Open AccessArticle
Remote Sens. 2014, 6(10), 10193-10214;

Assessing the Performance of MODIS NDVI and EVI for Seasonal Crop Yield Forecasting at the Ecodistrict Scale

Science and Technology Branch (S & T), Agriculture and Agri-Food Canada (AAFC), Lethbridge Research Centre, 5403 1st Avenue South, P.O. Box 3000, Lethbridge,AB T1J 4B1, Canada
AgroClimate, Geomatics, and Earth Observations Division (ACGEO), S & T, AAFC, 960 Carling Avenue, Ottawa, ON K1A 0C6, Canada
ACGEO, S & T, AAFC, 300-2010 12th Avenue, Regina, SK S4P OM3, Canada
Current Address: International Centre for Applied Climate Sciences, University of Southern Queensland, West Street, Toowoomba, QLD 4350, Australia
Authors to whom correspondence should be addressed.
Received: 25 August 2014 / Revised: 10 October 2014 / Accepted: 11 October 2014 / Published: 23 October 2014
(This article belongs to the Special Issue Remote Sensing in Food Production and Food Security)
Full-Text   |   PDF [8790 KB, uploaded 23 October 2014]   |


Crop yield forecasting plays a vital role in coping with the challenges of the impacts of climate change on agriculture. Improvements in the timeliness and accuracy of yield forecasting by incorporating near real-time remote sensing data and the use of sophisticated statistical methods can improve our capacity to respond effectively to these challenges. The objectives of this study were (i) to investigate the use of derived vegetation indices for the yield forecasting of spring wheat (Triticum aestivum L.) from the Moderate resolution Imaging Spectroradiometer (MODIS) at the ecodistrict scale across Western Canada with the Integrated Canadian Crop Yield Forecaster (ICCYF); and (ii) to compare the ICCYF-model based forecasts and their accuracy across two spatial scales-the ecodistrict and Census Agricultural Region (CAR), namely in CAR with previously reported ICCYF weak performance. Ecodistricts are areas with distinct climate, soil, landscape and ecological aspects, whereas CARs are census-based/statistically-delineated areas. Agroclimate variables combined respectively with MODIS-NDVI and MODIS-EVI indices were used as inputs for the in-season yield forecasting of spring wheat during the 2000–2010 period. Regression models were built based on a procedure of a leave-one-year-out. The results showed that both agroclimate + MODIS-NDVI and agroclimate + MODIS-EVI performed equally well predicting spring wheat yield at the ECD scale. The mean absolute error percentages (MAPE) of the models selected from both the two data sets ranged from 2% to 33% over the study period. The model efficiency index (MEI) varied between −1.1 and 0.99 and −1.8 and 0.99, respectively for the agroclimate + MODIS-NDVI and agroclimate + MODIS-EVI data sets. Moreover, significant improvement in forecasting skill (with decreasing MAPE of 40% and 5 times increasing MEI, on average) was obtained at the finer, ecodistrict spatial scale, compared to the coarser CAR scale. Forecast models need to consider the distribution of extreme values of predictor variables to improve the selection of remote sensing indices. Our findings indicate that statistical-based forecasting error could be significantly reduced by making use of MODIS-EVI and NDVI indices at different times in the crop growing season and within different sub-regions. View Full-Text
Keywords: ecodistrict; yield forecasting; MODIS; ICCYF; spring wheat ecodistrict; yield forecasting; MODIS; ICCYF; spring wheat

Graphical abstract

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited (CC BY 4.0).

Share & Cite This Article

MDPI and ACS Style

Kouadio, L.; Newlands, N.K.; Davidson, A.; Zhang, Y.; Chipanshi, A. Assessing the Performance of MODIS NDVI and EVI for Seasonal Crop Yield Forecasting at the Ecodistrict Scale. Remote Sens. 2014, 6, 10193-10214.
