A Proof-of-Concept Pilot Study of Contrast-Enhanced Ultrasound as a Potential Alternative to Contrast-Enhanced Magnetic Resonance Imaging in the Surveillance of Hepatocellular Adenoma and Focal Nodular Hyperplasia
Abstract
1. Introduction
2. Materials and Methods
2.1. Study Group
2.2. Magnetic Resonance Imaging Protocol
2.3. Contrast-Enhanced Ultrasound Protocol
2.4. Statistical Analysis
3. Results
3.1. Baseline Characteristics
3.2. Imaging Tumor Size Comparison (MRI vs. CEUS)
3.3. Lesion Size Evaluation During Follow-Up
4. Discussion
5. Conclusions
Author Contributions
Funding
Institutional Review Board Statement
Informed Consent Statement
Data Availability Statement
Conflicts of Interest
Abbreviations
| ADC | Apparent Diffusion Coefficient |
| B-mode | Brightness mode |
| CEUS | Contrast-Enhanced Ultrasound |
| DWI | Diffusion-Weighted Imaging |
| EASL | European Association for the Study of the Liver |
| FNH | Focal Nodular Hyperplasia |
| HA | Hepatocellular Adenoma |
| HCC | Hepatocellular Carcinoma |
| IQR | Interquartile Range |
| MI | Mechanical Index |
| MRI | Magnetic Resonance Imaging |
| RECIST | Response Evaluation Criteria in Solid Tumors |
| SD | Standard Deviation |
| T1-w | T1-weighted |
| T2-w | T2-weighted |
| US | Ultrasound |
References
- Reguram, R.; Ghonge, A.; Tse, J.; Dhanasekaran, R. Practical approach to diagnose and manage benign liver masses. Hepatol. Commun. 2024, 8, e0560. [Google Scholar] [CrossRef]
- Klompenhouwer, A.J.; van Rosmalen, B.V.; Haring, M.P.D.; Thomeer, M.G.J.; Doukas, M.; Verheij, J.; de Meijer, V.E.; van Gulik, T.M.; Takkenberg, R.B.; Kazemier, G.; et al. A multicentre retrospective analysis on growth of residual hepatocellular adenoma after resection. Liver Int. 2020, 40, 2272–2278. [Google Scholar] [CrossRef]
- Kinoshita, M.; Takemura, S.; Tanaka, S.; Hamano, G.; Ito, T.; Aota, T.; Koda, M.; Ohsawa, M.; Kubo, S. Ruptured focal nodular hyperplasia observed during follow-up: A case report. Surg. Case Rep. 2017, 3, 44. [Google Scholar] [CrossRef]
- Poetter-Lang, S.; Ba-Ssalamah, A.; Bastati, N.; Ba-Ssalamah, S.A.; Hodge, J.C.; Brancatelli, G.; Paradis, V.; Vilgrain, V. Hepatocellular adenoma update: Diagnosis, molecular classification, and clinical course. Br. J. Radiol. 2024, 97, 1740–1754. [Google Scholar] [CrossRef]
- Dobek, A.; Kobierecki, M.; Wieczorek, P.; Grząsiak, O.; Ciesielski, W.; Fabisiak, A.; Stefańczyk, L. Contrast-enhanced ultrasonography as a method of monitoring focal liver lesions—Initial report. Clin. Exp. Hepatol. 2024, 10, 120–128. [Google Scholar] [CrossRef] [PubMed]
- Dobek, A.; Kobierecki, M.; Ciesielski, W.; Grząsiak, O.; Fabisiak, A.; Stefańczyk, L. Usefulness of Contrast-Enhanced Ultrasound in the Differentiation between Hepatocellular Carcinoma and Benign Liver Lesions. Diagnostics 2023, 13, 2025. [Google Scholar] [CrossRef]
