Visual Explanations of Deep Learning Architectures in Predicting Cyclic Alternating Patterns Using Wavelet Transforms
Abstract
:1. Introduction
2. Methods
2.1. Dataset
2.2. Pre-Processing
2.3. Signal to Image Conversion
2.4. Deep Learning Models
2.4.1. Training Parameters
2.4.2. VGG19
2.4.3. ResNet50
2.4.4. InceptionNetV3
2.4.5. Densenet121
2.4.6. MobileNetV2
2.4.7. EfficientNetB0
2.5. Understanding the Classifier Decisions
3. Results
3.1. Signal to Scalogram Transformation
3.2. Parameters and Data Splitting
3.3. Performance Analysis
3.3.1. A/Not-A-Phase Prediction
3.3.2. A-Subtypes Classification
3.4. Visualizing the Regions Targeted Using Gradcam++
3.4.1. Binary Classification A/Not-A-Phase Classification
3.4.2. A-Phase Subtype Classification
4. Discussion
5. Conclusions
Author Contributions
Funding
Institutional Review Board Statement
Informed Consent Statement
Data Availability Statement
Acknowledgments
Conflicts of Interest
References
