Thermodynamics of Point Defects in Solids and Relation with the Bulk Properties: Recent Results
Abstract
:1. Introduction
2. Materials and Methods
3. Applying cB Model to High Pressure Diamond Anvil Measurements
4. Applications of the cB Model to Nuclear Fuels and Materials for Microelectronic Devices
5. Application of the cB Model to High T Superconductors
6. Applications of Usefulness in Geophysics and Seismology
7. Application of the cB Model to a Problem of Major Technological Interest
8. Search for Composition of Better Target Properties in Cu-Co-Si Alloys via Machine Learning
9. Recent Studies on the Foundation of the Physical Origin of the cB Model
9.1. Foundation of cB Model Studying the Interfacial Mobility Gradient in Thin Polymer Films Using Molecular Dynamics Simulations on a Layer-by-Layer Basis
9.2. Analytical Method for the Foundation of the cB Model Using Mie–Lennard–Jones Interatomic Potential
10. Summary and Conclusions
Author Contributions
Funding
Institutional Review Board Statement
Informed Consent Statement
Data Availability Statement
Conflicts of Interest
References
