Impact of Head Position on Facial Soft Tissue Thickness: An Ultrasound Study in the Slovak Population
Abstract
:1. Introduction
2. Materials and Methods
2.1. Sample Description and Anthropometric Measurements
2.2. Ultrasound Measurement Protocol
2.3. Statistical Analysis
3. Results
4. Discussion
Limits of the Study and Further Recommendations
5. Conclusions
Author Contributions
Funding
Institutional Review Board Statement
Informed Consent Statement
Data Availability Statement
Conflicts of Interest
References
- Kos, J. Přehled Topografické Anatomie; Stingl, J., Ed.; Karolinum: Prague, Czech Republic, 2014. [Google Scholar]
- De Greef, S.; Claes, P.; Vandermeulen, D.; Mollemans, W.; Suetens, P.; Willems, G. Large-Scale In-Vivo Caucasian Facial Soft Tissue Thickness Database for Craniofacial Reconstruction. Forensic Sci. Int. 2006, 159, S126–S146. [Google Scholar] [CrossRef] [PubMed]
- Thakur, S.; Sehrawat, J.S. Age and Sex Dependent Differences in Midline Facial Soft Tissue Thicknesses Measured on MRI Scans of Northwest Indian Subjects: A Forensic Anthropological Study. Egypt. J. Forensic Sci. 2023, 13, 38. [Google Scholar] [CrossRef]
- Panenková, P.; Beňuš, R.; Masnicová, S.; Obertová, Z.; Grunt, J. Facial Soft Tissue Thicknesses of the Mid-Face for Slovak Population. Forensic Sci. Int. 2012, 220, 293.e1–293.e6. [Google Scholar] [CrossRef]
- Beth, H. Aesthetic Procedures: Nurse Practitioner’s Guide to Cosmetic Dermatology; Springer International Publishing: Irvine, CA, USA, 2020. [Google Scholar]
- Manhein, M.H.; Listi, G.A.; Barsley, R.E.; Musselman, R.; Barrow, N.E.; Ubelaker, D.H. In vivo facial tissue depth measurements for children and adults. J. Forensic Sci. 2000, 45, 48–60. [Google Scholar] [CrossRef]
- El-Mehallawi, I.H.; Soliman, E.M. Ultrasonic assessment of facial soft tissue thicknesses in adult Egyptians. Forensic Sci. Int. 2001, 117, 99–107. [Google Scholar] [CrossRef] [PubMed]
- Cotofana, S.; Lachman, N. Anatomy of the Facial Fat Compartments and their Relevance in Aesthetic Surgery. J. Dtsch. Dermatol. Ges. 2019, 17, 399–413. [Google Scholar] [CrossRef]
- Kahn, J.L.; Wolfram-Gabel, R.; Bourjat, P. Anatomy and Imaging of the Deep Fat of the Face. Clin. Anat. 2000, 13, 373–382. [Google Scholar] [CrossRef]
- Kaur, M.; Garg, R.K.; Singla, S. Analysis of facial soft tissue changes with aging and their effects on facial morphology: A forensic perspective. Egypt. J. Forensic Sci. 2015, 5, 46–56. [Google Scholar] [CrossRef]
- Nkengne, A.A. Prédire l’âge de Personnes à Partir de Photos Du Visage: Une Étude Fondée Sur La Caractérisation et l’analyse de Signes Du Vieillissement; Université Pierre et Marie Curie: Paris, France, 2008. [Google Scholar]
