The Effect of Farmyard Manure and Mineral Fertilizers on Sugar Beet Beetroot and Top Yield and Soil Chemical Parameters

Abstract

In order to recommend the dose of fertilization for sugar beet under currently unstable weather conditions, we analysed beetroot and top yields, sugar content (SC), and the effect of fertilization on soil chemistry over a three-year period (2016–2018). All three years were characterized by different weather conditions. The year 2016 was very warm and very dry. The year 2017 was warm with normal precipitation. The year 2018 was extraordinary warm and very dry. We compared the following ten fertilization treatments: unfertilized control, farmyard manure (FYM), mineral fertilizers NPK1–4, and FYM + NPK1–4. The applications of FYM, NPK, and FYM + NPK resulted in significantly higher yields of beetroots and tops as compared with the control, while no significant differences were recorded among FYM, NPK, and FYM + NPK treatments. The SC was not affected by the fertilization. The application of NPK resulted in a lower pH value, while the highest values were recorded for the control and FYM treatments. The application of FYM + NPK increased the content of organic carbon (Corg) in the soil, the total content of nitrogen (Ntot), and P and K concentrations. According to the results of the linear-plateau model, the recommended dose of N is 112 kg ha⁻¹, corresponding to a beetroot yield of 66 t ha⁻¹.

1. Introduction

Sugar beet is one of the most important crops in the EU, as it is the only raw material for sugar extraction. Sugar beet acts as a good breaker of cereal crop rotations in the field and is also a good pre-crop for cereals (except for spring barley [1]), which are the most abundant arable crops in the EU. During most of the 20th century, sugar beet was a strategic crop in the Czech Republic. With the change from a centrally planned economy to a market economy in 1989, followed by the application of EU quotas restricting beetroot yields, sugar beet has undergone significant changes both in regards to the size of sown areas and in yields per hectare. Today, sugar beet is grown on an average area of 61,000 ha in the Czech Republic.

Beetroot and top yield and the quality of sugar beet are affected by a wide range of factors. Some of these factors are controllable by the farmers, such as crop rotation [2], tillage practices [3,4,5,6], or fertilization, however, some of them are not, such as weather conditions [7]. Fertilization represents a crucial factor influencing the final yield and quality, especially fertilization with nitrogen (N). The under application of N leads to a lower yield of beetroots and lower sucrose yield, while an over–application of N leads to imbalanced partitioning of assimilates, decreased sucrose content, and increased concentrations of impurities, resulting in reduced sucrose extraction [3,8,9,10,11,12] due to higher water retention by the beetroots and a lower amount of dry matter. An over–application of N also increases the concentration of soluble N compounds in the beetroots and this prevents subsequent extraction of sugar.

The determination of the optimal nitrogen dose varies from site to site, and therefore is site-specific dose. According to Chatterjee et al. [12], a single dose of 146 kg ha⁻¹ of N was recommended in North Dakota and Minnesota for sugar beet, irrespective of soil type and soil organic matter content, but this recommendation should be lowered to 112 kg ha⁻¹ of N, based on their two years of research. According toDeBruyn et al. [13], a dose of 157 kg ha⁻¹ of N was associated with the highest beetroot yield, while 136 kg ha⁻¹ of N was associated with the highest profit, in their three year experiment in Canada. In Europe, much attention is being paid to sugar beet nutrition experiments. Islamgulov et al. [14] experimented with the hybrid Hercules and found that 160 kg ha⁻¹ of N provided the highest economic efficiency under the conditions of the middle Cis-Ural region. According to Malnou et al. [15], who analysed the response of sugar beet to N fertilization at five sites within the UK, a dose of 100 kg of N per ha, in the absence of organic manure, should be applied for maximum yield. Similar results (100–110 kg ha⁻¹ of N) were published by Jaggard et al. [16], who analysed 161 experiments from England in their meta-analysis. The optimal dose can be determined by modelling. There are several models applicable depending on the crop evaluated, the data obtained, and the answer to the question being asked [17]. The quadratic model offers an answer to the maximum yield depending on the dose of nutrients. This model is very suitable for winter wheat because, with an increasing dose of nitrogen, wheat yields initially increase and begin to decline after reaching a critical value [18]. However, determining the dose of nutrients, in this way, may not be statistically significantly different from the lower dose of applied nutrients. Not every crop follows a parabolic course for the dependence of yields and doses of applied nutrients. For example, the reaction of sugar beet yields on doses of nitrogen may be linear [19], even the differences between the analysed fertilizer treatments are not significant. In that case, a linear-plateau model can provide useable answers [12,17,19].

Previously, the sugar beet crop, in the Czech Republic, was commonly fertilized with organic manures. We deliberately state “previously”, because today’s situation is completely different. There is a shortage of organic manure due to a reduction in animal production and there has been a significant split between animal and plant production, manifested by an insufficient amount of organic matter incorporated into the soil. The common doses of farmyard manure applied directly to potatoes and sugar beet range from 20 to 40 tons per hectare in the Czech Republic. As compared with mineral fertilizers, the content of nutrients in organic manures is non-standardized. Thus, the nutrient content may vary, depending on the animals from which it came, their diet, and other aspects. The mineralization process is also strongly dependent on weather conditions [20], and therefore farmers may not know exactly how much nutrients they applied to the soil, which may explain the recommendation to not use farmyard manure for sugar beet fertilization [21,22]. However, rising prices for mineral fertilizers [21] and the practice of growing sugar beet for the organic market [23] have increased the interest in the application of organic manures to sugar beet, especially in the USA, because the application of manures directly to sugar beet has a long tradition in Europe. Organic manures work in two ways. The first way represents direct releasing of nutrients into the soil environment through the process of mineralization. The second way represents the beneficial influence on the soil’s physical, chemical, and biological properties [24,25,26,27,28,29], especially maintaining and increasing soil organic carbon (SOC) content. This indirect positive effect of livestock manure on crop yields was evidenced by Hlisnikovský et al. [18].

