Systematic Review

Comparing the Effectiveness of Open and Minimally Invasive Approaches in Coronary Artery Bypass Grafting: A Systematic Review

1
Department of Medicine and Surgery, Batterjee Medical College, Jeddah 21442, Saudi Arabia
2
Department of Medicine and Surgery, Vision College, Jeddah 23643, Saudi Arabia
3
Faculty of Medicine, Taibah University, Al-Madinah Almunawwarah 41477, Saudi Arabia
4
Medical Physiology Department, Kasr Alainy, Faculty of Medicine, Cairo University, Giza 11562, Egypt
5
General Medicine Practice Program, Department of Physiology, Batterjee Medical College, Jeddah 21442, Saudi Arabia
*
Author to whom correspondence should be addressed.
Clin. Pract. 2024, 14(5), 1842-1868; https://doi.org/10.3390/clinpract14050147
Submission received: 20 August 2024 / Revised: 31 August 2024 / Accepted: 5 September 2024 / Published: 10 September 2024

Abstract

:
Coronary artery bypass grafting (CABG) is an essential operation for patients who have severe coronary artery disease (CAD). Both open and minimally invasive CABG methods are used to treat CAD. This in-depth review looks at the latest research on the effectiveness of open versus minimally invasive CABG. The goal is to develop evidence-based guidelines that will improve surgical outcomes. This systematic review used databases such as PubMed, MEDLINE, and Web of Science for a full electronic search. We adhered to the PRISMA guidelines and registered the results in the PROSPERO. The search method used MeSH phrases and many different study types to find papers. After removing duplicate publications and conducting a screening process, we collaboratively evaluated the full texts to determine their inclusion. We then extracted data, including diagnosis, the total number of patients in the study, clinical recommendations from the studies, surgical complications, angina recurrence, hospital stay duration, and mortality rates. Many studies that investigate open and minimally invasive CABG methods have shown that the type of surgery can have a large effect on how well the patient recovers and how well the surgery works overall. While there are limited data on the possible advantages of minimally invasive CABG, a conclusive comparison with open CABG is still dubious. Additional clinical trials are required to examine a wider spectrum of patient results.

1. Introduction

Coronary artery bypass grafting (CABG) is a frequently conducted surgical intervention aiming at restoring blood flow to the heart in individuals with coronary artery disease (CAD) [1]. CAD is a global health threat associated with substantial illness and death [2]. CAD, a prevalent cardiovascular disorder, frequently presents with distinctive indicators that warrant careful consideration. These indicators include symptoms such as angina, chest pain, or pressure, which may occasionally extend to the arms, neck, or jaw. In addition, dyspnea experienced during physical activity or even during periods of rest indicates insufficient blood flow to the heart. It is important to note that symptoms might vary among individuals; therefore, it is important to pay attention to both common indicators and unusual presentations [3].
There are many different types of CABG, each made to meet the specific needs of a patient and help them deal with the challenges of CAD. Historically, CABG has been conducted via an open technique called a sternotomy, a vertical incision in the chest that provides extensive access to the heart and its blood vessels [4]. The procedure has a proven history of success, demonstrating the ability to produce durable grafts and provide long-lasting relief from angina, reducing the likelihood of recurrent cardiac episodes [5]. This method revolutionized the treatment of advanced CAD [6]. However, ongoing progress has led to minimally invasive techniques in CABG, which offer less invasive options with potentially improved recovery times. Endovascular therapies, such as percutaneous coronary procedures, have also come up as other ways to control CAD. This has increased therapy options and made patient care better [7].
The development of minimally invasive techniques such as Minimally Invasive Direct Coronary Artery Bypass (MIDCAB) and Off-Pump Coronary Artery Bypass (OPCAB) has significantly altered the surgical paradigm. MIDCAB is the utilization of smaller incisions, also known as “keyhole” incisions, with a specific focus on addressing single-vessel disease [8]. Nevertheless, in recent times, minimally invasive methods have become increasingly popular because of their potential advantages, including decreased surgical trauma, shorter hospital stays, and quicker recovery. These benefits make them attractive to patients needing less invasive CAD management alternatives [9]. When dealing with CAD, which is very delicate, both traditional open-heart surgeries and the new minimally invasive treatments have their pros and cons [10].
This systematic review critically evaluates how well open and minimally invasive methods work for CABG. Although much research has examined the results of various processes, there is still a continuing dispute about their superiority. Proponents of the open technique contend that it offers enhanced visualization and accessibility to the heart, leading to enhanced rates of graft patency and long-term results. On the other hand, proponents of the minimally invasive method highlight the benefits of smaller cuts, such as decreased blood loss and postoperative pain, resulting in faster healing and higher patient contentment. This review aims to compare the results and complications of minimally invasive CABG to traditional CABG achieved through a sternotomy. Because CAD is a major global health issue that causes a lot of illness and death, the study aims to determine whether minimally invasive cardiac surgery (MICS) CABG can be better than traditional open CABG while also having lower hospitalization duration and mortality rates.