- Toledo Avelar, L.E.; Cardoso, M.A.; Santos Bordoni, L.; De Miranda Avelar, L.; De Miranda Avelar, J.V. Aging and Sexual Differences of the Human Skull. Plast. Reconstr. Surg.-Glob. Open 2017, 5, e1297. [Google Scholar] [CrossRef] [PubMed]
- De Greef, S.; Vandermeulen, D.; Claes, P.; Suetens, P.; Willems, G. The Influence of Sex, Age and Body Mass Index on Facial Soft Tissue Depths. Forensic Sci. Med. Pathol. 2009, 5, 60–65. [Google Scholar] [CrossRef]
- Limbert, G.; Masen, M.A.; Pond, D.; Graham, H.K.; Sherratt, M.J.; Jobanputra, R.; McBride, A. Biotribology of the Ageing Skin—Why We Should Care. Biotribology 2019, 17, 75–90. [Google Scholar] [CrossRef]
- Alimova, S.; Sharobaro, V.; Yukhno, A.; Bondarenko, E. Possibilities of Ultrasound Examination in the Assessment of Age-Related Changes in the Soft Tissues of the Face and Neck: A Review. Appl. Sci. 2023, 13, 1128. [Google Scholar] [CrossRef]
- Meikle, B.; Stephan, C.N. B-mode Ultrasound Measurement of Facial Soft Tissue Thickness for Craniofacial Identification: A Standardized Approach. J. Forensic Sci. 2020, 65, 939–947. [Google Scholar] [CrossRef]
- Hrazdira, I. Biofyzikální Základy Ultrasnografie: Jak Pracovat s Ultrazvukovým Diagnostickým Přístrojem; Univerzita Palackého: Olomouc, Czech Republic, 2011; ISBN 978-80-244-2895-6. [Google Scholar]
- Masnicová, S.; Beňuš, R.; Panenková, P. Rekonštrukcia Podoby Tváre z Lebky; Akadémia policajného zboru v Bratislave: Bratislava, Slovakia, 2011. [Google Scholar]
- Smith, S.L.; Throckmorton, G.S. A new technique for three-dimensional ultrasound scanning of facial tissues. J. Forensic Sci. 2004, 49, JFS2003203-7. [Google Scholar] [CrossRef]
- Krishan, K.; Sidhu, M.C.; Kanchan, T.; Menezes, R.G.; Sen, J. Diurnal Variation in Stature—Is It More in Children or Adults? Biosci. Hypotheses 2009, 2, 174–175. [Google Scholar] [CrossRef]
- Baillie, L.J.; Muirhead, J.C.; Blyth, P.; Niven, B.E.; Dias, G.J. Position Effect on Facial Soft Tissue Depths: A Sonographic Investigation. J. Forensic Sci. 2016, 61, S60–S70. [Google Scholar] [CrossRef] [PubMed]
- Stephan, C.N.; Preisler, R. In Vivo Facial Soft Tissue Thicknesses of Adult Australians. Forensic Sci. Int. 2018, 282, 220.e1–220.e12. [Google Scholar] [CrossRef] [PubMed]
- Thiemann, N.; Keil, V.; Roy, U. In Vivo Facial Soft Tissue Depths of a Modern Adult Population from Germany. Int. J. Leg. Med. 2017, 131, 1455–1488. [Google Scholar] [CrossRef] [PubMed]
- Somos, C.P.; Rea, P.M.; Shankland, S.; Kranioti, E.F. Medical Imaging and Facial Soft Tissue Thickness Studies for Forensic Craniofacial Approximation: A Pilot Study on Modern Cretans. In Biomedical Visualisation; Rea, P.M., Ed.; Advances in Experimental Medicine and Biology; Springer International Publishing: Cham, Switzerland, 2019; Volume 1138, pp. 71–86. ISBN 978-3-030-14226-1. [Google Scholar]
