Remote Sensing of Soil Moisture in Vineyards Using Airborne and Ground-Based Thermal Inertia Data
Abstract
:1. Introduction
2. Background
2.1. Thermal Inertia: Theoretical Background
2.2. Thermal Inertia Modification by a Vegetation Cover
3. Methods
3.1. Study Area
3.2. Fieldwork and Data Collection
3.3. Aerial Mapping of Thermal Inertia
3.4. Calculating Thermal Inertia
3.5. Statistical Analysis
4. Results
4.1. Aerial Thermal Imagery
4.2. Soil Physical Properties
4.3. Relationships between Field Measurements and Remote Sensing Imagery
4.4. Regression Relationships between Thermal Inertia and Soil Properties
5. Discussion
5.1. Thermal Inertia and Soil Properties
5.2. Advantages of Remotely-Sensed Thermal Inertia
5.3. Limitations of Field Estimated Thermal Inertia
5.4. Improving Moisture Retrieval Using Thermal Inertia
6. Conclusions
Acknowledgments
Conflict of Interest
References and Notes