2. Materials and Methods

2.1. Search Strategy

The systematic review was registered in PROSPERO (CRD42024506685) and was conducted following the Preferred Reporting Items for Systematic Reviews and Meta-Analyses (PRISMA) guidelines [11] (Appendix D and Appendix E). A comprehensive electronic search was conducted using the following databases: PubMed, MEDLINE, and Web of Science, with no specific time frame. A search strategy has been developed by the authors F.E, A. A and approved by the rest of the research team. Studies related to the comparative effectiveness of open and minimally invasive approaches in CABG were identified inclusively using a combination of Medical Subject Headings (MeSH) such as “Coronary Artery Bypass Grafting” OR “Coronary Artery Bypass Surgery” OR “Coronary Artery Bypass” OR “Aortocoronary Bypass” OR “Bypass Surgery” OR “CABG” AND “Coronary Artery Disease” OR “Aortocoronary” OR “Open heart surgery” OR “Minimally invasive surgery” OR “Endoscopic Surgery” AND “Mortality” OR “Wound Infection” OR “Bleeding Rates” OR “Stroke rates” OR “Length of hospital stay”. To identify any missing articles, a further review of the references to the studies was conducted.
The search technique included searching several databases: PubMed (n = 3234), MEDLINE (n = 1202), and Web of Science (n = 2581). At first, the records were checked for duplicates, leaving 7017 distinct records. During the eligibility phase, 1053 records were reviewed, and 5964 records were eliminated based on established criteria. Out of the records reviewed, 174 full-text articles were evaluated for eligibility, excluding 879 articles with indicated reasons. Seventy-one papers met the criteria for inclusion in the qualitative synthesis.

2.2. Study Selection

2.2.1. Inclusion Criteria

This review included studies that compare the effectiveness of open and minimally invasive approaches in coronary artery bypass grafting. This review considered various research designs, including randomized controlled trials (RCTs), quasi-experimental studies, cohort studies, case-control studies, and observational studies published in English. Furthermore, this review only included studies that were published in peer-reviewed journals or other credible sources.

2.2.2. Exclusion Criteria

This systematic review excluded studies that do not investigate the effectiveness of open or minimally invasive approaches in CABG. We also excluded studies that focused on surgical procedures or interventions unrelated to CABG, animal studies, in vitro studies, and review articles. Studies published in languages other than English or with insufficient data, such as those that lack detailed outcome measures, specific numerical results, or relevant statistical analyses necessary to evaluate the efficacy of the surgical techniques, were not considered for inclusion in this review.

2.2.3. Screening and Data Extraction

After conducting the primary search, the records were imported to Google Drive (Mountain View, CA, USA: Google) and Mendeley Desktop (Mendeley Ltd., London, UK), where duplicate articles were removed. The remaining results were then imported into Rayyan [(https://www.rayyan.ai/) accessed on 3 October 2023] for screening by three authors (R.A., S.A., H.A.) based on relevance determined by titles and abstracts. Next, the full texts of the studies that passed the initial screening were reviewed by two authors (S.F., A.M.) for the final inclusion or exclusion decision [12]. Any disagreements during the screening process were resolved through discussion with (A.A.) and the other researchers. Data were extracted from the selected studies through an Excel sheet, including the title, author’s name, country, year of publication, name of the journal, study design, level of evidence, sample size, surgical complication (wound infection rates, bleeding rates, and stroke rate), angina recurrence, length of hospital stay, and mortality rates.

2.2.4. Quality Assessment and Bias Evaluation

We evaluated the included studies for their quality and potential bias using the Grading of Recommendations Assessment, Development, and Evaluation (GRADE) system. This comprehensive assessment revealed varying levels of evidence within the included studies, thereby offering valuable insights into their overall quality and potential sources of bias. Retrospective and prospective cohort studies used the Newcastle–Ottawa Scale for bias assessment (Appendix A). Additionally, we used the revised Cochrane risk-of-bias tool for randomized trials (RoB 2) to assess the risk bias of RCTs (Appendix B). We also used the MINORS tool to evaluate the quality of the non-randomized studies included in this review (Appendix C). These evaluations provide insights into the overall quality and potential sources of bias in the included studies, enhancing the robustness and reliability of the reported results.

2.3. Data Synthesis

Despite conducting a basic descriptive statistical analysis using Review Manager version 5.4.1 (Cochrane, London, UK), we could not conduct a meta-analysis because of the high heterogeneity and lack of consistent data formats in the included studies. The following aspects of the heterogeneity were visible as shown in Table 1 and Table 2: first, the variability in research methodologies encompassing randomized controlled trials (RCTs), cohort studies, and observational studies. Second, there are distinctions between traditional and minimally invasive procedures for CABG. Lastly, there is inconsistent reporting of outcomes such as wound infection rates, bleeding rates, stroke rates, death rates, and length of hospital stay.

3. Results

In our search, a total of only 73 articles fulfilled the full scrutiny required to be included in this systematic review [13,14,15,16,17,18,19,20,21,22,23,24,25,26,27,28,29,30,31,32,33,34,35,36,37,38,39,40,41,42,43,44,45,46,47,48,49,50,51,52,53,54,55,56,57,58,59,60,61,62,63,64,65]. A total of 879 articles were excluded from full-text review for many reasons. These exclusions were due to reasons such as not having the complete text available, duplicates, methodological shortcomings, or flawed results attributed mainly to different outcomes sought among studies included (diverse treatment strategies) and for research articles that contained diabetic patients but had no specific measurements of periodontal therapy within it. Other excluded papers were in a language other than English. A mix of research designs was observed across the included studies in this systematic review. The range of designs allowed for a more complete evaluation of the efficacy and approaches to CABG in open form or minimally invasive. The PRISMA flowchart of the systematic review is illustrated in Figure 1 and details all components. The 73 studies included in the systematic review were from several locations worldwide. The included studies were published from 1997 to 2023.
The articles that reference the comparative effectiveness of open and minimally invasive approaches in CABG, together with a comprehensive overview of the demographics of their participants, are detailed in Table 2.