- Haring, M.P.D.; Gouw, A.S.H.; de Haas, R.J.; Cuperus, F.J.C.; de Jong, K.P.; de Meijer, V.E. The effect of oral contraceptive pill cessation on hepatocellular adenoma diameter: A retrospective cohort study. Liver Int. 2019, 39, 905–913. [Google Scholar] [CrossRef] [PubMed]
- Tse, J.R.; Felker, E.R.; Naini, B.V.; Shen, L.; Shen, J.; Lu, D.S.K.; Kamaya, A.; Raman, S.S. Hepatocellular Adenomas: Molecular Basis and Multimodality Imaging Update. RadioGraphics 2023, 43, e220134. [Google Scholar] [CrossRef]
- Vernuccio, F.; Ronot, M.; Dioguardi Burgio, M.; Cauchy, F.; Choudhury, K.R.; Dokmak, S.; Soubrane, O.; Valla, D.; Zucman-Rossi, J.; Paradis, V.; et al. Long-term Evolution of Hepatocellular Adenomas at MRI Follow-up. Radiology 2020, 295, 361–372. [Google Scholar] [CrossRef]
- Nguyen, T.T.L.; Le Bail, B.; Frulio, N. Spontaneous necrosis and regression of focal nodular hyperplasia. Diagn. Interv. Imaging 2024, 105, 507–508. [Google Scholar] [CrossRef] [PubMed]
- Gaspersz, M.P.; Klompenhouwer, A.J.; Broker, M.E.E.; Thomeer, M.G.J.; van Aalten, S.M.; Steegers, E.; Terkivatan, T.; de Koning, H.; de Man, R.A.; Ijzermans, J.N.M. Growth of hepatocellular adenoma during pregnancy: A prospective study. J. Hepatol. 2020, 72, 119–124. [Google Scholar] [CrossRef]
- Hasuike, S.; Nagata, K.; Sasaki, H.; Hirata, T.; Suzuki, S.; Komaki, Y.; Ozono, Y.; Nakamura, K.; Miike, T.; Iwakiri, H.; et al. Inflammatory Hepatocellular Adenoma Mimicking Focal Nodular Hyperplasia That Grew during Pregnancy and Changed Its Appearance on Magnetic Resonance Imaging after Delivery. Intern. Med. 2023, 62, 3143–3149. [Google Scholar] [CrossRef]
- Bilreiro, C.; Soler, J.C.; Ayuso, J.R.; Caseiro-Alves, F.; Ayuso, C. Diagnostic value of morphological enhancement patterns in the hepatobiliary phase of gadoxetic acid-enhanced MRI to distinguish focal nodular hyperplasia from hepatocellular adenoma. Radiol. Med. 2021, 126, 1379–1387. [Google Scholar] [CrossRef] [PubMed]
- Ashhab, A.A.; Abu-Sulb, A.; Yang, J.D.; Noureddin, M.; Sundaram, V.; Kuo, A.; Ayoub, W.S. Estrogen-Driven Growth of Focal Nodular Hyperplasia: Truth or Myth? ACG Case Rep. J. 2021, 8, e00531. [Google Scholar] [CrossRef] [PubMed]
- Bröker, M.E.E.; Taimr, P.; de Vries, M.; Braun, L.M.M.; de Man, R.A.; Ijzermans, J.N.M.; Dwarkasing, R.S. Performance of Contrast-Enhanced Sonography Versus MRI With a Liver-Specific Contrast Agent for Diagnosis of Hepatocellular Adenoma and Focal Nodular Hyperplasia. Am. J. Roentgenol. 2020, 214, 81–89. [Google Scholar] [CrossRef] [PubMed]
- Swensson, J.; McCrate, M.; Halappa, V.G.; Stethen, T.; Akisik, F. Contrast-Enhanced Ultrasound Compared With Hepatobiliary Agent MRI for Differentiation of Focal Nodular Hyperplasia and Hepatic Adenoma: A Prospective Trial. Ultrasound Q. 2024, 40, e00696. [Google Scholar] [CrossRef]
