Search Results (3)

Search Parameters:
Keywords = Fabry-Perot cavity antenna (FPCA)

Order results
Result details
Results per page
Show export options expand_more Show export options expand_less
Select all
Export citation of selected articles as:
12 pages, 2147 KiB
Article
Two-Dimensional Scanning of Circularly Polarized Beams via Array-Fed Fabry–Perot Cavity Antennas
by Mikhail Madji, Edoardo Negri, Walter Fuscaldo, Davide Comite, Alessandro Galli and Paolo Burghignoli
Appl. Sci. 2024, 14(24), 12058; https://doi.org/10.3390/app142412058 - 23 Dec 2024
Cited by 1 | Viewed by 933
Abstract
In this paper, we present an array-fed Fabry–Perot cavity antenna (FPCA) based on a partially reflecting sheet (PRS) capable of generating a circularly polarized (CP), highly directive, far-field radiation pattern in the 27–28.5 GHz frequency range. The PRS, the cavity, and the array [...] Read more.
In this paper, we present an array-fed Fabry–Perot cavity antenna (FPCA) based on a partially reflecting sheet (PRS) capable of generating a circularly polarized (CP), highly directive, far-field radiation pattern in the 27–28.5 GHz frequency range. The PRS, the cavity, and the array of feeders serve to different purposes in this original structure. The PRS is engineered to produce a circular polarization from a linearly polarized source placed inside the cavity. The cavity is optimized to obtain a directive conical beam from the dipole-like pattern of the simple source, and allows for a frequency scan of the beam along the elevation plane. The array of feeders is designed to obtain a pencil beam whose azimuthal pointing direction can be controlled by properly phasing the sources. The radiation performance is studied with a specific application of the reciprocity theorem in a full-wave solver along with the pattern multiplication principle. A number of array-pattern configurations in terms of operation frequency and phase shift are investigated and presented to show the potential of the proposed solution in terms of design flexibility and radiation performance. Full article
(This article belongs to the Special Issue Feature Paper Collection in the Section ‘Electrical, Electronics and Communications Engineering’)
►▼ Show Figures

Figure 1

11 pages, 7232 KiB
Article
Circularly Polarized High-Gain Fabry-Perot Cavity Antenna with High Sidelobe Suppression
by Muhammad Hussain, Kyung-Geun Lee and Dongho Kim
Appl. Sci. 2023, 13(14), 8222; https://doi.org/10.3390/app13148222 - 15 Jul 2023
Cited by 2 | Viewed by 2423
Abstract
The proposed design approach improves the circularly polarized Fabry-Perot cavity antenna (CP-FPCA) by increasing gain and sidelobe suppression (SLS) while reducing the axial ratio (AR) and cross-polarization levels. Conventional CP-FPC antennas have a high AR due to the lack of independent control over [...] Read more.
The proposed design approach improves the circularly polarized Fabry-Perot cavity antenna (CP-FPCA) by increasing gain and sidelobe suppression (SLS) while reducing the axial ratio (AR) and cross-polarization levels. Conventional CP-FPC antennas have a high AR due to the lack of independent control over circular polarization conditions. The solution proposes a double-layered circularly polarized partially reflecting surface (CP-PRS) that independently controls the circular polarization conditions at the design frequency f0 (10 GHz) for equal magnitudes and at a ±90° phase difference between orthogonal components of the transmitted waves. The PRS and artificial magnetic conductor (AMC) unit cells are employed to satisfy Trentini’s beamforming condition, leading to increased gain and SLS and lowered AR and cross-polarization levels. Consequently, the proposed CP-FPCA provides a 15.4 dBi high gain with 25.3% aperture efficiency and more than 23.5 dB high SLS in each plane. Moreover, it achieves an AR lowered by 0.12 dB and a cross-polarization level below −42 dB. A strong correlation between the simulations and experiments proves the practicality of our proposal. Full article
(This article belongs to the Section Electrical, Electronics and Communications Engineering)
►▼ Show Figures

Figure 1

10 pages, 72923 KiB
Article
Dual-Band High-Gain Shared-Aperture Antenna Integrating Fabry-Perot and Reflectarray Mechanisms
by Xianjin Yi, Lin Zhou, Shuji Hao and Xing Chen
Electronics 2022, 11(13), 2017; https://doi.org/10.3390/electronics11132017 - 27 Jun 2022
Cited by 3 | Viewed by 2936
Abstract
This work presents a dual-band high-gain shared-aperture antenna. The proposed antenna integrates both the Fabry-Perot and reflectarray mechanisms; the antenna works as a Fabry-Perot cavity antenna (FPCA) in the S-band (2.45 GHz) and as a reflectarray antenna (RA) in the X-band [...] Read more.
This work presents a dual-band high-gain shared-aperture antenna. The proposed antenna integrates both the Fabry-Perot and reflectarray mechanisms; the antenna works as a Fabry-Perot cavity antenna (FPCA) in the S-band (2.45 GHz) and as a reflectarray antenna (RA) in the X-band (10 GHz). The antenna has a simple structure made up of only two printed circuit board layers. The bottom layer acts as a source antenna, a ground plane for the FPCA, and as a reflective surface for the RA. The upper layer contains the source antenna for the RA and serves as a partially reflective superstrate for the FPCA. The FPCA and RA thus share the same physical aperture but function independently. As an example, we design, fabricate, and characterize an antenna that operates at 2.45 and 10 GHz with an aperture size of 300 × 300 mm2. The measured results are found to be in good agreement with the simulations. We show that the proposed antenna achieves a gain of 16.21 dBi at 2.45 GHz and 21.6 dBi at 10 GHz with a −10 dB impedance bandwidths of 2.39–2.66 GHz and 9.40–10.28 GHz. The isolation between the two antenna ports is found to be larger than 30 dB. Full article
(This article belongs to the Topic Antennas)
►▼ Show Figures

Figure 1

Show export options expand_more Show export options expand_less
Select all
Export citation of selected articles as:

Displaying article 1-50 on page 1 of 1.