3.1. Patients’ Profiles and Characteristics

A total of 60,954 patients were included in this systematic review. A total of 46,379 patients underwent open CABG and 14,575 minimally invasive CABGs. The age of participants differed significantly across studies, with mean ages 54 years (range for young group = 34–46 to old group = 75–97).
The analysis of the gender distribution across studies showed predominant involvement among males, with 40,187 participants compared with a total of 20,767 females. Our original research included a cohort of 102 patients with one-vessel disease of the LAD coronary artery, studied from December 1996 to December 1998 [16]. This study’s findings revealed significant benefits associated with using OPCAB. The OPCAB group had a 0% operative death rate, but the surgical time was significantly shorter than that of the MIDCAB group (4% mortality). These results suggest that OPCAB has a better technical result (p = 0.004). Recurrent angina occurred in 40% of MIDCAB and 27% of OPCAB patients during a mean follow-up period of 5.2 years [13]. Another study illustrated the rationale for the use of MICS as opposed to a traditional CABG trial. The trial aimed to include eighty-eight patients per group, using the SF-36 questionnaire as the primary tool for assessing quality of life (QoL) after a month. On the other hand, previous studies demonstrated that an average hospital stay following MICS is 5 days, while it takes at least nine more days in sternotomy CABG [18]. The Society of Thoracic Surgeons maintained a regional database for clinical quality improvement, from which a second study extracted patients with CABG. There was a total of 278 open CABG and 139 MICS CABG patients. In addition, the rates of serious morbidity were similar between matched groups, with an open CABG rate of 7.9% and a MICS CABG rate of 7.2%, respectively (p = 0.795). On a notable note, MICS CABG was associated with the advantages of less use of blood product transfusions (12.2% in the MICS CABG vs. 22.3% in open CABG; p = 0.013) and a shorter duration hospitalization period (6 days for MIS-CABG vs. 7 days for open CABG, p = 0.005). Furthermore, the findings demonstrated that patients who had MICS CABG had lower hospital charges, with a median of $27,906 vs. $35,011 for open CABG (p = 0.001) [35].

3.2. Patient-Reported Outcomes and Complications

This section provides an overview of the results of patient-reported outcomes and the incidence of complications related to open and minimally invasive techniques in CABG. From April 2008 to July 2011, a study was conducted that included a total of 74 patients in the MIDCAB group and 78 patients in the OPCAB group. The comparison between the two groups was deemed adequate based on the patient demographics and EuroSCORE values. The OPCAB had a lower rate of cerebrovascular accidents (1.3% for OPCAB vs. 1.4% for MIDCAB, p = 1.0), recurrent myocardial infarctions (0% for OPCAB vs. 1.4% for MIDCAB, p = 0.3), and wound infections (2.7% for OPCAB vs. 5.4% for MIDCAB, p = 0.4) [55].

4. Discussion

We conducted a systematic review to determine the differences in outcomes between minimally invasive and traditional open CABG procedures. We found a strong association between the type of surgery performed and surgical trauma, duration till recovery, and postoperative complications. Historically, they have performed MIDCAB and OPCAB earlier than Lima LAD. These provide clinical relevance to minimally invasive approaches, especially for patients with specific comorbidities who might not be able to recover from this extensive surgery if performed openly. This further supports the increased use of less-invasive techniques that have minimal physiological consequences while still providing good anterograde coronary perfusion.
Our review underscores that the decision to recommend open or minimally invasive CABG should be patient-specific [13,24]. Patient age, left ventricular ejection fraction (LVEF), and concomitant comorbidities such as chronic kidney disease (CKD) are all associated with outcomes. For instance, younger patients with fewer comorbidities are likely to benefit more from the use of minimally invasive techniques, as these approaches have demonstrated lower hospital and long-term mortality rates. Conversely, in patients with more complicated pathology, the traditional ‘open’ approach may still be necessary to achieve a good long-term outcome [66,67,68].
Data presented in our systematic review suggest that the immediate decisions for surgical intervention in CABG should be patient-centered and driven more by clinical indications to achieve optimal outcomes [26]. While the MICABG has demonstrated potential in this field, particularly for simpler cases and associated evaluations, traditional open CABG remains the gold standard for providing durable grafts that realistically promise excellent long-term symptom relief despite its more invasive nature. In turn, a minimally invasive approach should be considered for patients who are hemodynamically stable with multivessel coronary artery disease, and this group may offer a better chance of faster recovery and fewer complications [69]. Given these advantages, there are also potential risks to minimally invasive CABG; this review identified a slightly greater risk of bleeding and wound infection compared with open surgery. The need for patient selection and skill in minimally invasive surgery is critical to limiting these risks, even though they are inherent in all surgical procedures.

Limitations

Some limitations of the systematic review we conducted are worth mentioning. Variability in the surgical techniques and care pathways ranged from standard open surgery to less invasive approaches. Presumably, this diversity could have influenced the pooling of results. Often, insufficient information on the exact particulars of surgical procedures, patient selection criteria, and postoperative care provided a meaningful comparison to various research studies. Some studies combined hybrid procedures or adjunctive therapies, while others omitted the details of supplementary methods that hindered the comparison between regimens.
There is room to improve the quality of these studies in future research by implementing multi-center trials and including a greater cross-section of the population. Uniform principles for assessing the surgical results and strict rules of postoperative therapy have to be followed in these studies. This standardization will improve the granularity of long-term data and help identify paradigms specific to a particular surgical strategy for CABG. Additional research is needed to determine the best practices across different patient populations.

5. Conclusions

This systematic study highlights that the choice of surgical strategy significantly affects the outcomes of CABG, with traditional open surgery and minimally invasive approaches showing poor compatibility. Although minimally invasive techniques hold potential, the existing information is inadequate to establish a clear preference for one method over another. To enhance our comprehension of CABG operations and improve future practice, it is imperative to conduct additional comparative clinical trials.

