Numerical Modeling of Scholte Wave in Acoustic-Elastic Coupled TTI Anisotropic Media
Abstract
:1. Introduction
2. Wave Equations
2.1. Acoustic-Elastic Coupled Equation
2.2. Bond Transformation
3. Staggered-Grid Finite Difference
Stability Condition
4. Numerical Experiments
4.1. 2D Two-Layer Acoustic-Elastic Coupled Model
4.2. 3D Two-Layer Acoustic-Elastic Coupled Model
4.3. Inhomogeneous Acoustic-Elastic Coupled Model
5. Conclusions
Author Contributions
Funding
Data Availability Statement
Acknowledgments
Conflicts of Interest
Appendix A
- Thomsen Parameter
- acoustic-elastic coupled equation in a 3D TTI media
Appendix B
References
