Derailments pose a significant threat to high-speed rail safety. The development of effective derailment containment provisions (DCPs) that can be installed within a track gauge and withstand impact loads of derailed wheels while controlling the lateral movement of derailed trains is essential. This paper presents an experimental study on the behavior of reinforced concrete (RC) DCP systems under quasi-static loading. Three steel anchors were assessed for their performance and load-bearing capacity in a single-anchor test. Four full-scale DCP system tests were carried out to examine the effects of scenarios of impact load positions at the anchor and mid-span of the DCPs. The crack pattern, failure mechanism, load–displacement relationship, initial stiffness, and absorber energy capacity of the DCP specimens were acquired. The findings reveal that the failure mode of the DCP specimens was predominantly affected by the tension failure of the steel anchors. The load-carrying capacity and performance equivalent of the DCP system under the applied load scenarios significantly exceeded the design load, ranging from 125% to 168%. Also, the initial stiffness of the DCP system remains largely unaffected by the applied load positions, whereas the absorption energy capacity exhibits a contrasting trend. Full article

Railway derailments present a safety hazard, carrying the potential for severe consequences for both human lives and the economy. Implementing derailment containment provisions (DCPs) near the track centerline is essential for mitigating risks in operating high-speed rail (HSR) while providing significant advantages for the large-scale upgrade of existing railway infrastructure. Therefore, this paper investigated the feasibility of a DCP system made of steel through quasi-static experiments, aiming to enhance safety in HSR operations. Initially, single anchor tests were conducted to assess its capacity to withstand applied loads, prevent the pullout of steel anchors, and avoid the local rotation of the steel frame. Then, full-scale steel DCP systems were manufactured and tested for quasi-static load at different locations, including the mid-anchor, the mid-span, and the end-anchor. The relationship between applied load and displacement, along with the initial stiffness of the DCP specimens, was discussed. The findings revealed that the single anchor can withstand an applied load of up to 197.9 kN. The DCP specimen maintained structural integrity at the 207 kN target load under all load scenarios, showing a maximum displacement of 8.93 mm in the case of applied load at mid-span. Furthermore, the initial stiffness of the DCP systems was 1.77 to 2.55 times greater than that of a single anchor, validating a force-bearing coordination mechanism among neighboring anchors and the substantial impact of the applied load positions on their stiffness. Full article

This study proposes a theoretical method to estimate the impact force of Derailment Containment Provisions (DCPs) for the prevention of secondary collisions in the event of a train derailment. By comparing the impact forces estimated using the commonly used Olson model and dynamic simulations, the study identifies significant differences in average and maximum impact forces. The study shows that these differences arise due to the mass effects of vehicle bodies transmitted to the DCP during a collision. To address this issue, the impact force of the Olson model was modified by considering the stiffness of suspensions between masses as a simplified spring–mass model. The modified impact force was verified through impact simulations using the KTX model on curved tracks with various radii. The results show that the modified Olson model provides a reasonable estimate of the impact force, with differences of less than 8% observed under all simulation conditions. This study provides a valuable contribution to the design and analysis methodology for DCPs, improving their effectiveness in preventing secondary collisions and enhancing railway safety. Full article

In order to reduce the large damage caused by train derailment, protective facilities of various shapes and conditions can be installed on railroad tracks. These protective facilities are referred to as derailment containment provisions (DCPs) and three different types are used worldwide. However, there are no clear standards for DCP design such as installation location, size, and design load, and the performance verification of DCPs installed in the actual railway field is not sufficiently performed. In this paper, the functionality of DCP type I was analyzed experimentally. A method for estimating the collision (impact) load acting on the DCP was proposed. In addition, the containment effect of DCP type I according to the change in the vehicle’s center of gravity was identified through a comparative analysis of the dynamic motion such as roll, pitch, and yaw. Full article

As the operating speed of a train increases, there is a growing interest in reducing damage caused by derailment and collision accidents. Since a collision with the surrounding structure after a derailment accident causes a great damage, protective facilities like a barrier wall or derailment containment provision (DCP) are installed to reduce the damage due to the secondary collision accident. However, the criteria to design a protective facility such as locations and design loads are not clear because of difficulties in predicting post-derailment behaviors. In this paper, we derived a simplified frame model that can predict post derailment behaviors in the design phase of the protective facilities. The proposed vehicle model can simplify for various frames to reduce the computation time. Also, the actual derailment tests were conducted on a real test track to verify the reliability of the model. The simulation results of the proposed model showed reasonable agreement to the test results. Full article