Author Contributions

Author Contributions: Concept and design: A.A. (Arwa Alsharif), A.A. (Abdulaziz Alsharif), G.A. and R.A.; Acquisition: A.A.A., S.A., H.A., S.F. and A.M.; Analysis of data: F.E.H., A.A. (Arwa Alsharif), A.A. (Abdulaziz Alsharif), G.A. and R.A.; Drafting of the manuscript: A.A.A., S.A., H.A., S.F. and A.M.; Critical review of the manuscript for important intellectual content: F.E.H., A.A. (Arwa Alsharif), A.A. (Abdulaziz Alsharif), G.A., A.A.A., R.A., S.A., H.A., S.F. and A.M.; Supervision: F.E.H. All authors have read and agreed to the published version of the manuscript.

Funding

This research received no external funding.

Acknowledgments

Fatma E. Hassan, who played a crucial role in designing this systematic evaluation, provided tremendous assistance and mentorship to support this research. Throughout this project, her proficiency and dedication to enhancing our knowledge of coronary artery bypass grafting have been critical.

Conflicts of Interest

The authors declare no conflicts of interest.

Appendix A

Retrospective and prospective cohort studies used the Newcastle Ottawa Scale for bias assessment. Using the Newcastle–Ottawa scale, case-control and cohort studies scored 7 out of 9, indicating a high level of quality. According to the level of evidence and grading recommendations of the American Society of Plastic Surgery, among the included studies, one study had a level II, four studies had a level IV, and five studies had a level V of evidence (Table A1).
Table A1. The Newcastle–Ottawa Scale for the included cohort prospective and retrospective studies.
Table A1. The Newcastle–Ottawa Scale for the included cohort prospective and retrospective studies.
SelectionComparabilityOutcomeQuality ScoreRisk of Bias (0–3: High, 4–6: Moderate, 7–9: Low)
ArticleQ1Q2Q3Q4Q5Q6Q7Q8
Olson [4]*********9low
Rosenblum [7]*********9low
Vicol [13]*********9low
Barış Çaynak [19]* * * *4moderate
Umberto Benedetto [20]*********9low
Yunpeng Ling [21]* ** **5moderate
Kayatta MO [23] ** ** 4moderate
Marc Ruel [25]* ******7low
Shahzad G [26]*********9low
Vincenzo Giambruno [27]****** **8low
Ali Hage [10]*********9low
Joseph Lamelas [28]* ******7low
Bob Kiaii [29]* *******8low
Joshua Michael Rosenblum [7]** ******8low
Alberto Repossini [30]**** ***7low
Florian Hecker [31]* *******8low
Shameer Khubber [32]* ******7low
Nicholas R [33]*********9low
Jia-Ji Liu [34]* *******8low
Hiroto Kitahara [35]*********9low
Yugal K. Mishra [36]*********9low
Sanin Fazlinović [37]*********9low
Ho Young Hwang [38]* ******7low
Wenhui Gong [39]* ******7low
Carlo Antona [40]*********9low
Lin Liang [41]* ** ***6moderate
Zia K [42]********8low
Paweł Bugajski [44]********8low
Redoy Ranjan [45]* ******7low
Marek Cisowskia [46]********8low
Husam H. Balkhy [47]*********9low
BH Kirmani [48]*********9low
Ali İhsan Tekin [49]********8low
Minoru Ono [50]********7low
Lufeng Zhang [51]*********8low
Hideaki Takai [52]********7low
Rashmi Birla [53]*********9low
Joseph McGinn [54]*********9low
Emad Barsoum [55]********8low
Diegeler [57]*********8low
Dong Li [58]*********9low
Do-Kyun Kim [60]*********8low
Oktar [61]*********9low
Raghuram [62]*********8low
Park [63]*********9low
Halkos, 2014 [65]*********8low
Selection: Q1. Representativeness of the exposure cohort? Q2. Selection of the non-exposure cohort? Q3. Ascertainment of exposure? Q4. Demonstration that outcome of interest was not present at the start of the study?; Comparability: Q5. Comparability of cohort based on the design or analysis?; Outcome: Q6. Assessment of outcome? Q7. Was follow-up long enough for outcomes to occur? Q8. Adequacy of follow-up of cohorts?; *: means the corresponding quality component or criterion is partially met, **: means the corresponding quality component or criterion is fully met.

Appendix B

Table A2. Bias of the included cohort prospective and retrospective studies evaluated according to the Newcastle–Ottawa Scale.
Table A2. Bias of the included cohort prospective and retrospective studies evaluated according to the Newcastle–Ottawa Scale.
AuthorBias Arising from the Randomization ProcessBias Due to Deviations from Intended Interventions Bias Due to Missing Outcome DataBias in Measurement of the OutcomeBias in Selection of the Reported Result Overall RoB
Taggart [1]lowsome concernslowlowlowlow
Shroyer [6]lowsome concernslowlowlowlow
Zenati, Marco [15]lowsome concernslowlowlowlow
Angelini [16]lowsome concernslowlowlowlow
Ming Hao Guo [18]lowsome concernslowlowlowlow
Meice Tian [22]lowsome concernslowlowlowlow
Weimar [24]lowSome ConcernslowlowSome ConcernsSome Concerns
Anno Diegeler [43] low some concerns some concerns lowsome concerns low
Stone [56]lowLowhighlowlowlow
Sajja [59]lowLowSome ConcernsLowSome ConcernsSome Concerns
Moussa [64]lowSome ConcernsSome ConcernsLowSome ConcernsSome Concerns

