Agarose/Spherical Activated Carbon Composite Gels for Recyclable and Shape-Configurable Electrodes

1
Department of Energy Systems Research, Ajou University, Suwon 16499, Korea
2
Department of Chemical Engineering, Ajou University, Suwon 16499, Korea
3
Department of Energy Systems, Soonchunhyang University, Asan 31583, Korea
*
Authors to whom correspondence should be addressed.
Polymers 2019, 11(5), 875; https://doi.org/10.3390/polym11050875
Received: 31 March 2019 / Revised: 6 May 2019 / Accepted: 10 May 2019 / Published: 14 May 2019
(This article belongs to the Special Issue Polymers for Electronic Applications)
  |
PDF [3514 KB, uploaded 14 May 2019]
  |

Abstract

Soft electrodes have been known as a key component in the engineering of flexible, wearable, and implantable energy-saving or powering devices. As environmental issues are emerging, the increase of electronic wastes due to the short replacement cycle of electronic products has become problematic. To address this issue, development of eco-friendly and recyclable materials is important, but has not yet been fully investigated. In this study, we demonstrated hydrogel-based electrode materials composed of agarose and spherical activated carbon (agar/SAC) that are easy to shape and recycle. Versatile engineering processes were applied thanks to the reversible gelation of the agarose matrix which enables the design of soft electrodes into various shapes such as thin films with structural hierarchy, microfibers, and even three-dimensional structures. The reversible sol–gel transition characteristics of the agar matrix enables the retrieval of materials and subsequent re-configuration into different shapes and structures. The electrical properties of the agar/SAC composite gels were controlled by gel compositions and ionic strength in the gel matrix. Finally, the composite gel was cut and re-contacted, forming conformal contact to show immediate restoration of the conductivity. View Full-Text
Keywords: agarose; hydrogels; activated carbon; soft electrodes; conducting polymers agarose; hydrogels; activated carbon; soft electrodes; conducting polymers
Figures

Graphical abstract

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited (CC BY 4.0).

Supplementary material

SciFeed

Share & Cite This Article

MDPI and ACS Style

Kim, J.S.; Kim, J.-H.; Cho, Y.; Shim, T.S. Agarose/Spherical Activated Carbon Composite Gels for Recyclable and Shape-Configurable Electrodes. Polymers 2019, 11, 875.