- Helmer, R. Schäldelidentifizierung Durch Elektroniesche Bildmischung: Zugleich Ein Beitrag Zur Konstitutionsbiometrie Und Dickenmessung Der Gesichtweichteile; Kriminalistik-Verlag: Heilderberg, Germany, 1984. [Google Scholar]
- Chaimongkhol, T.; Mahakkanukrauh, P. The Facial Soft Tissue Thickness Related Facial Reconstruction by Ultrasonographic Imaging: A Review. Forensic Sci. Int. 2022, 337, 111365. [Google Scholar] [CrossRef]
- Švábová, P.; Matláková, M.; Beňuš, R.; Chovancová, M.; Masnicová, S. The Relationship between Biological Parameters and Facial Soft Tissue Thickness Measured by Ultrasound and Its Forensic Implications. Med. Sci. Law 2024, 64, 23–31. [Google Scholar] [CrossRef] [PubMed]
- Jia, L.; Qi, B.; Yang, J.; Zhang, W.; Lu, Y.; Zhang, H.-L. Ultrasonic Measurement of Facial Tissue Depth in a Northern Chinese Han Population. Forensic Sci. Int. 2016, 259, 247.e1–247.e6. [Google Scholar] [CrossRef]
- Peckmann, T.R.; Harris, M.; Huculak, M.; Pringle, A.; Fournier, M. In Vivo Facial Tissue Depth for Canadian Mi’kmaq Adults: A Case Study from Nova Scotia, Canada. J. Forensic Leg. Med. 2015, 29, 43–53. [Google Scholar] [CrossRef]
- Munn, L.; Stephan, C.N. Changes in Face Topography from Supine-to-Upright Position—And Soft Tissue Correction Values for Craniofacial Identification. Forensic Sci. Int. 2018, 289, 40–50. [Google Scholar] [CrossRef]
- Smith, S.L.; Throckmorton, G.S. Comparability of radiographic and 3D-ultrasound measurements of facial midline tissue depths. J. Forensic Sci. 2006, 51, 244–247. [Google Scholar] [CrossRef]
- Bulut, O.; Jessica Liu, C.-Y.; Koca, F.; Wilkinson, C. Comparison of Three-Dimensional Facial Morphology between Upright and Supine Positions Employing Three-Dimensional Scanner from Live Subjects. Leg. Med. 2017, 27, 32–37. [Google Scholar] [CrossRef]
- Perzová, B. Analýza Hrúbok Mäkkých Tvárových Tkanív Tváre v Slovenskej Populácii, Katedra Antropológie Prírodovedeckej Fakulty; Univerzity Komenského: Bratislava, Slovakia, 2017. [Google Scholar]
- Wilkinson, C.M. In vivo facial tissue depth measurements for white British children. J. Forensic Sci. 2002, 47, 459–465. [Google Scholar] [CrossRef] [PubMed]
- Ode, J.J.; Pivarnik, J.M.; Reeves, M.J.; Knous, J.L. Bosy Mass Index as a Predictor of Percent Fat in College Athletes and Non-athletes. Med. Sci. Sports Exerc. 2007, 39, 403–409. [Google Scholar] [CrossRef]
Category | N | Min. | Max. | Average | SD |
---|---|---|---|---|---|
Younger females | 39 | 20.02 | 25.34 | 22.77 | 1.18 |
Younger males | 26 | 20.72 | 24.78 | 22.73 | 1.02 |
Older females | 38 | 46.29 | 85.28 | 63.84 | 9.63 |
Older males | 18 | 48.76 | 86.88 | 64.35 | 9.30 |
Whole dataset | 121 | 20.02 | 86.88 | 41.85 | 21.58 |