Appendix C

The MINORS tool was used to assess the quality of the non-randomized studies included in this review. The total score ranged from 6 to 18, with a mean score of 12.3. The items with the lowest scores were the prospective calculation of the study size (score of 0 in all studies), the unbiased assessment of the study endpoint (score of 0 in all studies), and the inclusion of a consecutive series of patients (score of 1 or 2 in most studies). The items with the highest scores were the clearly stated aim of the study (score of 2 in all studies), the description of patient characteristics (score of 2 in all studies), and the clearly defined endpoints (score of 2 in all studies) (Table A3).
Table A3. The Methodological Index for Non-Randomized Studies (MINORS).
Table A3. The Methodological Index for Non-Randomized Studies (MINORS).
ItemBansal
2023
Ullah
2023
Benedetto
2009
Kikuchi
2017
Parnell
2018
Hage 2019Ouzzani
2016
Davierwala
2018
Chivasso
2016
A clearly stated aim 222222222
Inclusion of consecutive patients022002022
Prospective collection of data021002021
Endpoints appropriate to the aim of the study 222222222
Unbiased assessment of the study endpoint 112112221
Follow-up period appropriate to the aim of the study 022202022
Loss to follow-up less than 5%011001011
Prospective calculation of the study size 011001011
An adequate control group 012102012
Contemporary groups 012102012
Baseline equivalence of groups 012102012
Adequate statistical analyses 222222222
Total Score717191172081718

Appendix D

Table A4. Systematic Review Protocol and Support Template.
Table A4. Systematic Review Protocol and Support Template.
Title of the Systematic ReviewComparative the Effectiveness of Open and Minimally Invasive Approaches in Coronary Artery Bypass Grafting: A Systematic Review
Author and Affiliations
  • Arwa Tawfiq Alsharif
    College of Medicine and Surgery, Batterjee Medical College, Jeddah, Saudi Arabia
  • Abdulaziz Tawfiq Alsharif
    College of Medicine and Surgery, Vision College, Jeddah, Saudi Arabia
  • Ghadah Dhafer Alshamrani
    College of Medicine and Surgery, Batterjee Medical College, Jeddah, Saudi Arabia
  • Abdulhameed Luay Abu Alsoud
    College of Medicine and Surgery, Batterjee Medical College, Jeddah, Saudi Arabia
  • Rowaida Abdullah Durian
    College of Medicine and Surgery, Batterjee Medical College, Jeddah, Saudi Arabia
  • Sarah Mohammad Aljohani
    College of Medicine and Surgery, Batterjee Medical College, Jeddah, Saudi Arabia
  • Hawazen Omar Alahmadi
    Faculty of Medicine, Taibah University, Al-Madinah Almunawwarah, Saudi Arabia
  • Samratul Fuadah
    College of Medicine and Surgery, Batterjee Medical College, Jeddah, Saudi Arabia
  • Atheer Mohammed Mohammed
    College of Medicine and Surgery, Batterjee Medical College, Jeddah, Saudi Arabia
Supervisor/Project PIFatma E. Hassan
Department of Medical Physiology, Batterjee Medical College, Jeddah 21442, Saudi Arabia
[email protected]
(1)
Background of the systemic review
Coronary artery bypass grafting (CABG) is the most effective surgical procedure for coronary artery disease and the leading global cause of morbidity and mortality. Most notably, open and minimally invasive CABG approaches have evolved with advances in surgical techniques and technology. The advantages and disadvantages of each procedure link to the differences between these two distinct surgical methods [70]. For years, CABG, an open-heart surgery, has been the primary method of coronary revascularization, requiring a sternotomy with cardiopulmonary bypass (CPB) on a heart-lung machine. This ensures complete revascularization and provides the surgeon with direct access to each of the coronary vessels. This technique has two major disadvantages: high rates of perioperative morbidity and long convalescent periods. They often experience longer in-hospital healthcare episodes followed by a prolonged recovery time, which may decrease their quality of life [71]. Conversely, the minimally invasive CABG procedures have emerged as a promising alternative. These approaches reduced the size and number of incisions required, resulting in reduced surgical trauma and, consequently, improved post-surgical recovery. Minimally invasive CABG comprises robot-assisted surgery, grafts with completely endoscopic treatments or thoracotomy incisions, and other techniques. The advocates of minimally invasive CABG contend that it offers the potential for reduced pain, a faster return to regular activities with shorter hospital stays, and better cosmetic results [72].
Whether open or minimally invasive CABG should be the surgical treatment depends on the patient, surgeon, and institution. However, the medical community continues to grapple with this issue. Although some research states that minimally invasive CABG similar to OPCAB could give similar or better results in mortality, morbidity, and long-term graft patency, others say open CABG has remained the gold standard due to its established record of outcomes and capacity for full revascularization [71,73].
(2)
Aim of the systemic review
This systematic review aims to evaluate and compare the effectiveness of open and minimally invasive approaches in Coronary Artery Bypass Grafting (CABG) procedures.
(3)
Specific objectives of the systemic review
-
To compare the safety profiles of open and minimally invasive CABG procedures.
-
To analyze resource utilization aspects, including length of hospital stay, and post-surgical complication associated with each surgical approach.
