Correction: Takayama et al. Polyvinyl Butyral Addition Effects on Notched Charpy Impact Strength of Injection-Molded Glass Fiber-Reinforced Polypropylene. Polymers 2024, 16, 3472
Table and Figure Corrections
Reference
- Takayama, T.; Yuasa, Y.; Jiang, Q. Polyvinyl Butyral Addition Effects on Notched Charpy Impact Strength of Injection-Molded Glass Fiber-Reinforced Polypropylene. Polymers 2024, 16, 3472. [Google Scholar] [CrossRef] [PubMed]
PP (wt%) | GF (wt%) | MAH-PP (wt%) | PVB (wt%) | IFSS (MPa) | σw (MPa) | aiN (kJ/m2) | γi (N/mm) | φ (degree) | Lf (mm) | σFB (MPa) | σFB0 (MPa) |
---|---|---|---|---|---|---|---|---|---|---|---|
90 | 10 | 0 | 0 | 7.6 | 22.7 | 2.7 | 0.99 | 68.9 | 0.49 | 419 | 1928 |
80 | 20 | 0 | 0 | 7.4 | 21.4 | 3.5 | 0.43 | 63.9 | 0.50 | 326 | 1618 |
70 | 30 | 0 | 0 | 6.3 | 18.0 | 3.9 | 0.20 | 57.8 | 0.48 | 261 | 1460 |
89.5 | 10 | 0 | 0.5 | 8.4 | 22.4 | 2.1 | 0.65 | 69.2 | 0.50 | 389 | 1782 |
79.5 | 20 | 0 | 0.5 | 7.7 | 20.1 | 3.2 | 0.19 | 66.1 | 0.50 | 317 | 1520 |
69.5 | 30 | 0 | 0.5 | 6.9 | 17.4 | 4.2 | 0.04 | 56.3 | 0.50 | 286 | 1653 |
89 | 10 | 0 | 1 | 8.5 | 23.4 | 2.5 | 1.01 | 68.6 | 0.49 | 429 | 1981 |
79 | 20 | 0 | 1 | 7.3 | 20.2 | 3.3 | 0.33 | 59.0 | 0.50 | 325 | 1772 |
69 | 30 | 0 | 1 | 6.1 | 17.7 | 4.4 | 0.14 | 51.4 | 0.50 | 281 | 1843 |
85 | 10 | 0 | 5 | 7.2 | 20.3 | 2.5 | 1.77 | 71.4 | 0.48 | 391 | 1744 |
75 | 20 | 0 | 5 | 7.2 | 18.4 | 3.9 | 0.82 | 63.2 | 0.48 | 340 | 1706 |
65 | 30 | 0 | 5 | 5.7 | 14.6 | 5.0 | 0.48 | 56.2 | 0.49 | 281 | 1625 |
85 | 10 | 5 | 0 | 8.9 | 25.9 | 2.6 | 1.22 | 71.2 | 0.49 | 443 | 1975 |
75 | 20 | 5 | 0 | 8.5 | 25.3 | 5.0 | 0.57 | 66.5 | 0.49 | 418 | 1990 |
65 | 30 | 5 | 0 | 8.5 | 22.9 | 6.7 | 0.31 | 62.0 | 0.49 | 387 | 1987 |
84.5 | 10 | 5 | 0.5 | 8.2 | 24.8 | 3.1 | 0.99 | 72.2 | 0.48 | 468 | 2066 |
74.5 | 20 | 5 | 0.5 | 7.9 | 24.0 | 5.6 | 0.41 | 65.8 | 0.48 | 425 | 2044 |
64.5 | 30 | 5 | 0.5 | 7.8 | 22.2 | 6.9 | 0.20 | 59.6 | 0.49 | 383 | 2063 |
84 | 10 | 5 | 1 | 8.3 | 26.5 | 2.4 | 1.31 | 63.7 | 0.47 | 423 | 2106 |
74 | 20 | 5 | 1 | 8.0 | 25.6 | 4.8 | 0.57 | 61.1 | 0.48 | 406 | 2119 |
64 | 30 | 5 | 1 | 7.7 | 23.6 | 5.9 | 0.30 | 56.2 | 0.48 | 358 | 2077 |
80 | 10 | 5 | 5 | 8.0 | 25.2 | 2.5 | 2.13 | 69.4 | 0.48 | 412 | 1881 |
70 | 20 | 5 | 5 | 7.9 | 24.4 | 4.3 | 1.09 | 66.0 | 0.48 | 372 | 1780 |
60 | 30 | 5 | 5 | 7.8 | 23.0 | 5.8 | 0.71 | 61.9 | 0.50 | 342 | 1758 |