Anthropometric Landmark | N | Upright Position | Supine Position | Difference Between Positions 1 | z-Value | p-Value | ||
---|---|---|---|---|---|---|---|---|
Mean | SD | Mean | SD | (mm) | ||||
Metopion (mm) | 121 | 4.84 | 0.95 | 4.95 | 0.99 | −0.11 | −2.371 | <0.05 * |
Glabella (mm) | 121 | 5.13 | 0.92 | 4.83 | 0.76 | 0.30 | −4.594 | <0.05 * |
Nasion (mm) | 121 | 3.88 | 0.79 | 3.92 | 0.75 | −0.04 | −0.388 | >0.05 |
Rhinion (mm) | 121 | 3.39 | 0.83 | 3.57 | 0.72 | −0.18 | −2.772 | <0.05 * |
Midphiltrum (mm) | 120 | 9.37 | 2.09 | 9.35 | 1.86 | 0.02 | −0.261 | >0.05 |
Supramentale (mm) | 121 | 10.54 | 1.45 | 10.10 | 1.22 | 0.44 | −4.409 | <0.05 * |
Pogonion (mm) | 121 | 7.64 | 2.45 | 7.36 | 2.14 | 0.28 | −2.183 | <0.05 * |
Gnathion (mm) | 121 | 5.55 | 1.86 | 5.69 | 1.55 | −0.14 | −1.452 | >0.05 |
Alare (mm) | 121 | 10.84 | 1.52 | 10.99 | 1.54 | −0.15 | −0.253 | >0.05 |
Supraorbital (mm) | 121 | 4.82 | 1.80 | 5.41 | 2.47 | −0.59 | −3.253 | <0.05 * |
Infraorbital (mm) | 121 | 4.84 | 1.52 | 5.68 | 2.07 | −0.84 | −3.131 | <0.05 * |
Fossa canina (mm) | 121 | 18.04 | 2.47 | 16.94 | 2.71 | 1.10 | −4.329 | <0.05 * |
Midmandible (mm) | 121 | 6.89 | 3.10 | 6.54 | 2.51 | 0.35 | −1.284 | >0.05 |
Malare (mm) | 121 | 10.79 | 1.58 | 10.56 | 1.35 | 0.14 | −1.026 | >0.05 |
Zygomatic (mm) | 121 | 8.89 | 2.14 | 9.41 | 2.15 | −0.52 | −3.296 | <0.05 * |
Gonion (mm) | 121 | 5.64 | 2.68 | 6.06 | 3.03 | −0.42 | −3.649 | <0.05 * |
Females (N = 39) | Males (N = 26) | |||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|
Anthropometric Landmark | Upright Position | Supine Position | Difference Between Positions 1 | p-Value | Upright Position | Supine Position | Difference Between Positions 1 | p-Value | ||||
Mean | SD | Mean | SD | (mm) | Mean | SD | Mean | SD | (mm) | |||
Metopion (mm) | 4.32 | 0.79 | 4.45 | 0.93 | −0.13 | >0.05 | 4.64 | 0.67 | 4.85 | 0.80 | −0.21 | <0.05 * |
Glabella (mm) | 4.62 | 0.69 | 4.34 | 0.54 | 0.28 | <0.05 * | 4.79 | 0.68 | 4.50 | 0.59 | 0.29 | <0.05 * |
Nasion (mm) | 3.63 | 0.68 | 3.73 | 0.71 | −0.10 | >0.05 | 3.87 | 0.71 | 3.87 | 0.75 | 0.00 | >0.05 |
Rhinion (mm) | 3.17 | 0.68 | 3.56 | 0.64 | −0.39 | <0.001 * | 3.37 | 0.96 | 3.49 | 1.80 | −0.12 | >0.05 |
Midphiltrum (mm) | 9.80 | 1.34 | 9.64 | 1.43 | 0.16 | <0.05 | 10.55 | 1.82 | 10.63 | 1.67 | −0.08 | >0.05 |
Supramentale (mm) | 10.20 | 1.40 | 9.38 | 1.13 | 0.82 | <0.001 * | 10.80 | 0.96 | 9.88 | 0.82 | 0.92 | >0.05 |
Pogonion (mm) | 6.88 | 2.20 | 6.97 | 2.13 | −0.09 | >0.05 | 7.88 | 2.40 | 6.95 | 2.13 | 0.93 | <0.01 * |
Gnathion (mm) | 5.19 | 1.55 | 5.37 | 1.45 | −0.18 | >0.05 | 4.98 | 1.12 | 5.43 | 1.20 | −0.45 | >0.05 |
Alare (mm) | 10.25 | 1.20 | 10.58 | 1.47 | −0.33 | >0.05 | 10.55 | 0.88 | 10.63 | 0.57 | −0.08 | >0.05 |
