The automated process chain of an unmanned production system is a distinct challenge in the technical state of the art. In particular, accurate and fast raw-part recognition is a current problem in small-batch production. This publication proposes a method for automatic optical raw-part detection to generate a digital blank shadow, which is applied for adapted CAD/CAM (computer-aided design/computer-aided manufacturing) planning. Thereby, a laser-triangulation sensor is integrated into the machine tool. For an automatic raw-part detection and a workpiece origin definition, a dedicated algorithm for creating a digital blank shadow is introduced. The algorithm generates adaptive scan paths, merges laser lines and machine axis data, filters interference signals, and identifies part edges and surfaces according to a point cloud. Furthermore, a dedicated software system is introduced to investigate the created approach. This method is integrated into a CAD/CAM system, with customized software libraries for communication with the CNC (computer numerical control) machine. The results of this study show that the applied method can identify the positions, dimensions, and shapes of different raw parts autonomously, with deviations less than 1 mm, in 2.5 min. Moreover, the measurement and process data can be transferred without errors to different hardware and software systems. It was found that the proposed approach can be applied for rough raw-part detection, and in combination with a touch probe for accurate detection. Full article

STEP-NC (Standard for the Exchange of Product Model Data–Numerical Control) for metal milling and turning is not implemented by industrial computer numerical controllers. Solutions reported are prototypes based on post-processing in G-code. Moreover, minority machining processes, such as stone cutting, have not yet been contemplated in the STEP-NC standard. This article takes that sector as a use case. An extended STEP-NC model for circular saw stone-cutting operations is proposed, and a prototype automation implementation is developed to work with this extended model. This article shows how modern technological resources for coordinated axes control provided by many industrial controllers for the automation of general-purpose machines can speed up the processes of implementing STEP-NC numerical controllers. This article proposes a mixed and flexible approach for STEP-NC-based machine automation, where different strategies can coexist when it comes to executing STEP-NC machining files, so controllers do not need to implement the standard in an exhaustive way for all the possible features, but only at selected ones when convenient. This is demonstrated in a prototype implementation which is able to process STEP-NC product files with mixed-feature types: standard milling and non-standard sawblade features for stone processing. Full article

Wire Arc Additive Manufacturing (WAAM) has emerged over the last decade and is dedicated to the realization of high-dimensional parts in various metallic materials. The usual process implementation consists in associating a high-performance welding generator as heat source, a NC controlled 6 or 8 degrees (for example) of freedom robotic arm as motion system and welding wire as feedstock. WAAM toolpath generation methods, although process specific, can be based on similar approaches developed for other processes, such as machining, to integrate the process data into a consistent technical data environment. This paper proposes a generic multiaxis tool path generation approach for thin wall structures made with WAAM. At first, the current technological and scientific challenges associated to CAD/CAM/CNC data chains for WAAM applications are introduced. The focus is on process planning aspects such as non-planar non-parallel slicing approaches and part orientation into the working space, and these are integrated in the proposed method. The interest of variable torch orientation control for complex shapes is proposed, and then, a new intersection crossing tool path method based on Design For Additive Manufacturing considerations is detailed. Eventually, two industrial use cases are introduced to highlight the interest of this approach for realizing large components. Full article

A STEP-NC or ISO 14649 compliant machine controller is developed, using Open Architecture Control technology for a three-axis Computer Numerical Control milling machine in this research. The controller is developed on a Raspberry Pi single-board computer, using C++ language. This new development is proposed as a low-cost alternative to ISO6983 standard, ensuring continuous integration in the CAD/CAM/CNC chain in machining; thus, it broadens the spectrum of problems handled by conventional CNC systems. The new machine controller is intelligent enough to extract geometrical and manufacturing parameters, cutting tool data, and material data from the STEP-NC file. Accordingly, tool paths for machining can be generated in the controller itself. The shop floor level modification of parameters and the possibility of regeneration of new toolpaths is an added advantage of this new controller. The modified or improved version of the STEP-NC file can be sent back to the CAD/CAM system to close the CAD/CAM/CNC chain. Machine condition monitoring can be achieved by connecting sensors through an available slave I/O board. In the present development, the current drawn by each servo motor is fed back to the controller for cutting condition monitoring. A laboratory scale three-axis CNC milling machine is developed to test the performance of the newly developed controller. The accuracy of positioning, perpendicularity of axes and linearity of this machine are experimentally verified through standard tests. The STEP-NC compliance of the controller is tested and verified, using a STEP-NC program derived based on a sample program given in ISO 14649 standard. Full article
