This study investigated the feasibility and effectiveness of a commercial top-down stereolithography (SLA)-based system for the additive manufacturing of zirconia dental prostheses. Yttria-stabilized zirconia–resin slurries were prepared, and zirconia objects were fabricated using a top-down SLA system. Thermogravimetric–differential thermal analysis was used to examine the resin, while X-ray fluorescence spectroscopy and X-ray diffraction were used to analyze the printed samples. The microstructures of additively manufactured and subtractively manufactured zirconia were compared using field emission scanning electron microscopy (FE-SEM) before and after sintering. Biaxial flexural strength tests were also conducted to evaluate mechanical properties. The green bodies obtained via additive manufacturing exhibited uniform layering with strong interlayer adhesion. After sintering, the structures were dense with minimal porosity. However, compared to subtractively manufactured zirconia, the additively manufactured specimens showed slightly higher porosity and lower biaxial flexural strength. The results demonstrate the potential of SLA-based additive manufacturing for dental zirconia applications while also highlighting its current mechanical limitations. The study also showed that using a blade to evenly spread viscous slurry layers in a top-down SLA system can effectively reduce oxygen inhibition at the surface and relieve internal stresses during the layer-by-layer printing process, offering a promising direction for clinical adaptation. Full article

Lithium-ion batteries (LIBs) have significantly advanced portable electronics, yet their reliance on flammable organic solvents and lithium dendrite formation pose safety risks. Solid-state batteries (SSBs), utilizing solid electrolytes, offer a safer alternative with higher energy and power densities. This study explores the fabrication of solid electrolytes using ceramic stereolithography, focusing on lithium lanthanum zirconate (LLZ) due to its high ionic conductivity and chemical stability. A photosensitive paste containing 40–43 vol% LLZ was suitable for processing by stereolithography, and optimized processing parameters of 100 mW laser power and 1000 mm/s laser scanning speed with a 50 μm laser spot size were identified for sufficient material curing and interlayer lamination of LLZ. Thin embossed sheets were designed to enhance ion exchange and reduce internal resistance and were fabricated by the ceramic stereolithography method. The effect of cold isostatic pressing (CIP) on the sintered microstructure was investigated, and the potential for CIP to promote solid-phase diffusion during sintering was demonstrated, particularly at 67 MPa. The resulting LLZ-embossed sheets exhibited dense ceramic microstructures. These findings support the potential application of ceramic stereolithography for fabricating efficient solid electrolytes for next-generation telecommunications and mobile devices. Full article

In ceramic stereolithography, composite “green” bodies must be thermally processed to de-bind organic content and sinter the material. The conventional process for dewaxing and sintering of yttria stabilized zirconia stereolithography components is typically very long. The time and energy cost of thermal treatment of these components can be reduced by controlling the size of the solid particles in the photosensitive material. The Discrete Element Method was used to model the number of particle contacts per mass using particles of various median diameter, and a three-dimensional curved surface graph was generated. Ceramic slurries were prepared using powders that fulfilled the conditions of various calculated data points from the DEM model analysis. The prepared slurries were processed by stereolithography additive manufacturing and fabricated precursors were thermally processed to dewax and sinter the parts. The relationship between the particle size and the occurrence of crack formation after heat treatment was investigated. Heat treatment parameters were further investigated using the predicted slurry composition that was optimal for crack prevention. The required time for dewaxing and sintering of yttria stabilized zirconia components was reduced to one tenth of the conventional time through optimization of slurry composition and thermal treatment schedule. Full article

The additive manufacturing of ceramics offers a reliable and repeatable method for fabricating parts with complex geometries. To compete with conventional ceramic forming methods, the time and cost associated with material and process optimization for ceramic stereolithography should be improved. Computational analysis methods can be utilized to reduce the number of experimental steps required for material and process optimization. This work used the discrete element method and ray tracing analyses to predict suitable material parameters and processing conditions for ceramic stereolithography. The discrete element method was used to create alumina particle dispersion models to predict suitable paste compositions, and ray tracing was used to predict suitable laser power and scan speed to achieve a sufficient curing depth for stereolithography processing. The predicted conditions of paste composition and processing parameters were comparable to experimental values, reducing the number of experimental iterations required for process optimization. Furthermore, suitable processing parameters for high-speed fabrication by stereolithography was predicted, achieving a processing speed much faster than previously reported ceramic stereolithography. The reduction in process optimization timeline, and the increase in fabrication speed, could increase the appeal of ceramic stereolithography to industry. Full article