Concerning the issues discussed above, we analysed a three-year sequence in a long-term field experiment, and focused on how mineral fertilizers (different doses, NPK1–4), farmyard manure (FYM), and combinations of FYM and NPK (FYM + NPK1–4) affected the yield and quality of sugar beet beetroots and tops. In this paper, we also recommend the dose of fertilizers according to the linear-plateau regression model. The evaluation included three years (2016, 2017, and 2018). All three years were characterized by different weather conditions. The year 2016 was very warm and very dry, but with relatively good conditions for sugar beet. The year 2017 was warm, with normal precipitation. The year 2018 was extraordinary warm and very dry, significantly affecting sugar beet beetroot and top yields, therefore, in our experiment, we covered the unfavourable conditions that occurred more frequently and were connected with global weather change. Finally, an analysis of soil properties affected by the fertilizer treatments is also provided.

2. Materials and Methods

2.1. Site Description

The long-term field trial was located on the western border of the city of Prague (the Czech Republic, Central Europe, temperate climate zone, 50°05′15″ N, 14°17′28″ E). The trial was established to study the effect of different fertilizer treatments and crop rotations on yield and quality of arable crops and soil chemical properties. The year the trial was established was 1954. The annual mean precipitation and mean temperature from the establishment of the trial is shown in Figure 1. The standard climatological long-term average (1954–2019) precipitation and temperature was 490.4 mm and 8.65 °C, respectively. The standard climatological normal (1961–1990) of the precipitation and temperature was 472.8 mm and 7.97 °C, respectively. The average annual precipitation for the years 2016, 2017, and 2018 was 382.1, 470.0, and 345.3 mm, respectively. The average annual temperature for the same years was 10.0, 9.9, and 11.1 °C, respectively. The average temperature at the site had an increasing trend, and total precipitation also increased slightly (Figure 1). According to Kožnarová and Klabzuba [30], all three years were characterized by different weather conditions. The year 2016 was very warm and very dry, with conditions relatively good for sugar beet. The year 2017 was warm with normal precipitation, providing optimal conditions for sugar beet. The year 2018 was extraordinary warm and very dry, significantly reducing beetroot and top yields. The altitude of the trial site is 370 m a.s.l. According to the World Reference Base [31], the soil type is haplic Luvisol.

2.2. Experimental Design Description

The long-term field trial consisted of five fields, marked as I, II, III, IV, and B. Each field consisted of 96 experimental plots (12 × 12 m), where 24 different fertilizer treatments were applied in four replications (24 × 4 = 96). Each field was arranged in a completely randomized block design. The results used, in this paper, analysed the yield and quality of sugar beet from fields IV (2016), III (2017), and II (2018). The crop rotation in these fields was equal, consisting of red clover, red clover, winter wheat, sugar beet, spring barley, potatoes, winter wheat, sugar beet, and spring barley. In this paper, we analysed the sugar beet following the red clover-winter wheat sequence.Among the 24 fertilizer treatments, the following 10 fertilizer treatments were analysed in this paper: (1) the control (unfertilized since 1954), (2) NPK1, (3) NPK2, (4) NPK3, (5) NPK4, (6) the farmyard manure (FYM), (7) FYM + NPK1, (8) FYM + NPK2, (9) FYM + NPK3, and (10) FYM + NPK4. The FYM was applied in October before moderate deep tillage (0.2 m) at a dose of 21 t ha⁻¹. The content of nutrients in the applied FYM was approximately 105 kg, 39 kg, and 124 kg of N, P, and K ha⁻¹, respectively. The doses of mineral N, P, and K are shown in

Table 1. Doses of applied N, P, and K in the analysed fertilizer treatments.

Fertilizer Treatment	N (kg ha−1)	P (kg ha−1)	K (kg ha−1)
NPK1	80	64	150
NPK2	120	64	150
NPK3	160	80	200
NPK4	200	80	200
FYM + NPK1	(105) + 80	(39) + 64	(124) + 150
FYM + NPK2	(105) + 120	(39) + 64	(124) + 150
FYM + NPK3	(105) + 160	(39) + 80	(124) + 200
FYM + NPK4	(105) + 200	(39) + 80	(124) + 200

Note: Values in parentheses represent the expected amount of nutrients provided by the FYM.

.

Mineral N was applied as lime ammonium nitrate (27% N), mineral P as the superphosphate (8.3% P), and mineral K as potassium chloride (49.8% K). Mineral P and K fertilizers were applied in autumn and were incorporated into the soil by moderate deep tillage (0.2 m). Mineral N was applied in the spring, before the beet planting. The harvest of the sugar beet was in October. The sugar beet tops from each experimental plot were separated from the beetroots by hand trimmers and weighed in a net using a mobile digital scale. The harvest of sugar beet beetroots was done using a root crops digger. The beetroots were, then, weighted in the same way as the sugar beet tops, using the nets and mobile digital scale.

