The Lightning Mapping Imager (LMI) onboard the Fengyun-4A (FY-4A) satellite is the first independently developed satellite-borne lightning imager in China. It enables continuous lightning detection in China and surrounding areas, regardless of weather conditions. The FY-4A LMI uses a Charge-Coupled Device (CCD) array for lightning detection, and the accuracy of lightning positioning is influenced by cloud top height (CTH). In this study, we proposed an ellipsoid CTH parallax correction (ECPC) model for lightning positioning applicable to FY-4A LMI. The model utilizes CTH data from the Advanced Geosynchronous Radiation Imager (AGRI) on FY-4A to correct the lightning positioning data. According to the model, when the CTH is 12 km, the maximum deviation in lightning positioning caused by CTH in Beijing is approximately 0.1177° in the east–west direction and 0.0530° in the north–south direction, corresponding to a horizontal deviation of 13.1558 km, which exceeds the size of a single ground detection unit of the geostationary satellite lightning imager. Therefore, it is necessary to be corrected. A comparison with data from the Beijing Broadband Lightning Network (BLNET) and radar data shows that the corrected LMI data exhibit spatial distribution that is closer to the simultaneous BLNET lightning positioning data. The coordinate differences between the two datasets are significantly reduced, indicating higher consistency with radar data. The correction algorithm decreases the LMI lightning location deviation caused by CTH, thereby improving the accuracy and reliability of satellite lightning positioning data. The proposed ECPC model can be used for the real-time correction of lightning data when CTH is obtained at the same time, and it can be also used for the post-correction of space-based lightning detection with other cloud top height data. Full article

The Lightning Mapping Imager (LMI) onboard the geostationary meteorological satelliteFengYun-4A (FY-4A) detects both intra-cloud (IC) and cloud-to-ground (CG) lightning continuously during daytime and nighttime. This study examined, for the first time, the optical characteristics and distribution of the “Event,” “Group,” and “Flash” observed by the LMI in the whole LMI observation domain. The optical properties and spatial distribution of the LMI lightning were compared with those of the Lightning Imaging Sensor on the International Space Station (ISS-LIS) based on the dataset during 2018–2020. Due to the different spatial resolutions and detection efficiencies of these two lightning imagers, the number of ISS-LIS lightning was more than that of LMI lightning. The ISS-LIS Flash duration was also larger than that of the LMI Flash. The duration, radiance, and footprint of LMI lightning in different regions were analyzed in detail based on the LMI lightning dataset in 2019. The duration and radiance of the Flash were generally less than 50–500 ms and 200 Jm⁻²ster⁻¹μm⁻¹, respectively. The footprint of Flashes was distributed from 200 to 600 km². The number of Groups per Flash was mostly less than five. Considering the spatial distribution and temporal variations in the LMI lightning compared with the ground-based Lightning Location Network in China (LLNC), it was found that the LMI Group number was close to the LLNC CG (Cloud-to-Ground) Event number. The maximum Flash density was found in the middle and lower south of the Yangtze River and Pearl River Delta region, respectively, while the lower values were in western China, where the mean radiance per Flash was greater. There was more LMI lightning during the nighttime than that during the daytime, indicating the higher detection efficiency of the LMI in the nighttime than in the daytime. Full article

In this study, the effect of day/night factor on the detection performance of the FY4A lightning mapping imager (LMI) is evaluated using the Bayesian theorem, and by comparing it to the measurements made by a ground-based low-frequency magnetic field lightning location system. Both the datasets were collected in the summers of 2019–2020 in Hainan, China. The results show that for the observed summer thunderstorms in Hainan, the daytime detection efficiencies of LMI (DE_LMI) were 20.41~35.53% lower than the nighttime DE_LMI. Compared to other space-based lightning sensors (lightning imaging sensors/optical transient detectors (LIS/OTD) and geostationary lightning mapper (GLM)), the detection performance of LMI is more significantly influenced by the day/night factor. The DE_LMI rapidly dropped within about four hours after sunrise while it increased before sunset. For the storms that formed at night and lasted for an entire day, the DE_LMI remained relatively low during the daytime, even as the thunderstorms intensified. The poor detection performance of LMI during daytime is probably because of the sunlight reflection by clouds and atmosphere, which results in larger background radiative energy density (RED) than that at night. During night, LMI captured the lightning signals well with low RED (8.38~10.63 μJ sr⁻¹ m⁻² nm⁻¹). However, during daytime, signals with RED less than 77.12 μJ sr⁻¹ m⁻² nm⁻¹ were filtered, thus lightning groups could rarely be identified by LMI, except those with extremely high RED. Due to the limitations of the Bayesian theorem, the obtained DE in this study was “relative” DE rather than “absolute” DE. To obtain the absolute DE of LMI, the total lightning density is necessary but can hardly be measured. Nonetheless, the results shown here clearly indicate the strong impact of day/night factor on the detection performance of LMI, and can be used to improve the design and post-processing method of LMI. Full article

