The energy absorption capacity of materials with negative Poisson’s ratio (NPR) is attracting interest from both industry and academia due to the excellent impact resistance of the local shrinkage of materials. However, understanding the compressive behavior of 3D auxetic structures at different strain rates and developing design methods are challenging tasks due to the limited literature and insufficient data. This paper presents a study on the behavior of Poisson’s ratio of an advanced 3D chiral structure, which is formed of two orthogonally positioned 2D hexagonal nodes-based chiral structures. Firstly, both theoretical analysis and numerical simulations are conducted to identify the Poisson’s ratio of 2D chiral structures. The same theoretical value of −1 is obtained for 2D chiral structures with a bending-dominated ligaments assumption. Thereafter, the Poisson’s ratio of 3D chiral structures is determined numerically using a low-speed loaded model composed of 5 × 5 × 8 3D unit cells for eliminating the boundary effects. The results show that impact velocity can strongly affect the energy absorption and deformation behavior of the proposed 3D chiral structure. Increasing the beam radius results in reduced energy absorption capability. However, the energy absorption capability of the 3D chiral structure is not sensitive to the yield strength of nodes. Impact direction affects the energy absorption performance of the 3D chiral structure, depending on the crushing strain. The research results could be used to optimize the design of the proposed novel 3D chiral honeycombs for various applications, such as impact energy absorbers and vibration-resistant dampers. Full article

To evaluate the electrical heating performance by auxetic pattern, re-entrant honeycomb (RE), chiral truss (CT), honeycomb (HN), and truss (TR), using graphene/PLA (Polylactic acid) filament, were manufactured by CFDM (conveyor fused deposition modelling) 3D printer. In addition, HN and TR, which was indicated to have an excellent electrical heating property, were selected to verify the feasibility of applying fabric heating elements. The result of morphology was that the number of struts constituting the unit cell and the connected points were TR < HN < CT < RE. It was also influenced by the surface resistivity and electrical heating performance. RE, which has the highest number of struts constituting the unit cell and the relative density, had the highest value of surface resistivity, and the lowest value was found in the opposite TR. In the electrical heating performance of samples, the heat distribution of RE was limited even when the applied voltage was increased. However, HN and TR were diffused throughout the sample. In addition, the surface temperature of RE, CT, HN, and TR was about 72.4 °C, 83.1 °C, 94.9 °C, and 85.9, respectively as applied at 30 V. When the HN and TR were printed on cotton fabric, the surface resistivity of HN/cotton and TR/cotton was about 10³ Ω/sq, which showed conductive material. The results of electrical heating properties indicated that the heat distribution of HN/cotton showed only in the region where power was supplied, but the TR/cotton was gradually expanded and presented stable electric heating properties. When 30 V was applied, the surface temperature of both samples showed more than 80 °C, and the shape was maintained stably due to the high thermal conductivity of the cotton fabric. Therefore, this study ensured that HN and TR show excellent electrical heating performance among four types of auxetic patterns with continuity. Full article

Our research investigated the energy absorption characteristics of chiral auxetic lattices filled cylindrical composite tubes subjected to a uniaxial and lateral quasi-static load. The lattice structures were manufactured using a 3D printing technique. Carbon fiber composite tubes without filler material were initially subjected to uniaxial and lateral quasi-static crushing load. The same types of experiment were then performed on chiral lattices and chiral lattices filled composite tubes. For the different cases, the load–displacements curves were analyzed and the specific energy absorption (SEA) values were compared. The SEA capability for the axial quasi-static crushing of the chiral lattices filled composite tubes decreased in comparison with the hollow composite design. However, the most significant result was that the average SEA value in the case of lateral loading increased dramatically in comparison with the hollow composite configuration. Full article

The mechanical behaviour of three different auxetic cellular structures, hexa-chiral 2D, tetra-chiral 2D and tetra-chiral 3D, was experimentally investigated in this study. The structures were produced with the powder bed fusion method (PBF) from an austenitic stainless steel alloy. The fundamental material mechanical properties of the sample structures were determined with classic quasi-static compressive tests, where the deformation process was captured by a high-resolution digital camera. The Split Hopkinson Pressure Bar (SHPB) apparatus was used for dynamic impact testing at two impact velocities to study the strain-rate dependency of the structures. Two synchronised high-speed cameras were used to observe the impact tests. The captured images from both quasi-static and dynamic experiments were processed using a custom digital image correlation (DIC) algorithm to evaluate the displacement/strain fields and the Poisson’s ratio. Predominant auxetic behaviour was observed in all three structures throughout most of the deformation process both under quasi-static and impact loading regimes. The tetra-chiral 2D structure showed the most significant auxetic behaviour. Significant stress enhancement in all tested structures was observed in dynamic testing. The Poisson’s ratio strain-rate dependency was confirmed for all three auxetic structures. Full article