-
To assess and compare the long-term outcomes, associated with open and minimally invasive CABG.
(4)
Criteria for including studies in this review
Population, or participants and condition of interestThis includes patients of different ages, and genders, who have been diagnosed with coronary artery disease (CAD) in various healthcare settings. The condition of interest for this systematic review research is to investigate and compare the outcomes and effectiveness of open and minimally invasive approaches in CABG procedures.
Interventions or exposures
-
Open Coronary Artery Bypass Grafting (Open CABG): This intervention involves the conventional surgical approach for coronary revascularization, which generally includes a sternotomy and the use of a heart-lung machine for cardiopulmonary bypass. This review will assess their collective effectiveness.
-
Minimally Invasive Coronary Artery Bypass Grafting (Minimally Invasive CABG): This intervention encompasses a range of minimally invasive surgical techniques for coronary revascularization, such as small thoracotomy incisions, robot-assisted surgery, and totally endoscopic procedures. This review will examine the comparative effectiveness of these approaches in terms of clinical outcomes, and safety.
Comparisons or control groups
-
Open CABG as Control: This group comprises patients who have undergone the traditional open CABG procedure. These patients serve as the control group against which the outcomes of other interventions, such as minimally invasive CABG, will be compared.
-
Minimally Invasive CABG as Comparisons: In certain analyses, patients who have undergone minimally invasive CABG may serve as a comparative assessment of the relative benefits and drawbacks of each surgical approach.
Outcomes of interestSurgical complications (Wound infection rate, Bleeding rate, Stroke rate, Angina recurrence rate, Length of hospital stay, and Mortality rate)
Setting
-
Hospitals
-
Outpatient clinics
-
Cardiac surgical centers
Inclusion criteria
  • Studies that of the evaluate the open approaches in coronary artery bypass grafting.
  • Studies that of the evaluate the minimally invasive approaches in coronary artery bypass grafting.
  • Studies involving patients diagnosed with coronary artery disease who require coronary artery bypass grafting.
  • Randomized controlled trials (RCTs), quasi-experimental studies, cohort studies, case-control studies, and observational studies.
  • Studies published in peer-reviewed journals or other credible sources.
  • Studies published in the English language.
Exclusion criteria
  • Studies that focus on other surgical procedures or interventions unrelated to coronary artery bypass grafting.
  • Case-report studies, Review articles
  • Animal studies, in vitro studies, and review articles.
  • Studies published in languages other than English.
  • Studies with insufficient data or lack of relevant outcome measures.
(5)
Search methods
Electronic databases
-
PubMed database
-
MEDLINE database
-
Web of science
Keywords(Coronary Artery Bypass Grafting OR Coronary Artery Bypass Surgery OR Coronary Artery Bypass OR Aortocoronary Bypass OR Bypass Surgery OR Coronary Artery Disease OR Aortocoronary OR CABG OR Open-heart surgery OR Minimally invasive surgery OR Endoscopic Surgery OR Surgical outcomes OR Mortality OR Graft patency OR Graft Occlusion OR Vascular Graft Restenosis OR Length of hospital stay)
(6)
Methods of review
Details of methods, number of reviewers, how agreements are to be reached and disagreements dealt with, etc.Four main reviewers and a fifth to resolve any disagreements. Resolving any outstanding disagreements, an article by Dr. Fatma and Dr. Arwa.
Quality assessment tools or checklists used with references or URLs
  • Grading of Recommendations Assessment, Development, and Evaluation (GRADE) system to evaluate the overall quality of evidence and strength of recommendations.
  • Newcastle–Ottawa Scale (NOS): to assess the quality of non-randomized studies, such as cohort and case-control studies.
  • Revised Cochrane Risk-of-Bias Tool (RoB 2) to evaluate the risk of bias in randomized controlled trials (RCTs).
  • MINORS tool: to assess the methodological quality of non-randomized studies, including case series.
Narrative synthesis details of what and how synthesis will be performedA narrative synthesis will be conducted alongside any meta-analysis and will be carried out using a framework that consists of four elements: 1—Developing a theory of how the intervention works, why, and for whom. 2—Developing a preliminary synthesis of findings of included studies. 3—Exploring relationships within and between studies. 4—Assessing the robustness of the synthesis.
Meta-analysis details of what and how analysis and testing will be performed. If no meta-analysis is to be conducted, please give a reason.Although a meta-analysis is planned, this will only become apparent when we see what data has been extracted and made available from the systematic review. Need to think about how heterogeneity will be explored.
Grading evidence system used, if any, such as GRADEGRADE will be used for evidence assessment.
(7)
Presentation of results
Additional material summary tables, flowcharts, etc, to be included in the final paperA flow chart of the whole process Protocol Data extraction from and tables Forest plots of studies are included in the final review.