2.3. Sugar Beet Analyses

2.3.1. Nitrogen and Phosphorus Content in Plant Materials

Nitrogen and phosphorus contained in plant tissues were determined by mineralization with a mixture of sulfuric acid, hydrogen peroxide, and selenium. A portion of the analysed sample was oxidized with hydrogen peroxide in concentrated sulfuric acid. After decomposition of the hydrogen peroxide and distillation of the water, the mineralization was completed by boiling with sulfuric acid under the catalytic action of selenium. The resulting solution was analysed using a San plus System SKALAR analyser (Skalar Analytical B.V., Breda, The Netherlands).

2.3.2. The Contents of K, Ca, Mg, and Na in Plant Materials

The contents of K, Ca, Mg, and Na in plant tissues were determined by oxidation with hydrogen peroxide in a concentrated nitric acid medium in a closed system with a controlled temperature rise, using a Milestone microwave digestion system (Milestone Inc., Sorisole, Italy). The final analysis was carried out using a ICP–OES Trace Scan device (Thermo Jarrel Ash, Trace Scan, Franklin, TN, USA).

2.3.3. Sugar Content Analysis

Sampling and determination of sugar content were performed following the ČSN 46 2110 standard. Laboratory processing of whole sugar beet beetroots bean with its cleaning and subsequent mechanical processing. Beetroots were cut into slices to represent its entire profile. In this way, a sample was taken from each beetroot and further grated on a mechanical grater. The grated material was thoroughly mixed to be sufficiently homogeneous. From the sample, thus prepared, 26 g was again weighed, put into a beaker, and circumfused with the extraction solution. This was followed by heating in a water bath heated to 80 °C for 30 min. After this time, the samples were cooled to room temperature, filtered through a filter, and the filtrate was poured through a tube of an automatic polarimeter (Polarimeter MCP 200, Anton Paar, Graz, Austria).

2.4. Soil Analysis

The samples of the soil (Ap horizon, 0–30 cm) were taken using a soil probe. Totally, four soil samples were taken from each experimental plot. The pH value was analysed potentiometrically (inoLab pH 730, WTW, Xylem Analytics, Weilheim, Germany). The content of soil organic carbon (Corg) was analysed according to [2,3]. The content of nitrogen (Ntot) was done using sulfuric acid in the heating block (Tecator, Sweden), and following the Kjeldahl method [32]. The contents of soil P, K, Ca, and Mg were analysed via the Mehlich III solution [33], followed by ICP-OES analysis (Thermo Scientific iCAP 7400 Duo, Thermo Fisher Scientific, Cambridge, UK).

2.5. Data Analyses

The analysis of variance (ANOVA) was used to evaluate the effect of fertilizer treatment in one season. For the evaluation of fertilizer treatment, season, and their interaction, the multivariate analysis of variance (MANOVA) was used. Both analyses were followed by Tukey’s HSD post hoc test to select the treatments and seasons that differentiated significantly. To perform all analyses, we used STATISTICA 13.3 software (TIBCO Software, Palo Alto, CA, USA). The linear-plateau model was calculated using the R software (R: A language and environment for statistical computing. R Foundation for Statistical Computing, Vienna, Austria, 2020), together with the three R packages [34,35,36].

3. Results

3.1. The Effect of Farmyard Manure (FYM) on Sugar Beet Beetroot and Top Yield

If we compare the effect of manure application, we find that the beetroot yield in the observed period (2016–2018) was significantly affected by both the fertilization treatment (d.f. = 1, F = 13.58, p < 0.001) and especially the weather conditions (d.f. = 2, F = 73.48, p < 0.002). The effect of the interaction between the treatment and year was also significant (d.f. = 2, F = 4.29; p < 0.03). The conditions of the year had the highest impact on beetroot yield (80%), followed by the fertilizer treatment (15%), and their interaction (5%).

The application of the FYM provided comparable results as the control. Significantly higher yields were recorded only in 2016 (

Table 2. The beetroot and top yield as affected by the fertilizer treatment (control and farmyard manure (FYM)) and year (2016–2018).

	Beetroot Yield (t ha−1)				Top Yield (t ha−1)
	2016	2017	2018	$\overline{\mathrm{X}}$	2016	2017	2018	$\overline{\mathrm{X}}$
Control	57.4 ± 4.3A	65.7 ± 2.0A	35.6 ± 4.0A	52.9 ± 4.3A	20.4 ± 1.5A	22.8 ± 0.6A	9.0 ± 0.1A	17.4 ± 1.9A
FYM	75.0 ± 1.1B	68.7 ± 1.0A	39.9 ± 2.3A	61.2 ± 4.7B	23.8 ± 0.6A	24.8 ± 1.7A	9.6 ± 0.9A	19.4 ± 2.2B
	66.2 ± 3.9Bb	67.2 ± 1.2b	37.8 ± 2.3a		22.1 ± 1.0b	23.8 ± 0.9b	9.3 ± 0.4a

Note: The mean values with the standard error of the mean followed by the same letter (small letters “a”, horizontally; and big letters ”A”, vertically) are not significantly different (p, 0.05).

). The average beetroot yield was 52.9 t ha⁻¹ in the control, and 61.2 t ha⁻¹ in the FYM treatment (2016–2018, Table 2). Comparing the years, the average yield was 66.2 t ha⁻¹ and 67.2 t ha⁻¹ in 2016 and 2017, respectively (without a statistical difference), while the significantly lower yield was recorded in 2018 (37.8 t ha⁻¹) (Table 2).