In this study, a new moving amplification matching algorithm was proposed, and then the temporal and spatial differences and correlation were analysed and evaluated by comparing the FengYun-4A Lightning Mapping Imager (FY-4A LMI) data and the China Meteorological Administration Lightning Detection Network Advanced TOA and Direction (CMA-LDN ADTD) system data of southwest China in July 2018. The results are as follows. Firstly, the new moving amplification matching algorithm could effectively reduce the number of invalid operations and save the operation time in comparison to the conventional ergodic algorithms. Secondly, LMI has less detection efficiency during the daytime, using ADTD as a reference. The lightning number detected by ADTD increased from 5:00 AM UTC (13:00 PM BJT, Beijing Time) and almost lasted for a whole day. Thirdly, the trends of lightning data change of LMI and ADTD were the same as the whole. The average daily lightning matching rate of the LMI in July was 63.23%. The average hourly lightning matching rate of the LMI in July was 75.08%. Lastly, the mean value of the spherical surface distance in the matched array was 35.49 km, and roughly 80% of the matched distance was within 57 km, indicating that the spatial threshold limit was relatively stable. The correlation between LMI lightning radiation intensity and ADTD lighting current intensity was low. Full article

The Fengyun-4A (FY-4A) Lightning Mapping Imager (LMI) is the first satellite-borne lightning imager developed in China, which can detect lightning over China and its neighboring regions based on a geostationary satellite platform. In this study, the spatial distribution and temporal variation characteristics of lightning activity over China and its neighboring regions were analyzed in detail based on 2018 LMI observations. The observation characteristics of the LMI were revealed through a comparison with the Tropical Rainfall Measuring Mission (TRMM)-Lightning Imaging Sensor (LIS) and World Wide Lightning Location Network (WWLLN) observations. Moreover, the optical radiation characteristics of lightning signals detected by the LMI were examined. Factors that may affect LMI detection were discussed by analyzing the differences in optical radiation characteristics between LMI and LIS flashes. The results are as follows. Spatially, the flash density distribution pattern detected by the LMI was similar to those detected by the LIS and WWLLN. High-flash density regions were mainly concentrated over Southeastern China and Northeastern India. Temporally, LMI flashes exhibited notable seasonal and diurnal variation characteristics. The LMI detected a concentrated lightning outbreak over Northeastern India in the premonsoon season and over Southeastern China in the monsoon season, which was consistent with LIS and WWLLN observations. LMI-observed diurnal peak flash rates occurred in the afternoon over most of the regions. There was a “stepwise” decrease in the LMI-observed optical radiance, footprint size, duration, and number of groups per flash, from the ocean to the coastal regions to the inland regions. LMI flashes exhibited higher optical radiance but lasted for shorter durations than LIS flashes. LMI observations are not only related to instrument performance but are also closely linked to onboard and ground data processing. In future, targeted improvements can be made to the data processing algorithm for the LMI to further enhance its detection capability. Full article

As the first Geostationary Satellite with the LMI (Lightning Mapping Imager) instrument aboard running over the eastern hemisphere, FY-4A (Feng-Yun-4A) can better indicate severe convection and compensate for the limitations of radar observation in temporal and spatial resolution. In order to realize the application of FY-4A lightning data in numerical weather prediction (NWP) models, a logarithmic relationship between FY-4A lightning density and maximum radar reflectivity is presented to convert FY-4A lightning data into maximum FY-4A proxy reflectivity. Then, according to the profiles of radar reflectivity, the maximum FY-4A proxy reflectivity is extended to 3D FY-4A proxy reflectivity. Finally, the 3D FY-4A proxy reflectivity is assimilated in RMAPS-ST (Rapid-refresh Multi-scale Analysis and Prediction System—Short Term) to compare with radar assimilation. Four groups of continuous cycling data assimilation and forecasting experiments are carried out for a severe rainfall case. The results demonstrate that cycling assimilation of 3D FY-4A proxy reflectivity can adjust the moisture condition effectively, and indirectly affects the temperature and wind fields, then makes the thermal and dynamic analysis more reasonable. The Fractions Skill Scores (FSSs) show that the rainfall forecasts are improved significantly within 6 h by assimilating 3D FY-4A proxy reflectivity, which is similar to the parallel experiments in assimilating radar reflectivity. In addition, other cycling data assimilation experiments are carried out in mountainous areas without radar data. The improvement of precipitation forecasts in mountainous areas further proves that the application of assimilating 3D FY-4A proxy reflectivity can be considered a useful substitute where observed radar data are missing. Through the two severe rainfall cases, this method could be framed as an example of how to use lightning for data assimilation. Full article
