Wing Design in Flies: Properties and Aerodynamic Function
Abstract
:1. Introduction
2. Aerodynamic Properties of Root-Flapping Rectangular Wings
3. The Aerodynamic Benefits of an Ideal Planform
4. Functional Relevance of Three-Dimensional Wing Shape
5. Wing Stiffness and Benefits of Elastic Wing Deformation
6. Conclusions
Supplementary Materials
Author Contributions
Funding
Acknowledgments
Conflicts of Interest
References