In this paper, stereolithographic additive manufacturing of ceramic dental crowns is discussed and reviewed. The accuracy of parts in ceramic processing were optimized through smart computer-aided design, manufacturing, and evaluation. Then, viscous acrylic resin, including alumina particles, were successfully compounded. The closed packing of alumina particles in acrylic pastes was virtually simulated using the distinct element method. Multimodal distributions of particle diameters were systematically optimized at an 80% volume fraction, and an ultraviolet laser beam was scanned sterically. Fine spots were continuously joined by photochemical polymerization. The optical intensity distributions from focal spots were spatially simulated using the ray tracing method. Consequently, the lithographic conditions of the curing depths and dimensional tolerances were experimentally measured and effectively improved, where solid objects were freely processed by layer stacking and interlayer bonding. The composite precursors were dewaxed and sintered along effective heat treatment patterns. The results show that linear shrinkages were reduced as the particle volume fractions were increased. Anisotropic deformations in the horizontal and vertical directions were recursively resolved along numerical feedback for graphical design. Accordingly, dense microstructures without microcracks or pores were obtained. The mechanical properties were measured as practical levels for dental applications. Full article

Zirconia electrodes with dendritic patterns were fabricated by stereolithographic additive manufacturing (STL-AM). A solid electrolyte of yttria-stabilized zirconia (YSZ) was selected for oxygen separation in the molten salt electrolysis of aluminum smelting without carbon dioxide excretion. Thereafter, 4, 6, 8 and 12-coordinated dendritic structures composed of cylindrical lattices were designed as computer graphics. The specific surface area of each structure was maximized by changing the aspect ratio. The spatial profile and surface pressure of the hot liquid propagation in the dendrite patterns were systematically visualized by computational fluid dynamics (CFD). During the fabrication process, a photosensitive resin containing zirconia particles was spread on a substrate, and an ultraviolet (UV) laser beam was scanned to create a two-dimensional (2D) cross-section. Through layer laminations, three-dimensional (3D) objects with dendritic structures were successfully fabricated. The ceramics were obtained through dewaxing and sintering. Full article

Three-dimensional (3D) microphotonic crystals with a diamond structure composed of titania microlattices were fabricated using ultraviolet laser lithography, and the bandgap properties in the terahertz (THz) electromagnetic-wave frequency region were investigated. An acrylic resin paste with titania fine particle dispersions was used as the raw material for additive manufacturing. By scanning a spread paste surface with an ultraviolet laser beam, two-dimensional solid patterns were dewaxed and sintered. Subsequently, 3D structures with a relative density of 97% were created via layer lamination and joining. A titania diamond lattice with a lattice constant density of 240 µm was obtained. The properties of the electromagnetic wave were measured using a THz time-domain spectrometer. In the transmission spectra for the Γ-X <100> direction, a forbidden band was observed from 0.26 THz to 0.44 THz. The frequency range of the bandgap agreed well with calculated results obtained using the plane–wave expansion method. Additionally, results of a simulation via transmission-line modeling indicated that a localized mode can be obtained by introducing a plane defect between twinned diamond lattice structures. Full article

Micrometer order magnetophotonic crystals with periodic arranged metallic glass and oxide glass composite materials were fabricated by stereolithographic method to reflect electromagnetic waves in terahertz frequency ranges through Bragg diffraction. In the fabrication process, the photo sensitive acrylic resin paste mixed with micrometer sized metallic glass of Fe₇₂B_14.4Si_9.6Nb₄ and oxide glass of B₂O₃·Bi₂O₃ particles was spread on a metal substrate, and cross sectional images of ultra violet ray were exposed. Through the layer by layer stacking, micro lattice structures with a diamond type periodic arrangement were successfully formed. The composite structures could be obtained through the dewaxing and sintering process with the lower temperature under the transition point of metallic glass. Transmission spectra of the terahertz waves through the magnetophotonic crystals were measured by using a terahertz time domain spectroscopy. Full article
