Compared with cubic Continuously Variable Crown (CVC), quintic CVC presents integrated control capability of quadratic and quartic crown. In order to take full advantage of quintic CVC and have better comprehensive control of the edge wave, center wave, high order wave and complex wave in practical application, it is necessary to further clarify the complicated profile control characteristics of quintic CVC. In this paper, quintic CVC technology in a 1500 mm continuous hot rolling mill production line has been taken as the research object and use finite element method to study its profile control characteristics. Through finite element simulation, an integrated model of rolls and strip was established to analyze the influence of the shifting, bending force and rolling force on strip profile with different strip widths. Both crown adjustment area and transverse stiffness are gained to study the control capability of quintic CVC. The simulation results show that the positive shifting and positive bending of CVC work roll reduce the quadratic crown and increase the quartic crown, and the controlling effect of shifting on both quadratic and quartic crown is more remarkable than that of bending. The control capability of the crown increases with the increase of strip width. That is, wider strip has a larger crown adjustment area. Meanwhile, there is a strong coupling relationship that the increase of quadratic crown can lead to the decrease of the quartic crown, which is not good for the flexible control of strip profile. With the increase of rolling force, the quadratic crown of strip increases significantly, while the quartic crown does not change obviously. Additionally, the increase of strip width significantly increases the transverse stiffness of mill. Full article

The back-up rolls of hot strip mills wear considerably under the conditions of high temperature and heavy load, which affects the roll service period and the stability of strip profile control. Serious uneven wear, short service periods, and spalling problems occurred on conventional back-up rolls of upstream stand CVC mills in 1500 mm continuous hot rolling production lines. Through finite element simulations, the problems are determined to be caused by the configuration of a flat roll contour of the back-up roll and the CVC roll contour of the work roll, which leads to uneven contact pressure between the rolls. The wear distribution form is ‘anti-CVC’ shape, and there is peak contact pressure between the rolls on both sides of the roll body. In particular, the long-term negative shifting of CVC on site further increases the peak contact pressure between the rolls, resulting in uneven wear and spalling accident. Based on the design technology of VCR back-up roll contours with variable contact lengths, and considering the cooperation between the middle of the back-up roll and the CVC work roll contour, the roll contour of the back-up roll has been improved. The designed VCRplus roll contour was analyzed and evaluated by finite element simulation, including the distribution of contact pressure between rolls, the control effect of bending force, and the transverse stiffness of the roll gap. The simulation results show that the VCRplus roll contour can effectively improve the uneven distribution of contact pressure between the rolls, and effectively improve the control effect of bending force and the transverse stiffness of the roll gap. Industrial tests demonstrate that VCRplus back-up roll contours have the advantages of uniform back-up roll wear, enhanced self-sustaining of the roll contour, and further extension of the back-up roll service life. The roll contour has now stably been put into industrial production, and the rolling capacity during the back-up roll service period has been extended from 150,000,000 kg to 250,000,000 kg. Full article

Quarter wave defects often occur in high-strength steel production in wide rolling mills, which seriously affect product quality and production stability. The existing shape control actuators, such as roll bending, roll shifting, and CVC roll shape, can not adjust the high-order wave, and the upgraded CVCplus roll shape also has limited effects on the quarter wave. Therefore, the MVCplus roll shape is developed based on the superposition principle in order to realize the local roll shape modification at the wave position. Two cosine curves are superposed on the CVC roll shape within the strip width to decrease the reduction at the quarter of the strip width, and maximum reduction is achieved at the position of maximum wave height. The new roll shape can significantly reduce the quarter wave defects in practical application, and has little effect on the adjustment characteristics of the original CVC roll shape. Full article