Supraorbital (mm) | 4.70 | 1.14 | 4.47 | 1.25 | 0.23 | >0.05 | 3.98 | 1.80 | 4.41 | 1.65 | −0.43 | >0.05 |
Infraorbital (mm) | 4.37 | 0.89 | 4.82 | 1.18 | −0.45 | <0.05 | 4.17 | 0.66 | 4.43 | 1.27 | −0.26 | >0.05 |
Fossa canina (mm) | 17.25 | 2.41 | 16.36 | 2.33 | 0.89 | <0.001 * | 17.34 | 1.34 | 17.70 | 1.55 | −0.36 | <0.05 * |
Midmandible (mm) | 5.62 | 2.18 | 5.86 | 2.19 | −0.24 | >0.05 | 5.30 | 1.71 | 5.21 | 1.97 | 0.09 | >0.05 |
Malare (mm) | 10.55 | 1.88 | 10.24 | 1.43 | 0.31 | >0.05 | 10.87 | 1.24 | 10.68 | 0.92 | 0.19 | >0.05 |
Zygomatic (mm) | 8.67 | 1.59 | 8.93 | 1.77 | −0.26 | >0.05 | 7.22 | 2.11 | 8.60 | 1.95 | −1.38 | <0.01 * |
Gonion (mm) | 4.59 | 1.74 | 4.92 | 1.77 | −0.33 | <0.01 | 4.58 | 1.67 | 5.10 | 1.83 | −0.52 | >0.05 |
Females (N = 38) | Males (N = 18) | |||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|
Anthropometric Landmark | Upright Position | Supine Position | Difference Between Positions 1 | p-Value | Upright Position | Supine Position | Difference Between Positions 1 | p-Value | ||||
Mean | SD | Mean | SD | (mm) | Mean | SD | Mean | SD | (mm) | |||
Metopion (mm) | 5.22 | 0.89 | 5.32 | 0.94 | −0.10 | >0.05 | 5.42 | 1.20 | 5.40 | 0.96 | 0.02 | >0.05 |
Glabella (mm) | 5.77 | 0.92 | 5.36 | 0.78 | 0.41 | <0.001 * | 5.36 | 0.75 | 5.27 | 0.55 | 0.09 | >0.05 |
Nasion (mm) | 4.90 | 0.83 | 4.60 | 0.84 | 0.30 | >0.05 | 4.20 | 0.90 | 4.11 | 0.70 | 0.09 | >0.05 |
Rhinion (mm) | 3.51 | 0.82 | 3.66 | 0.91 | −0.15 | >0.05 | 3.62 | 0.81 | 3.51 | 1.13 | 0.11 | >0.05 |
Midphiltrum (mm) | 8.36 | 2.21 | 7.83 | 2.60 | 0.53 | >0.05 | 10.51 | 2.22 | 10.13 | 1.39 | 0.38 | >0.05 |
Supramentale (mm) | 10.59 | 1.25 | 10.17 | 1.49 | 0.42 | <0.05 * | 12.27 | 1.83 | 11.81 | 1.66 | 0.46 | >0.05 |
Pogonion (mm) | 8.41 | 2.37 | 7.64 | 2.17 | 0.77 | <0.05 | 7.35 | 2.70 | 8.35 | 2.61 | −1.00 | >0.05 |
Gnathion (mm) | 6.42 | 2.27 | 6.28 | 1.83 | 0.14 | >0.05 | 5.28 | 1.68 | 5.45 | 1.8 | −0.17 | >0.05 |
Alare (mm) | 11.50 | 1.96 | 11.40 | 1.52 | 0.10 | >0.05 | 11.23 | 1.21 | 10.92 | 1.17 | 0.31 | >0.05 |
Supraorbital (mm) | 6.11 | 2.16 | 6.57 | 2.63 | −0.46 | >0.05 | 5.40 | 1.41 | 5.39 | 1.49 | 0.01 | >0.05 |
Infraorbital (mm) | 5.78 | 2.30 | 6.22 | 2.28 | −0.44 | >0.05 | 4.92 | 1.30 | 5.13 | 1.56 | −0.21 | >0.05 |
Fossa canina (mm) | 18.71 | 2.56 | 17.75 | 2.59 | 0.96 | <0.05 * | 19.43 | 2.73 | 18.82 | 2.13 | 0.61 | >0.05 |
Midmandible (mm) | 8.98 | 3.51 | 7.67 | 2.58 | 1.31 | <0.05 * | 7.53 | 2.82 | 6.91 | 1.99 | 0.62 | >0.05 |
Malare (mm) | 10.98 | 1.64 | 10.93 | 1.15 | 0.05 | >0.05 | 10.92 | 0.93 | 10.79 | 0.79 | 0.13 | >0.05 |
Zygomatic (mm) | 10.16 | 2.90 | 10.36 | 2.21 | −0.20 | >0.05 | 9.12 | 1.56 | 9.39 | 1.86 | −0.27 | >0.05 |
Gonion (mm) | 7.59 | 3.29 | 7.67 | 3.57 | −0.08 | >0.05 | 5.11 | 1.22 | 6.91 | 3.13 | −1.80 | <0.001 * |
