Automated Built-Up Extraction Index: A New Technique for Mapping Surface Built-Up Areas Using LANDSAT 8 OLI Imagery
Abstract
:1. Introduction
2. Test Sites and Cities
3. Data and Methods
3.1. Landsat Images and Reference Data
3.2. Methods
3.2.1. Image Preprocessing
3.2.2. Formulation of the Automated Built up Extraction Index (ABEI)
3.2.3. Pure-Pixel Selection
3.2.4. Improved Gravitational Search Algorithm
3.2.5. Classification, Threshold Optimization and Per-Pixel Accuracy Assessment
3.2.6. Mixed Pixel (Heterogeneous Region) Accuracy Assessment
3.2.7. The Performance Evaluation of ABEI Using Cross-Validation Analysis
4. Results
4.1. ABEI
4.2. Built-Up Extraction Maps
4.3. Classification Accuracy and Edge Pixel Effects
4.4. Optimal Threshold and Its Variability
4.5. Cross-Validation Analysis
5. Discussion
6. Conclusions
Author Contributions
Funding
Acknowledgments
Conflicts of Interest
References
