Electrochemical Creatinine (Bio)Sensors for Point-of-Care Diagnosis of Renal Malfunction and Chronic Kidney Disorders
Abstract
:1. Introduction
Age (Years) | Gender | Normal Range (µM) | Toxic Level (µM) |
---|---|---|---|
<14 | Male | 22.11–73.39 | <18, >80 |
Female | 22.11–73.39 | <18, >80 | |
15–20 | Male | 44.21–80.46 | <35.37, >88 |
Female | 37.14–68.97 | <31, >75.16 | |
20–70 | Male | 61.89–106.1 | <55, >113 |
Female | 44.21–88.42 | <39, >95 | |
>70 | Male | >61.89–106.1 | <45, >113 |
Female | >44.21–88.42 | <39, >95 |
2. Creatinine Receptors
2.1. Enzymatic Receptors
2.2. Non-Enzymatic Receptors
3. Electrochemical Creatinine (Bio)Sensors
3.1. Amperometric Creatinine Sensors
3.2. Potentiometric Creatinine Sensors
3.3. Voltammetric Creatinine Sensors
3.4. Other Electrochemical Sensors
4. Limitations and Challenges
Material or Matrix | Enzymes 1 | Electrodes 2 | Range 3 (µM) | LOD 4 (µM) | τres 5 (s) | Sensitivity 6 (mA/unit.M) | Stability in Days 7 (Loss in Activity) | Recovery 8 (%) | Ref. | |
---|---|---|---|---|---|---|---|---|---|---|
WE | RE | |||||||||
ZnO/chitosan/carboxylated MWCNT/polyaniline | CA, CI, SO | Pt | Ag/AgCl | 10–650 | 0.5 | 10 | 0.030 μA/μM·cm2 | 120 (−15%) | 98.7 | [42] |
Carboxylated MWCNT/polyaniline | CA, CI, SO | Pt | Ag/AgCl | 10–750 | 0.1 | 5 | 40 μA/μM·cm2 | 180 (−15%) | – | [42] |
Polypyrrole | – | Au | Au | 0–1001.8 | 40.7 | <300 | – | – | – | [63] |
Fe3O4/chitosan-graft-polyaniline | CRN, CR, SO | Pt | Ag/AgCl | 1–800 | 1 | 2 | 3.9 μA/μM·cm2 | 200 (−10%) | 99.93 | [101] |
AuNPs, MWCNTs | CRN, CR, SO | Teflon cylinder | Ag/AgCl | 3–1000 | 0.1 | 9 | 1.32 µA/mM | – | 98 | [99] |
Copper-polyaniline nanocomposite | CD | Carbon | Ag | 1–125 | 0.5 | 15 | 85 mA/M·cm2 | 3 | – | [58] |
Polymethylene blue | – | Cu–doped carbon | Ag/AgCl | 2.2–132.6 | 2 × 10−4 | – | 0.133 μA/ng·mL | 180 (−4%) | 98.7 | [104] |
Nafion-nsPANI | CD | Au | Ag/AgCl | 100–400 | – | – | 1300 μA/mM·cm2 | – | – | [22] |
CuO@MIP | – | CPE | Ag/AgCl | 0.5–200 | 0.083 | – | 0.21 µA/µM | 14 (−20%) | – | [64] |
ABTS+/CNT | – | Carbon | Ag/AgCl | 0–21300 | 11 | 60 | 27.3 µA/mM·cm2 | – | – | [56] |
Nafion/Polyaniline | CD | Au | Au | 10–1000 | 2 | – | – | 30 (−20%) | – | [108] |
Sb/NPC | – | GCE | Ag/AgCl | – | 0.744 | – | – | – | 90 | [52] |
Prussian blue | CA, CI, SO | CGP | – | 50–1400 | – | 180 | – | 120 (−14%) | – | [57] |
Conductive layer | CD | NH4+ ISE | – | 5–255 | 3 | 25 | – | – | – | [98] |
β-cyclodextrin/poly(3,4-ethylene dioxythiophene) | – | GCE | SCE | 100–10,000 | 50 | 60 | – | 30 (−5%) | – | [81] |
Fe3O4@polyaniline | – | GCE | – | 0.02–1 | 0.18 | – | – | 30 (−10%) | 104.9 | [82] |
PVA-styryl pyridinium | CD | pH–FET | Ag/AgCl | 20–2000 | 20 | 120–180 | 40 | <1 | – | [103] |
Silicalite | CD | pH–FET | Ag/AgCl | 0–2000 | 5 | – | 40 | 365 (−43.3%) | – | [105] |
BEA gold (Zeolites) | CD | pH–FET | Ag/AgCl | 0–2000 | 10 | – | 40 | – | – | [80] |
Calix [4]pyrrole | – | GCE | Ag/AgCl | 10–10,000 | ~1 | 54.1 | – | – | [83] | |
Zeolite paraffin | – | CPE | Ag/AgCl | 0.1–100 | 0.079 | <50 | 52 | – | – | [84] |
MWCNTs | CD | CPE | Ag/AgCl | 1000–50,000 | – | 900–3600 | 57.01 | – | – | [78] |
Cu2O@MIP | – | SPCE | 0–0.075 | 0.022 | – | 2.16 µA/nM | 35 | 93 | [109] | |
Polyethyleneimine/phosphotungstic acid | – | ITO | SCE | 0.125–62.5 | 0.06 | 200 | – | – | [110] | |
Cu | – | Carbon | SCE | 6–378 | 0.0746 | – | – | – | 98 | [111] |
rGO-AgNPs | – | GCE | – | 5 × 10−5–1.5 × 10–3 | 1.51×10−5 | – | – | – | 100 | [102] |
2-hydroxymethacrylate/methyl methacrylate/graphene oxide | – | GCE | – | 44.2–26.2 | 16.6 | 120 | – | – | – | [112] |
MWCNTs-inu-TiO2 | – | CPE | Ag/AgCl | 0.2–1000 | 0.06 | – | – | 240 (−10%) | – | [107] |
Nafion/graphene QDs | – | Au | Ag/AgCl | 0.97–450 | – | – | – | – | – | [87] |
Cobalt chloride | – | Carbon | AgCl | 44–354 | – | – | – | – | – | [28] |
AgNPs/folic acid/MWCNTs | – | CPE | SCE | 0.01–200 | 0.008 | 1.5 | 50 | 14 (−5%) | 96 | [53] |
5. Concluding Remarks
