Simulated Imagery Rendering Workflow for UAS-Based Photogrammetric 3D Reconstruction Accuracy Assessments

School of Civil and Construction Engineering, Oregon State University, 101 Kearney Hall, 1491 SW Campus Way, Corvallis, OR 97331, USA
Author to whom correspondence should be addressed.
Academic Editors: Gonzalo Pajares Martinsanz, Xiaofeng Li and Prasad S. Thenkabail
Received: 13 March 2017 / Revised: 17 April 2017 / Accepted: 19 April 2017 / Published: 22 April 2017
Full-Text   |   PDF [7727 KB, uploaded 22 April 2017]   |


Structure from motion (SfM) and MultiView Stereo (MVS) algorithms are increasingly being applied to imagery from unmanned aircraft systems (UAS) to generate point cloud data for various surveying and mapping applications. To date, the options for assessing the spatial accuracy of the SfM-MVS point clouds have primarily been limited to empirical accuracy assessments, which involve comparisons against reference data sets, which are both independent and of higher accuracy than the data they are being used to test. The acquisition of these reference data sets can be expensive, time consuming, and logistically challenging. Furthermore, these experiments are also almost always unable to be perfectly replicated and can contain numerous confounding variables, such as sun angle, cloud cover, wind, movement of objects in the scene, and camera thermal noise, to name a few. The combination of these factors leads to a situation in which robust, repeatable experiments are cost prohibitive, and the experiment results are frequently site-specific and condition-specific. Here, we present a workflow to render computer generated imagery using a virtual environment which can mimic the independent variables that would be experienced in a real-world UAS imagery acquisition scenario. The resultant modular workflow utilizes Blender, an open source computer graphics software, for the generation of photogrammetrically-accurate imagery suitable for SfM processing, with explicit control of camera interior orientation, exterior orientation, texture of objects in the scene, placement of objects in the scene, and ground control point (GCP) accuracy. The challenges and steps required to validate the photogrammetric accuracy of computer generated imagery are discussed, and an example experiment assessing accuracy of an SfM derived point cloud from imagery rendered using a computer graphics workflow is presented. The proposed workflow shows promise as a useful tool for sensitivity analysis and SfM-MVS experimentation. View Full-Text
Keywords: structure from motion; accuracy assessment; simulation; computer graphics; UAS structure from motion; accuracy assessment; simulation; computer graphics; UAS

Graphical abstract

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited (CC BY 4.0).