Appendix E

Table A5. PRISMA 2020 Checklist.
Table A5. PRISMA 2020 Checklist.
Section and Topic Item #Checklist ItemLocation where Item Is Reported
Title
Title1Identify the report as a systematic review.Page 1; Lines 3 and 4
Abstract
Abstract2See the PRISMA 2020 for Abstracts checklist.Page 1; Lines 24 to 39
Introduction
Rationale3Describe the rationale for this review in the context of existing knowledge.Page 2; Lines 54 to 64
Objectives4Provide an explicit statement of the objective(s) or question(s) this review addresses.Page 2; Lines 75 to 86
Methods
Eligibility criteria5Specify the inclusion and exclusion criteria for this review and how studies were grouped for the syntheses.Page 3; Lines 112 to 126
Information sources6Specify all databases, registers, websites, organizations, reference lists and other sources searched or consulted to identify studies. Specify the date when each source was last searched or consulted.Page 2 and 3; Lines 90 to 110
Search strategy7Present the full search strategies for all databases, registers and websites, including any filters and limits used.Page 2 and 3; Lines 90 to 110
Selection process8Specify the methods used to decide whether a study met the inclusion criteria of this review, including how many reviewers screened each record and each report retrieved, whether they worked independently, and if applicable, details of automation tools used in the process.Page 3; Lines 128 to 139
Data collection process9Specify the methods used to collect data from reports, including how many reviewers collected data from each report, whether they worked independently, any processes for obtaining or confirming data from study investigators, and if applicable, details of automation tools used in the process.Page 3; Lines 128 to 139
Data items10aList and define all outcomes for which data were sought. Specify whether all results that were compatible with each outcome domain in each study were sought (e.g., for all measures, time points, analyses), and if not, the methods used to decide which results to collect.Page 4; Lines 153 to 165
10bList and define all other variables for which data were sought (e.g., participant and intervention characteristics, funding sources). Describe any assumptions made about any missing or unclear information.Page 4; Lines 153 to 165
Study risk of bias assessment11Specify the methods used to assess risk of bias in the included studies, including details of the tool(s) used, how many reviewers assessed each study and whether they worked independently, and if applicable, details of automation tools used in the process.Page 4; Lines 141 to 151
Effect measures12Specify for each outcome the effect measure(s) (e.g., risk ratio, mean difference) used in the synthesis or presentation of results.ND
Synthesis methods13aDescribe the processes used to decide which studies were eligible for each synthesis (e.g., tabulating the study intervention characteristics and comparing against the planned groups for each synthesis (item #5)).ND
13bDescribe any methods required to prepare the data for presentation or synthesis, such as handling of missing summary statistics, or data conversions.ND
13cDescribe any methods used to tabulate or visually display results of individual studies and syntheses.ND
13dDescribe any methods used to synthesize results and provide a rationale for the choice(s). If meta-analysis was performed, describe the model(s), method(s) to identify the presence and extent of statistical heterogeneity, and software package(s) used.Page 4; Lines 153 to 161
13eDescribe any methods used to explore possible causes of heterogeneity among study results (e.g., subgroup analysis, meta-regression).Page 4; Lines 153 to 161
13fDescribe any sensitivity analyses conducted to assess robustness of the synthesized results.ND
Reporting bias assessment14Describe any methods used to assess risk of bias due to missing results in a synthesis (arising from reporting biases).Page 4; Lines 141 to 151
Certainty assessment15Describe any methods used to assess certainty (or confidence) in the body of evidence for an outcome.ND
Results
Study selection16aDescribe the results of the search and selection process, from the number of records identified in the search to the number of studies included in this review, ideally using a flow diagram.Page 5; Lines 167 to 183
16bCite studies that might appear to meet the inclusion criteria, but which were excluded, and explain why they were excluded.Page 5; Lines 168 to 174
Study characteristics17Cite each included study and present its characteristics.Page 6 to 14; Lines 184 to 217
Risk of bias in studies18Present assessments of risk of bias for each included study.Page 17 to 23; Lines 333 to 356
Results of individual studies19For all outcomes, present, for each study: (a) summary statistics for each group (where appropriate) and (b) an effect estimate and its precision (e.g., confidence/credible interval), ideally using structured tables or plots.Page 6 to 14; Lines 213 to 217
Results of syntheses20aFor each synthesis, briefly summarise the characteristics and risk of bias among contributing studies.Page 17 to 23; Lines 333 to 356
20bPresent results of all statistical syntheses conducted. If meta-analysis was conducted, present for each the summary estimate and its precision (e.g., confidence/credible interval) and measures of statistical heterogeneity. If comparing groups, describe the direction of the effect.ND
20cPresent results of all investigations of possible causes of heterogeneity among study results.ND
20dPresent results of all sensitivity analyses conducted to assess the robustness of the synthesized results.ND
Reporting biases21Present assessments of risk of bias due to missing results (arising from reporting biases) for each synthesis assessed.ND
Certainty of evidence22Present assessments of certainty (or confidence) in the body of evidence for each outcome assessed.ND
Discussion
Discussion23aProvide a general interpretation of the results in the context of other evidence.Page 15; Lines 260 to 289
23bDiscuss any limitations of the evidence included in this review.Page 16; Lines 291 to 298
23cDiscuss any limitations of this review process used.Page 16; Lines 291 to 298
23dDiscuss the implications of the results for practice, policy, and future research.Page 16; Lines 299 to 305
Other information
Registration and protocol24aProvide registration information for this review, including register name and registration number, or state that this review was not registered.Page 2; Lines 90 to 92
24bIndicate where this review protocol can be accessed, or state that a protocol was not prepared.Page 24; Lines 359 to 362
24cDescribe and explain any amendments to information provided at registration or in the protocol.Page 24; Lines 359 to 362
Support25Describe sources of financial or non-financial support for this review and the role of the funders or sponsors in this review.Page 17; Line 320
Competing interests26Declare any competing interests of review authors.Page 17; Line 332
Availability of data, code, and other materials27Report which of the following are publicly available and where they can be found: template data collection forms; data extracted from included studies; data used for all analyses; analytic code; any other materials used in this review.Pages 17 to 27; Lines 333 to 362