In the individual years, the top yield was not affected by the FYM application (Table 2). However, for the entire evaluated period (2016–2018), the differences among the compared treatments (d.f. = 1, F = 5.5, p < 0.03) and years (d.f. = 2, F = 113.0, p < 0.001) were significant. While the effect of the year was 95%, the effect of fertilization was only 5%. As in the case of beetroots, this means that the differences between the compared fertilization treatments were very low, while the fluctuation between the years was very high (caused mainly by the severe drought in 2018). The average top yield was 17.4 t ha⁻¹ in the control, while it was 19.4 t ha⁻¹ in the FYM treatment. Comparing the years, the highest yields were recorded in 2017 (23.8 t ha⁻¹), followed by 2016 (22.1 t ha⁻¹), and 2018 (9.3 t ha⁻¹) (Table 2).

3.2. The Effect of Mineral NPK on Sugar Beet Beetroot and Top Yield

If we compare the entire period (2016–2018), the application of mineral NPK fertilizers generally increased the beetroot yield significantly (

Table 3. The beetroot and top yield as affected by the fertilizer treatment (control, NPK1–4) and years (2016–2018).

	Beetroot Yield (t ha−1)				Top Yield (t ha−1)
	2016	2017	2018	$\overline{\mathrm{X}}$	2016	2017	2018	$\overline{\mathrm{X}}$
Control	57.4 ± 4.3A	65.7 ± 2.0A	35.6 ± 4.0A	52.9 ± 4.3A	20.4 ± 1.5A	22.8 ± 0.6A	9.0 ± 0.1A	17.4 ± 1.9A
NPK1	70.3 ± 1.3AB	72.9 ± 3.1A	40.6 ± 1.9AB	61.3 ± 4.6B	27.8 ± 1.3B	28.2 ± 0.7B	11.8 ± 0.6B	22.6 ± 2.3B
NPK2	70.7 ± 3.8AB	73.5 ± 2.5A	45.7 ± 0.7ABC	63.3 ± 4.0B	29.3 ± 1.5B	28.8 ± 1.1B	13.0 ± 0.5B	23.7 ± 2.4B
NPK3	68.3 ± 2.7AB	73.8 ± 2.3A	46.1 ± 0.8BC	62.7 ± 3.8B	32.6 ± 1.3B	30.5 ± 1.3BC	12.0 ± 0.4B	25.0 ± 2.8BC
NPK4	74.5 ± 4.3B	75.0 ± 2.0A	53.8 ± 2.6C	67.7 ± 3.4B	31.4 ± 0.7B	35.1 ± 1.9C	13.8 ± 0.6B	26.8 ± 2.9C
	68.2 ± 1.9b	72.2 ± 1.2b	44.4 ± 1.7a		28.3 ± 1.1b	29.1 ± 1.0b	11.9 ± 0.4a

Note: The mean values with the standard error of the mean followed by the same letter ( small letters “a”, horizontally and big letters “A”, vertically) are not significantly different (p, 0.05).

). According to MANOVA, the beetroot yield was mainly affected by the year (d.f. = 2, F = 146.3, p < 0.0001, 92%), showing a very high fluctuation among the years. The highest average yield was recorded in 2017 (72.2 t ha⁻¹), followed by 2016 (68.2 t ha⁻¹), and 2018 (44.4 t ha⁻¹). The effect of the fertilizer treatment was also significant (d.f. = 4, F = 11.4, p < 0.001), but the only significant difference was recorded between the control and NPK treatments. However, no significant differences among NPK1–4 treatments were recorded over the entire period (Table 3). The average beetroot yield was 52.9 t ha⁻¹ (control), 61.3 t ha⁻¹ (NPK1), 62,7 t ha⁻¹ (NPK3), 63.3 t ha⁻¹ (NPK2), and 67.7 t ha⁻¹ (NPK4). When only NPK treatments were considered, yield response to N rates across three years plateaued at 112 kg ha⁻¹ N with a corresponding beetroot yield of 66 t ha⁻¹ (Figure 2, left).

In the case of the sugar beet top yield, the effect of the year (d.f. = 2, F = 425.9, p < 0.0001), fertilizer treatments (d.f. = 4, F = 34.3, p < 0.001), and their interactions (d.f. = 8, F = 3.8, p < 0.002) was significant. The lowest average top yield over the evaluated period was provided by the control treatment (17.4 t ha⁻¹). Significantly higher top yields were recorded in NPK treatments, with the highest top yield in the NPK4 treatment (26.8 t ha⁻¹) (Table 3). The year again had the greatest impact on the top yield (92%), followed by the fertilization treatment (7%). Comparable top yields were recorded in the years 2016 (28.3 t ha⁻¹) and 2017 (29.1 t ha⁻¹), while a significantly lower top yield was recorded in the dry year 2018 (11.9 t ha⁻¹) (Table 3). According to the linear-plateau model, the mean top yield response to N rates across three years plateaued at 122 kg ha⁻¹ N, with a corresponding top yield of 25 t ha⁻¹ (Figure 2, right).

3.3. Comparison of the FYM and FYM + NPK Treatments

Over the entire evalutated period (2016–2018), the combined application of the FYM with mineral NPK fertilizers significantly increased the beetroot yields (d.f. = 5, F = 19.6, p < 0.001) (

Table 4. The beetroot and top yield as affected by the fertilizer treatment (control, FYM, FYM + NPK1–4) and years (2016–2018).

