Novel Electrically Conductive Cellulose Nanocrystals with a Core-Shell Nanostructure Towards Biodegradable Electronics
Abstract
:1. Introduction
2. Materials and Methods
2.1. Materials
2.2. Carbamation of Cellulose Nanocrystals Using 2,4-Toluene Diisocyanate
2.3. Hydrolysis and Quantification of Free Isocyanates on the CNC Surface (DSNCO)
2.4. Polymerization of the o-Toluidine Grafted on the CNC Surface
2.5. Determination of the Degree of Substitution of TDI (DSTDI)
2.6. Structural Characterization Using Fourier Transform Infrared (FT-IR)
2.7. Morphological Characterization Using X-ray Diffraction (XRD)
2.8. Morphological Characterization Using Atomic Force Microscopy
2.9. Electrical Conductivity Measurements
3. Results and Discussion
4. Conclusions
5. Patents
Author Contributions
Funding
Data Availability Statement
Conflicts of Interest
References