- Tselikas, L.; Pigneur, F.; Roux, M.; Baranes, L.; Costentin, C.; Roche, V.; Calderaro, J.; Herin, E.; Laurent, A.; Zafrani, E.; et al. Impact of hepatobiliary phase liver MRI versus Contrast-Enhanced Ultrasound after an inconclusive extracellular gadolinium-based contrast-enhanced MRI for the diagnosis of benign hepatocellular tumors. Abdom. Radiol. 2017, 42, 825–832. [Google Scholar] [CrossRef]
- Negrão de Figueiredo, G.; Mueller-Peltzer, K.; Schwarze, V.; Marschner, C.; Zhang, L.; Rübenthaler, J.; Siepmann, T.; Illigens, B.; Clevert, D. Long-term study analysis of contrast-enhanced ultrasound in the diagnosis of focal nodular hyperplasia. Clin. Hemorheol. Microcirc. 2020, 74, 441–452. [Google Scholar] [CrossRef]
- European Association for the Study of the Liver (EASL). EASL Clinical Practice Guidelines on the management of benign liver tumours. J. Hepatol. 2016, 65, 386–398. [Google Scholar] [CrossRef]
- Dietrich, C.F.; Nolsøe, C.P.; Barr, R.G.; Berzigotti, A.; Burns, P.N.; Cantisani, V.; Chammas, M.C.; Chaubal, N.; Choi, B.I.; Clevert, D.-A.; et al. Guidelines and Good Clinical Practice Recommendations for Contrast-Enhanced Ultrasound (CEUS) in the Liver–Update 2020 WFUMB in Cooperation with EFSUMB, AFSUMB, AIUM, and FLAUS. Ultrasound Med. Biol. 2020, 46, 2579–2604. [Google Scholar] [CrossRef]
- Roche, V.; Pigneur, F.; Tselikas, L.; Roux, M.; Baranes, L.; Djabbari, M.; Costentin, C.; Calderaro, J.; Laurent, A.; Rahmouni, A.; et al. Differentiation of focal nodular hyperplasia from hepatocellular adenomas with low-mecanical-index contrast-enhanced sonography (CEUS): Effect of size on diagnostic confidence. Eur. Radiol. 2015, 25, 186–195. [Google Scholar] [CrossRef]
- D’Onofrio, M.; Crosara, S.; De Robertis, R.; Canestrini, S.; Mucelli, R.P. Contrast-Enhanced Ultrasound of Focal Liver Lesions. Am. J. Roentgenol. 2015, 205, W56–W66. [Google Scholar] [CrossRef]
- Eisenhauer, E.A.; Therasse, P.; Bogaerts, J.; Schwartz, L.H.; Sargent, D.; Ford, R.; Dancey, J.; Arbuck, S.; Gwyther, S.; Mooney, M.; et al. New response evaluation criteria in solid tumours: Revised RECIST guideline (version 1.1). Eur. J. Cancer 2009, 45, 228–247. [Google Scholar] [CrossRef]
- Haring, M.P.D.; Spijkerboer, C.S.; Cuperus, F.J.C.; Duiker, E.W.; de Jong, K.P.; de Haas, R.J.; de Meijer, V.E. Behavior and complications of hepatocellular adenoma during pregnancy and puerperium: A retrospective study and systematic review. HPB 2021, 23, 1152–1163. [Google Scholar] [CrossRef]
- Glinka, J.; Claria, R.S.; Fratanoni, E.; Spina, J.; Mullen, E.; Ardiles, V.; Mazza, O.; Pekolj, J.; de Santibañes, M.; de Santibañes, E. Malignant transformation of hepatocellular adenoma in a young female patient after ovulation induction fertility treatment: A case report. World J. Gastrointest. Surg. 2019, 11, 229–236. [Google Scholar] [CrossRef]