	Beetroot Yield (t ha−1)				Top Yield (t ha−1)
	2016	2017	2018	$\overline{\mathrm{X}}$	2016	2017	2018	$\overline{\mathrm{X}}$
Control	57.4 ± 4.3A	65.7 ± 2.0A	35.6 ± 4.0A	52.9 ± 4.3A	20.4 ± 1.5A	22.8 ± 0.6A	9.0 ± 0.1A	17.4 ± 1.9A
FYM	75.0 ± 1.1B	68.7 ± 1.0AB	39.9 ± 2.3AB	61.2 ± 4.7B	23.8 ± 0.6A	24.8 ± 1.7AB	9.6 ± 0.9A	19.4 ± 2.2A
FYM+NPK1	76.9 ± 1.5B	74.4 ± 1.7BC	47.6 ± 0.9BC	66.3 ± 4.1C	32.8 ± 1.2B	30.1 ± 1.2BC	13.2 ± 0.3B	25.4 ± 2.7B
FYM+NPK2	73.3 ± 1.5B	74.3 ± 1.5BC	50.0 ± 1.4C	65.9 ± 3.5BC	31.9 ± 1.1B	30.5 ± 1.9BC	13.3 ± 0.4B	25.2 ± 2.6B
FYM+NPK3	75.1 ± 1.0B	73.6 ± 0.6BC	47.8 ± 1.8BC	65.5 ± 3.8BC	33.7 ± 0.2B	33.4 ± 0.9C	13.5 ± 0.3B	26.9 ± 2.9B
FYM+NPK4	70.9 ± 3.0B	77.8 ± 2.1C	50.0 ± 1.3C	66.2 ± 3.8C	30.3 ± 1.0B	36.4 ± 2.2C	13.8 ± 0.2B	26.8 ± 3.0B
	71.4 ± 1.6b	72.4 ± 1.0b	45.1 ± 1.4a		28.8 ± 1.1b	29.7 ± 1.1b	12.1 ± 0.4a

Note: The mean values with the standard error of the mean followed by the same letter ( small letters “a”, horizontally; and big letters “A”, vertically) are not significantly different (p, 0.05).

). The lowest yield was recorded in the control (52.9 t ha⁻¹), followed by the FYM treatment (61.2 t ha⁻¹). The addition of mineral NPK fertilizers significantly increased the beetroot yields as compared with the control and FYM treatments (Table 4), ranging from 65.5 t ha⁻¹ (FYM + NPK3) to 66.3 t ha⁻¹ (FYM + NPK1). The differences among all FYM + NPK treatments were insignificant. The effect of the year was also significant (d.f. = 2, F = 333.7, p < 0.0001), as well as the year*treatment interaction (d.f. = 10, F = 2.5, p = 0.014). The comparison of years indicated the same results as the previous evaluation. While in the years with relatively favourable conditions (2016 and 2017) the differences were not significant (the average yields were 71.4 t ha⁻¹ in 2016 and 72.4 t ha⁻¹ in 2017), the conditions of the year 2018 sharply reduced the beetroot yield to an average value of 45.1 t ha⁻¹. The beetroot yield response to different rates of FYM and NPK fertilizers plateaued at 165 kg ha⁻¹ N, with a corresponding beet yield 66 t ha⁻¹ (Figure 3, left).

A similar effect of mineral fertilizers was found for the top yields. The top yield was significantly affected by the year (d.f. = 2, F = 493.8, p < 0.0001), fertilization treatment (d.f. = 5, F = 41.8, p < 0.0001), and their interaction (d.f. = 10, F = 4.5, p < 0.001). The lowest yields were provided by the control and FYM treatments (17.4 and 19.4 t ha⁻¹, respectively) (Table 4). The addition of mineral fertilizers increased the top yields significantly, ranging from 25.2 t ha⁻¹ (FYM + NPK2) to 26.9 t ha⁻¹ (FYM + NPK3). The differences between the FYM + NPK treatments were insignificant. Comparing the years, dry conditions during 2018 resulted in the lowest yield of the tops (12.1 t ha⁻¹), while significantly higher yields were recorded in 2016 and 2017 (28.8 and 29.7 t ha⁻¹, respectively). According to the linear-plateau model, the response of the sugar beet tops plateaued at 181 kg ha⁻¹ N, with a corresponding yield of 24 t ha⁻¹ (Figure 3, right).

3.4. The Effect of Fertilization on Sugar Content (SC) and Chemical Elements Concentration

We must admit that due to limited funds, analyses of sugar beet in reduced quantities were performed over the years 2016–2018. This means that no repeated measurements were performed from each fertilizer treatment every single year. Therefore, the results of the statistical analysis presented here represent the average results for the entire analysed period. It is, therefore, necessary to take the results with a grain of salt.

According to the statistical analysis, no significant differences were recorded between the fertilizer treatments for any analysed parameter (the SC and the concentration of N, P, K, Ca, Mg, and Na) of the sugar beetroots. The SC varied from 19.7% (NPK4) to 21.9% (NPK1) (

Table 5. The sugar content (%) and concentrations of N, P, K, Ca, Mg, and Na (%) in sugar beet beetroots as affected by the fertilizer treatment and over the years 2016–2018.

