A Review of Robotic Fish Based on Smart Materials
Abstract
:1. Introduction
2. Hydrodynamic Analysis Model
2.1. Numerical Method
2.2. Analysis Method
3. BCF
3.1. SMA
3.2. IPMCs
3.3. Piezoelectric
3.4. DE
4. MPF
4.1. SMA
4.2. IPMCs
4.3. DE
5. Discussion
6. Conclusions
Author Contributions
Funding
Institutional Review Board Statement
Informed Consent Statement
Data Availability Statement
Acknowledgments
Conflicts of Interest
List of Abbreviations
Abbreviation | Definition |
AUVs | Autonomous Underwater Vehicles |
BCF | Body and/or Caudal Fin Swing |
MPF | Median and/or Paired Fin Swing |
EBT | Elongated Body Theory |
WPT | Wave Plate Theory |
SMA | Shape Memory Alloys |
PZT | Lead Zirconate Titanate |
IPMC | Ionic Polymer Metal Composites |
CPG | Central Pattern Generator |
CFD | Computational Fluid Dynamics |
N–S | Navier–Stokes |
LAEBT | Large Amplitude Elongated Body Theory |
SMA | Shape Memory Alloy |
SME | Shape Memory Effect |
PVC | Polyvinyl Chloride |
ABS | Acrylonitrile-Butadiene-Styrene |
CFRP | Carbon Fibre-Reinforced Polymer |
MFC | Macro-Fibre Composite |
DEA | Dielectric Elastomer Actuator |
PMMA | Polymethyl Methacrylate |
PDMS | Polydimethylsiloxane |
PET | Polyethylene Terephthalate |
SIS DEA | Silicone-Based Dielectric Elastomer Actuator |
DE | Dielectric Elastomer |
RL | Reinforcement Learning |
References
