To address the challenge of detecting debonding damage in glass-fiber-reinforced polymer (GFRP) rock bolt anchorage structures, this study proposes a time reversal detection method based on piezoelectric sensing and a Convolutional Neural Network–Support Vector Machine (CNN-SVM) model. Through COMSOL 6.1 numerical simulations and laboratory experiments, the influence of debonding length, location, and quantity on the characteristics of detection signals was investigated. The results indicate that an increase in debonding length leads to a rise in the amplitude of the focused signal, a reduction in the main peak frequency, and greater energy concentration around the main peak. Specifically, the amplitude increased by 10.96% (simulations) and 54.9% (experiments) for lengths from 0 to 1200 mm, while the peak frequency decreased by 3.43% (simulations) or increased slightly (experiments). When the debonding location changes, the amplitude remains stable, while the main peak frequency increases by 4.94% in simulations and shifts to higher frequencies experimentally, and the energy exhibits an increasing trend. An increase in the number of debonding points results in decreased amplitude, elevated main peak frequency, and more severe wave packet overlap. Multi-defect configurations reduced the amplitude by 16.68% (simulations) and 3% (experiments), with peak frequency increases of up to 3.35%. Based on these characteristics, a CNN-SVM evaluation model was constructed, using the wavelet time–frequency maps of experimental signals as input and the debonding state as output. The model achieved evaluation accuracy rates of 99%, 100%, and 100% under varying debonding lengths from 10 to 100 mm, different debonding positions, and increasing numbers of debonding defects, all exceeding 95%, thereby validating the reliability and high precision of the proposed method. Full article

Fully grouted rock bolts play a vital role in stabilising underground excavations, particularly in corrosive environments where material properties, geometric configuration, and installation conditions influence their load transfer performance. Although the practical importance of fully grouted fibreglass rock bolts is well recognised, quantitative evidence on their axial load transfer mechanisms remains limited. Prior work has primarily centred on steel rock bolts, with few studies on how embedment length, grout stiffness, interface roughness and confining stress govern bond mobilisation in fully grouted fibreglass rock bolts, indicating a clear need for further scientific investigation. This study examines the axial load transfer and shear behaviour of fully grouted fibreglass rock bolts, focusing on the effects of embedment length (EL), grout properties, and boundary conditions. A comprehensive series of laboratory pull-out tests were conducted on two widely used Australian glass fibre reinforced polymer (GFRP) rock bolts, TD22 and TD25, with diameters of 22 mm and 25 mm, respectively, under varying ELs and grout curing times to evaluate their axial performance. Additionally, single shear tests and uniaxial compressive strength (UCS) tests were conducted to assess the shear behaviour of the rock bolts and the mechanical properties of the grout. The results showed that increased EL, bolt diameter, and grout curing time generally enhance axial capacity. With grout curing from day 7 to the day 28, the influence of embedment length became increasingly pronounced, as the axial peak load rose from 35 kN (TD22-50, 7 days) to 116 kN (TD22-150, 28 days) and from 39 kN (TD25-50, 7 days) to 115 kN (TD25-150, 28 days), confirming that both longer bonded lengths and extended curing significantly enhance the axial load-bearing capacity of fully grouted GFRP rock bolts. However, the TD22 rock bolts exhibited superior shear strength and ductility compared to the TD25 rock bolts. Also, a calibrated distinct element model (DEM) was developed in 3DEC to simulate axial load transfer mechanisms and validated against experimental results. Parametric studies revealed that increasing the grout stiffness from 5 e7 N/m to 5 e8 N/m increased the peak load from 45 kN to 205 kN (approximately 350%), while reducing the peak displacement, indicating a shift toward a more brittle response. Similarly, increasing the grout-bolt interface roughness boosted the peak load by 150% (from 60 kN to 150 kN) and enhanced residual stability, raising the residual load from 12 kN to 93.5 kN. In contrast, confining stress (up to 5 MPa) did not affect the 110 kN peak load but reduced the residual load by up to 60% in isotropic conditions. These quantitative findings provide critical insights into the performance of GFRP bolts and support their optimised design for underground reinforcement applications. Full article