	SC (%)	N (%)	P (%)	K (%)	Ca (%)	Mg (%)	Na (%)
Control	19.9 ± 0.8	0.19 ± 0.01	0.02 ± 0.01	0.16 ± 0.03	0.07 ± 0.01	0.05 ± 0.01	0.006 ± 0.002
NPK1	21.9 ± 1.3	0.20 ± 0.02	0.02 ± 0.01	0.17 ± 0.03	0.05 ± 0.01	0.05 ± 0.01	0.005 ± 0.001
NPK2	20.5 ± 0.9	0.20 ± 0.01	0.08 ± 0.06	0.17 ± 0.02	0.16 ± 0.11	0.05 ± 0.01	0.006 ± 0.001
NPK3	19.8 ± 0.3	0.19 ± 0.02	0.02 ± 0.01	0.16 ± 0.03	0.05 ± 0.01	0.05 ± 0.01	0.006 ± 0.001
NPK4	19.7 ± 0.9	0.20 ± 0.02	0.02 ± 0.01	0.18 ± 0.04	0.04 ± 0.01	0.05 ± 0.01	0.007 ± 0.001
FYM	20.1 ± 0.5	0.19 ± 0.01	0.02 ± 0.01	0.15 ± 0.02	0.05 ± 0.01	0.05 ± 0.01	0.007 ± 0.001
FYM + NPK1	21.1 ± 1.1	0.20 ± 0.02	0.02 ± 0.01	0.16 ± 0.02	0.05 ± 0.01	0.05 ± 0.01	0.008 ± 0.001
FYM + NPK2	21.2 ± 0.8	0.22 ± 0.02	0.02 ± 0.01	0.20 ± 0.03	0.05 ± 0.01	0.05 ± 0.01	0.010 ± 0.003
FYM + NPK3	19.8 ± 0.7	0.20 ± 0.02	0.02 ± 0.01	0.16 ± 0.03	0.05 ± 0.01	0.05 ± 0.01	0.007 ± 0.001
FYM + NPK4	20.7 ± 0.6	0.21 ± 0.01	0.02 ± 0.01	0.17 ± 0.03	0.04 ± 0.01	0.05 ± 0.01	0.007 ± 0.001

Note: The mean values without letters were not significantly different.

). The concentration of N, P, K, Ca, Mg, and Na was not affected by the fertilizer treatment (Table 5).

Similar results were recorded in the case of the sugar beet tops, where the concentrations of N, P, K, Ca, and Mg were analysed. Except for P, the effect of the fertilizer treatment was insignificant. All results are shown in

Table 6. The concentrations of N, P, K, Ca, and Mg in sugar beet tops as affected by the fertilizer treatment and over the years 2016–2018.

	N (%)	P (%)	K (%)	Ca (%)	Mg (%)
Control	2.54 ± 0.21	0.15 ± 0.01A	3.66 ± 0.17	1.38 ± 0.12	0.85 ± 0.10
NPK1	2.39 ± 0.23	0.19 ± 0.01 AB	4.35 ± 0.21	1.26 ± 0.15	0.84 ± 0.10
NPK2	2.63 ± 0.15	0.20 ± 0.01 AB	4.43 ± 0.24	1.15 ± 0.18	0.79 ± 0.11
NPK3	2.67 ± 0.17	0.19 ± 0.01 AB	4.11 ± 0.11	1.25 ± 0.17	0.95 ± 0.10
NPK4	3.03 ± 0.16	0.23 ± 0.02B	4.20 ± 0.09	1.14 ± 0.17	0.84 ± 0.13
FYM	2.51 ± 0.22	0.18 ± 0.01AB	3.36 ± 0.56	1.25 ± 0.06	0.83 ± 0.02
FYM + NPK1	2.71 ± 0.29	0.23 ± 0.03B	3.85 ± 0.18	1.04 ± 0.11	0.76 ± 0.06
FYM + NPK2	2.96 ± 0.24	0.22 ± 0.01B	4.14 ± 0.06	1.10 ± 0.10	0.82 ± 0.06
FYM + NPK3	3.07 ± 0.12	0.22 ± 0.01B	3.55 ± 0.08	1.09 ± 0.06	0.89 ± 0.05
FYM + NPK4	2.89 ± 0.11	0.22 ± 0.01B	3.94 ± 0.19	1.08 ± 0.08	0.84 ± 0.01

Note: The mean values with the standard error of the mean followed by the same letter are not significantly different (p, 0.05). Mean values without letters were not significantly different.

. In the case of P, the mean concentration varied from 0.15% (control) to 0.23% (NPK4 and FYM + NPK1 treatments). Higher concentrations of the P were found in the FYM + NPK treatments as compared with the control, FYM, and NPK treatments (Table 6).

3.5. The Effect of the Fertilizer Treatments on the Soil Properties

The application of different combinations and doses of fertilizers did not affect the value of the soil pH. The average values ranged from 6.08 (NPK3) to 6.60 (FYM). The concentration of N was slightly affected by the fertilizer treatment. The lowest concentrations were recorded in the control and FYM treatments (0.13%), while the highest concentrations were recored in the FYM+NPK4 treatment (0.16%). All other treatments provided results fitting within these extreme limits. In the case of soil carbon content, the distribution of the fertilizer treatments is clearer. The lowest C concentration was recorded in the control treatment (0.99%). All FYM + NPK treatments differed significantly from this value, and ranged from 1.26% to 1.35%, while the FYM and all NPK treatments filled the space between the control and FYM + NPK treatments. The concentration of soil P significantly varied among the treatments with lowest concentration in the control (20 mg kg⁻¹) and FYM (29 mg kg⁻¹) treatments and highest concentrations in NPK4 (70 mg kg⁻¹) and FYM + NPK4 (93 mg kg⁻¹) treatments. A similar pattern was recorded in the case of K (lowest concentrations were in the control and FYM treatments, while the highest concentrations were in the NPK4 and FYM + NPK2 treatments) (

