all the interface, bias, and built-in self-test circuits. Full article