Currently, resin polymer anchoring agents are widely used for bolting support in coal mine roadways to anchor the bolts to the surrounding rock mass. However, due to the relatively low strength of the resin anchoring agent itself, the required anchoring length tends to be excessively long. Based on this, this paper proposes the use of resin concrete as a replacement for resin. Compared to resin anchoring agents, resin concrete offers greater mechanical interlocking force with anchor rods, which can reduce the theoretical anchoring length. To systematically investigate the influence of factors such as the diameter and anchorage length of Glass Fiber-Reinforced Polymer (GFRP) bolt on the bond behavior between GFRP bolts and resin concrete, 33 standard pull-out tests were designed and conducted in accordance with the CSA S807-19 standard. Taking the 18 mm-diameter bolt as an example, when the bond lengths were 2D, 3D, 4D, and 5D, the average bond strengths were 41.32 MPa, 39.18 MPa, 38.84 MPa, and 37.44 MPa, respectively. This represents a decrease of 5.18%, 6.00%, and 9.39% for each subsequent increase in bond length. The results indicate that the bond strength between GFRP anchors and resin decreases as the anchorage length increases. Due to the shear lag effect, the average bond strength also decreases with increasing anchor diameter. Taking a 5D (where D is the anchor diameter) anchorage length as a reference, the average bond strengths for anchor diameters of 18 mm, 20 mm, 22 mm, and 24 mm were 37.44 MPa, 33.97 MPa, 32.18 MPa, and 31.50 MPa, respectively. The corresponding reductions compared to the 18 mm diameter case were 9.27%, 14.05%, and 15.87%. Based on the experimental results, this paper proposes a bond–slip constitutive model between the bolt and resin concrete, which consists of a rising branch, a descending branch, and a residual branch. A differential equation relating shear stress to displacement was established, and the functions describing the variation in displacement, normal stress, and shear stress along the position were solved for the ascending branch. Although an analytical solution for the differential equation of the descending branch was not obtained, it will not affect the subsequent derivation of the theoretical anchorage length for the GFRP bolt–resin concrete system, as structural components in practical engineering are not permitted to undergo excessive bond-slip. Full article

As a new type of pre-reinforcement material for tunnel faces, glass fiber-reinforced polymer (GFRP) bolts can effectively and safely improve the stability of tunnel faces in soft surrounding rocks and speed up excavation. Therefore, in this paper, systematic research is carried out on the bond strength of GFRP bolts in tunnel faces and their relative pre-reinforcement parameters. Firstly, the effects of rebar diameter, anchorage length, and mortar strength on the bonding properties of GFRP bars were studied by indoor pull-out tests. The bond strength–slip curves under different working conditions were obtained, and the curves showed that the ultimate bond strength between GFRP bars and mortar was negatively correlated with the diameter of GFRP bars but positively correlated with the strength of the mortar. In addition, the increase in anchorage length led to a reduction in bonding strength. Secondly, inverse analysis was used to analyse the mechanical parameters of the bond performance of the anchor bars by the finite difference software FLAC3D, and the results indicated that 1/5 of the compressive strength of the GFRP bar grouting body can be taken as the ultimate bond strength to calculate the cohesive strength of the grout. Additionally, the formula of GFRP bar grouting body stiffness was revised. Finally, based on the results of laboratory tests and the inverse analysis, the numerical simulation analysis results showed that the optimal reinforcement configuration for a shallow buried tunnel face surrounded by weak rock is to use GFRP bars with a length of 17 m arranged in the center circle of the tunnel face with a reasonable reinforcement density of 1.0 bolt/m². The calculation formula of the stiffness and cohesion strength of the GFRP bar grouting body and the reinforcement scheme proposed in this paper can provide a reference for the construction of shallowly buried rock tunnels in soft surrounding rock. Full article