Table 7. The basic soil chemical properties as affected by the fertilizer treatment and over the years 2016–2018.

	pH	Ntot (%)	Corg (%)	P (mg kg−1)	K (mg kg−1)	Ca (mg kg−1)	Mg (mg kg−1)
Control	6.44 ± 0.16A	0.13 ± 0.01A	0.99 ± 0.04A	20 ± 4A	150 ± 7A	3097 ± 104	180 ± 9
NPK1	6.26 ± 0.18B	0.14 ± 0.01AB	1.10 ± 0.03AB	53 ± 10BC	182 ± 8ABC	2813 ± 121	150 ± 10
NPK2	6.20 ± 0.29B	0.14 ± 0.01AB	1.15 ± 0.05AB	59 ± 5CD	198 ± 11ABC	2951 ± 231	149 ± 3
NPK3	6.08 ± 0.08C	0.13 ± 0.01A	1.16 ± 0.05AB	52 ± 2BC	173 ± 14AB	2790 ± 99	147 ± 16
NPK4	6.20 ± 0.12B	0.14 ± 0.01AB	1.22 ± 0.04AB	70 ± 1CDE	195 ± 10ABC	2800 ± 139	141 ± 7
FYM	6.60 ± 0.17A	0.14 ± 0.01AB	1.19 ± 0.05AB	29 ± 5AB	166 ± 15A	3240 ± 214	187 ± 1
FYM + NPK1	6.46 ± 0.21A	0.15 ± 0.01AB	1.27 ± 0.07B	64 ± 1CDE	199 ± 23ABC	3154 ± 308	176 ± 15
FYM + NPK2	6.34 ± 0.20AB	0.15 ± 0.01AB	1.31 ± 0.10B	87 ± 6DE	246 ± 11CD	3031 ± 244	172 ± 10
FYM + NPK3	6.19 ± 0.11B	0.15 ± 0.01AB	1.26 ± 0.02AB	73 ± 3CDE	202 ± 13ABC	2891 ± 142	170 ± 5
FYM + NPK4	6.26 ± 0.20B	0.16 ± 0.01B	1.35 ± 0.07B	93 ± 12E	254 ± 24D	3022 ± 129	177 ± 3

Note: The mean values with the standard error of the mean followed by the same letter are not significantly different (p, 0.05). Mean values without letters were not significantly different.

). The concentrations of Ca and Mg were not affected by the fertilizer treatment (Table 7).

4. Discussion

As compared with the control, statistically higher beetroot yields in the FYM treatment were recorded only in 2016 (+17.6 t ha⁻¹). In the following years, the application of FYM resulted in comparable yields. If we compare the entire evaluated period (2016–2018), the application of FYM increased the average sugar beet beetroot yield by about 8 t ha⁻¹. In the case of the tops, no differences between the control and the FYM treatments were recorded in individual years. A comparison of the entire analysed period showed that the average top yield was significantly higher in the FYM treatment (+2.0 t ha⁻¹) (Table 2). As mentioned above, the mineralization of manure in the soil strongly depends on the weather and other soil parameters [20]. The years 2016 and 2017 represent seasons with relatively good (2016) and good (2017) conditions, resulting in very high yields in the control (especially in 2017, these yields are very high for the unfertilized control treatment and we assume that they are the result of exceptionally good climatic conditions during the season), and visible effect of the FYM (especially in 2016). The extremely unfavourable weather conditions in 2018 reduced beetroot yields by 43% and top yields by 69%. The explanation for the higher yields in the FYM treatment lies both in the direct supply of nutrients through mineralization and the course of mineralization. According to Barłóg et al. [8], three main periods of beetroot yield formation can be distinguished, i.e., early, midseason, and final period, with N requirements dominating in the first two stages. The FYM is a fertilizer with a high C/N ratio (in comparison with slurries), and contains a high amount of organic N that is not directly available to plants [20], therefore, FYM releases its nutrients slowly and over a longer period, covering critical periods of beet formation (if weather conditions allow it). A similar effect of FYM on sugar beet yield was published in [21]. According to their results, the yield response to different manure ratios across two years plateaued at 23 t ha⁻¹, with a corresponding beet yield of 62.2 t ha⁻¹. The sugar content (SC, %) was not affected by the FYM application. Both treatments (control and FYM) varied from 19.9% to 20.1%. The same situation happened in the case of other chemical elements in the beetroots and tops (Table 5 and Table 6), therefore, the application of the FYM provided higher yields and, consequently, a higher amount of sugar harvested from the field, without significant changes in sugar beet chemical composition. This also applies to the comparison of all other fertilization treatments (Table 5 and Table 6), except P concentration in sugar beet tops (Table 6), where P concentration slightly increases in NPK4 and all FYM + NPK treatments.

Application of mineral fertilizers significantly increased beetroot and top yield (Table 3). This result is expected and is in line with other published results [6,9,14,21], as N is the most important element for sugar beet and mineral fertilizers provide readily available N in precisely definable amounts. In our research, it was rather crucial to recommend an average dose of nitrogen that provided the best results during the years including both, the standard and the dry weather conditions. In the case of mineral fertilizers applied without organic manures, it is relatively simple and our results are comparable with other recommendations [12,15,16], while lower than recommendations of [13,14], but every experiment provides site-specific recommendations concerning soil and climate conditions of the site. In our case, a dose of 122 kg ha⁻¹ N represents a breakpoint between the linear and plateau functions of the developed model, with the corresponding beetroot yield of 66 t ha⁻¹. Application of N above this value does not increase the beetroot yield significantly.