- Mathieu, D.; Kobeiter, H.; Maison, P.; Rahmouni, A.; Cherqui, D.; Zafrani, E.S.; Dhumeaux, D. Oral contraceptive use and focal nodular hyperplasia of the liver. Gastroenterology 2000, 118, 560–564. [Google Scholar] [CrossRef]
- Halankar, J.A.; Kim, T.K.; Jang, H.J.; Khalili, K.; Masoom, H.A. Understanding the natural history of focal nodular hyperplasia in the liver with MRI. Indian J. Radiol. Imaging 2012, 22, 116–120. [Google Scholar] [CrossRef] [PubMed]
- Kuo, Y.; Wang, J.; Lu, S.; Hung, C.; Wei, Y.; Hu, T.; Chen, C.; Yen, Y.; Lee, C.; Eng, H. Natural course of hepatic focal nodular hyperplasia: A long-term follow-up study with sonography. J. Clin. Ultrasound 2009, 37, 132–137. [Google Scholar] [CrossRef]
- Paratore, M.; Garcovich, M.; Amodeo, A.; Fianchi, F.; Santopaolo, F.; Ponziani, F.R.; Zocco, M.A.; Gasbarrini, A.; Riccardi, L.; Pompili, M. Evolution of focal nodular hyperplasia during long-term ultrasound follow-up: Results from a single-center study. J. Ultrasound 2025. [Google Scholar] [CrossRef] [PubMed]
- Silva, T.S.; Sung, M.; Nelson, D.W.; DiFronzo, A.L.; O’Connor, V.V. A Multicenter, 10-Year Experience With Hepatocellular Adenoma: Risk Factors and Disease Course. Am. Surg. 2022, 88, 2345–2350. [Google Scholar] [CrossRef] [PubMed]
- Schwarze, V.; Marschner, C.; Negrão de Figueiredo, G.; Rübenthaler, J.; Clevert, D.A. Single-Center Study: Evaluating the Diagnostic Performance and Safety of Contrast-Enhanced Ultrasound (CEUS) in Pregnant Women to Assess Hepatic Lesions. Ultraschall Med.—Eur. J. Ultrasound 2020, 41, 29–35. [Google Scholar] [CrossRef] [PubMed]



| FNH n = 28 | HA n = 13 | |
|---|---|---|
| Age—Median (IQR) | 46 (36.8–54) | 43 (39–64) |
| Sex | ||
| Female | 19 (95.0%) | 10 (83.3%) |
| Male | 1 (5.0%) | 2 (16.7%) |
| Higher diameter MRI—Median (IQR) [mm] | 21 (14–35.5) | 28 (23–41) |
| Higher diameter CEUS—Median (IQR) [mm] | 21 (15–36) | 32 (24.5–42) |
| Lower diameter MRI—Median (IQR) [mm] | 15 (11–28) | 23 (21–38.5) |
| Lower diameter CEUS—Median (IQR) [mm] | 16 (12–29.5) | 20 (18–37) |
| MRI | CEUS | p | |
|---|---|---|---|
| Higher diameter | |||
| Median [mm] | 25 | 25 | 0.1331 |
| IQR [mm] | 15–40 | 18–38 | |
| Min–Max [mm] | 5–102 | 5–105 | |
| Lower diameter | |||
| Median [mm] | 21 | 19 | 0.1546 |
| IQR [mm] | 14–30 | 14–30 | |
| Min–Max [mm] | 4–93 | 5–80 | |
| Relative change in sum of diameters between observations [%] | |||
| Median [mm] | 100 | 100 | 0.3378 |
| IQR [mm] | 99–101 | 99–101 | |
| Min–Max [mm] | 58–138 | 51–143 |
| Total number of lesions followed | 41 |
| Baseline measurements (one per lesion) | 41 |
| Total follow-up measurements | 51 |
| Follow-up examinations per lesion | |
| Mean | 2.42 |
| Range (Min–Max) | 1–6 |
| Follow-up intervals | |
| Mean | 12.8 months |
| Maximum interval | 52.1 months |
| Total Follow-up duration | |
| Median Follow-up duration | 8.5 months |
| Maximum Follow-up duration | 72.6 months |