The combined application of FYM and mineral fertilizers (FYM + NPK treatments) had a different course each year. In years with good climatic conditions, the beetroot yield fertilized with the FYM was comparable (2016) or slightly lower (2017, only FYM + NPK4 treatment provided significantly higher yields as compared with the FYM treatment) than in the FYM + NPK treatments (Table 4). A significant difference only became apparent with the advent of drought in 2018, when treatments fertilized with FYM + NPK provided higher yields than treatments fertilized only with FYM. In years with a normal course, manure could cover the demands of beets during the season and provided very good yields. However, in the event of a drought, the efficiency of manure decreased as it responded more sensitively to unsuitable climatic conditions. The positive benefit of mineral fertilizers was also manifested in the case of the tops. The combined application of FYM and mineral fertilizers provided, on average, higher yields than the application of FYM alone. These results were predictable. For this article, it was more important to analyse the response of beetroots and tops to the dose of nutrients and to determine the recommended dose. From this point of view, it is interesting that the breaking point of the linear-plateau model occurred at the same value as in the NPK treatments, i.e., 66 t ha⁻¹, but the amount of nitrogen increased to 165 kg ha⁻¹ (+53 kg ha⁻¹ N as compared with the NPK treatments). The same situation occurred in the case of the beet tops, where the break occurred at a yield of 24 t ha⁻¹, and at a dose of 181 kg ha⁻¹ N (+59 kg ha⁻¹ N as compared with the NPK treatments). According to the data, the combined application of FYM and NPK did not bring any massive improvement in yields as compared with NPK or FYM applied alone, showing that maximum yielding potential of the sugar beet was reached under local soil-climate conditions. According to [8], the maximum yield potential of sugar beet in Europe is between 110 and 150 t ha⁻¹ (calculations based on [7]), and around 80 t ha⁻¹ in Poland, but the farmers’ share of the actual yields is only 50 or 60% of that value.

According to the MANOVA results, both, beetroot and top yields were mainly affected by the weather conditions, while the effect of the fertilizer treatment was minor. This was mainly due to the extraordinary dry year in 2018. There is an increasing number of dry years and their frequent occurrence and weather instability, generally, are associated with the current global change in climate conditions. These extreme years should not be surprising in the coming period. The farmers in Europe are already adapting their approaches to this fact by selecting other crop varieties and species and adjusting the timing of cultivation [37].

A slightly different situation is found in the case of soil parameters. Application of NPK without organic manures resulted in generally lower pH values as compared with the control and FYM treatments (Table 7). The applications of FYM + NPK treatments resulted in between these two groups, which mean that FYM reduces the negative impact of NPK on soil pH. The same results were published by [24,38]. By affecting the value of the soil pH, organic manures also modify the environment for and activity of the microbial community in the soil [24], and the availability of nutrients. The concentration of soil N was not affected significantly by the fertilizer treatment, only high doses of applied mineral N (FYM + NPK4) resulted in significantly higher N concentration as compared with the control. In the case of P and K, the highest concentrations of both elements were recorded in FYM + NPK treatments, The combination of FYM with NPK significantly increased the soil C content. This result is in agreement with the results published by [24,39,40]. On the one hand, application of mineral fertilizers without manures can decrease soil carbon content when the C inputs to the soil from arable crops (including straw, roots, and post-harvest residues) are lower than the C decomposed by the soil microbial community. On the other hand, organic manures contain organic matter that directly affects the physiological, chemical, and biological properties of the soil. From this point of view, the combined application of FYM and mineral fertilizers results in maintaining soil fertility and is a sustainable approach to soil care [24,26,39].

5. Conclusions

The decisive factors determining sugar beet beetroot and top yield were weather conditions. During the years with relatively good (2016) and good (2017) conditions, the beetroot and top yield was on average 70 t ha⁻¹ and 28.7 t ha⁻¹, respectively. In the extraordinary dry year of 2018, the average beetroot and top yield decreased to 44 t ha⁻¹ and 12 t ha⁻¹, respectively.

The application of FYM at a dose of 21 t ha⁻¹ significantly increased the beetroot and top yield, if we evaluate the entire period (2016–2018). In individual years, we recorded a significant difference only in the case of beetroots, in 2016. In general, the yields with FYM treatment were always higher than in the case of the non-fertilized control.

The application of mineral fertilizers significantly increased beetroot and top yield as compared with the unfertilized control. According to the results of the linear-plateau model, a suitable N dose is 112 kg ha⁻¹ with a corresponding yield of 66 t ha⁻¹. This model took into account the average yields of years including standard and unsuitable climatic conditions.

In the case of the joint application of FYM and NPK, we did not record a significant increase in yield as compared with NPK applied alone.

The sugar content and the concentration of chemical elements in the beetroots and the tops were not significantly affected by the fertilization treatment, except for slightly higher concentrations of P in the tops.

The application of NPK in the soil resulted in lower pH values than we observed in the control and FYM treatments. The combined application of FYM and NPK slightly reduced the negative impact of NPK on soil pH. The application of NPK, FYM, and especially the combination of NPK and FYM significantly increased the content of Corg, P, and K in the soil.