References

  1. Taggart, D.P.; Altman, D.G.; Gray, A.M.; Lees, B.; Gerry, S.; Benedetto, U.; Flather, M. Randomized Trial of Bilateral versus Single Internal-Thoracic-Artery Grafts. N. Engl. J. Med. 2016, 375, 2540–2549. [Google Scholar] [CrossRef] [PubMed]
  2. Bansal, A.; Hiwale, K. Updates in the Management of Coronary Artery Disease: A Review Article. Cureus 2023, 15, e50644. [Google Scholar] [CrossRef] [PubMed]
  3. Ullah, M.; Wahab, A.; Khan, S.U.; Zaman, U.; Rehman, K.U.; Hamayun, S.; Naeem, M.; Ali, H.; Riaz, T.; Saeed, S.; et al. Stent as a Novel Technology for Coronary Artery Disease and Their Clinical Manifestation. Curr. Probl. Cardiol. 2023, 48, 101415. [Google Scholar] [CrossRef] [PubMed]
  4. Olson, P.; Cinelli, M.; Rahming, H.S.; Vazzana, T.; Spagnola, J.; Barsoum, E.; Assaad, M.; Tamburrino, F.; Lafferty, J. Repeat Revascularization Post Coronary Artery Bypass Grafting: Comparing Minimally Invasive and Traditional Sternotomy Techniques in 1468 Cases. Cureus 2022, 14, e25687. [Google Scholar] [CrossRef]
  5. Benedetto, U.; Melina, G.; Angeloni, E.; Refice, S.; Roscitano, A.; Fiorani, B.; Di Nucci, G.D.; Sinatra, R. Coronary artery bypass grafting versus drug-eluting stents in multivessel coronary disease. A meta-analysis on 24,268 patients. Eur. J. Cardio-Thorac. Surg. 2009, 36, 611–615. [Google Scholar] [CrossRef]
  6. Shroyer, A.L.; Grover, F.L.; Hattler, B.; Collins, J.F.; McDonald, G.O.; Kozora, E.; Lucke, J.C.; Baltz, J.H.; Novitzky, D. On-Pump versus Off-Pump Coronary-Artery Bypass Surgery. N. Engl. J. Med. 2009, 361, 1827–1837. [Google Scholar] [CrossRef]
  7. Rosenblum, J.M.; Binongo, J.; Wei, J.; Liu, Y.; Leshnower, B.G.; Chen, E.P.; Miller, J.S.; Macheers, S.K.; Lattouf, O.M.; Guyton, R.A.; et al. Priorities in coronary artery bypass grafting: Is midterm survival more dependent on completeness of revascularization or multiple arterial grafts? J. Thorac. Cardiovasc. Surg. 2021, 161, 2070–2078.e6. [Google Scholar] [CrossRef]
  8. Kikuchi, K.; Mori, M. Minimally invasive coronary artery bypass grafting: A systematic review. Asian Cardiovasc. Thorac. Ann. 2017, 25, 364–370. [Google Scholar] [CrossRef]
  9. Parnell, A.; Prince, M. Anaesthesia for minimally invasive cardiac surgery. BJA Educ. 2018, 18, 323–330. [Google Scholar] [CrossRef]
  10. Hage, A.; Giambruno, V.; Jones, P.; Chu, M.W.; Fox, S.; Teefy, P.; Lavi, S.; Bainbridge, D.; Harle, C.; Iglesias, I.; et al. Hybrid Coronary Revascularization Versus Off-Pump Coronary Artery Bypass Grafting: Comparative Effectiveness Analysis with Long-Term Follow-up. J. Am. Heart Assoc. 2019, 8, e014204. [Google Scholar] [CrossRef]
  11. Moher, D.; Liberati, A.; Tetzlaff, J.; Altman, D.G. Preferred Reporting Items for Systematic Reviews and Meta-Analyses: The PRISMA Statement. PLoS Med. 2009, 6, e1000097. [Google Scholar] [CrossRef] [PubMed]
  12. Chaabna, K.; Cheema, S.; Abraham, A.; Alrouh, H.; Lowenfels, A.B.; Maisonneuve, P.; Mamtani, R. Systematic overview of hepatitis C infection in the Middle East and North Africa. World J. Gastroenterol. 2018, 24, 3038–3054. [Google Scholar] [CrossRef] [PubMed]
  13. Vicol, C.; Nollert, G.; Mair, H.; Samuel, V.; Lim, C.; Tiftikidis, M.; Eifert, S.; Reichart, B. Midterm results of beating heart surgery in 1-vessel disease: Minimally invasive direct coronary artery bypass versus off-pump coronary artery bypass with full sternotomy. Heart Surg. Forum 2003, 6, 341–344. Available online: https://pubmed.ncbi.nlm.nih.gov/15011666 (accessed on 26 January 2024). [PubMed]
  14. Davierwala, P.M.; Leontyev, S.; Garbade, J.; Lehmann, S.; Holzhey, D.; Misfeld, M.; Borger, M.A. Off-pump coronary artery bypass surgery with bilateral internal thoracic arteries: The Leipzig experience. Ann. Cardiothorac. Surg. 2018, 7, 483–491. [Google Scholar] [CrossRef] [PubMed]
  15. Zenati, M.A.; Bhatt, D.L.; Bakaeen, F.G.; Stock, E.M.; Biswas, K.; Gaziano, J.M.; Kelly, R.F.; Tseng, E.E.; Bitondo, J.; Quin, J.A.; et al. Randomized Trial of Endoscopic or Open Vein-Graft Harvesting for Coronary-Artery Bypass. N. Engl. J. Med. 2019, 380, 132–141. [Google Scholar] [CrossRef]
  16. Angelini, G.D.; Culliford, L.; Smith, D.K.; Hamilton, M.C.K.; Murphy, G.J.; Ascione, R.; Baumbach, A.; Reeves, B.C. Effects of on- and off-pump coronary artery surgery on graft patency, survival, and health-related quality of life: Long-term follow-up of 2 randomized controlled trials. J. Thorac. Cardiovasc. Surg. 2009, 137, 295–303.e5. [Google Scholar] [CrossRef]
  17. Chivasso, P.; Guida, G.A.; Fudulu, D.; Bruno, V.D.; Marsico, R.; Sedmakov, H.; Zakkar, M.; Rapetto, F.; Bryan, A.J.; Angelini, G.D. Impact of off-pump coronary artery bypass grafting on survival: Current best available evidence. J. Thorac. Dis. 2016, 8, S808–S817. [Google Scholar] [CrossRef]
  18. Guo, M.H.; Wells, G.A.; Glineur, D.; Fortier, J.; Davierwala, P.M.; Kikuchi, K.; Lemma, M.G.; Mishra, Y.K.; McGinn, J.; Ramchandani, M.; et al. Minimally Invasive coronary surgery compared to STernotomy coronary artery bypass grafting: The MIST trial. Contemp. Clin. Trials 2019, 78, 140–145. [Google Scholar] [CrossRef]
  19. Çaynak, B.; Sicim, H. Evaluation of anastomosis quality with intraoperative transit time flowmeter in minimally invasive multi-vessel coronary artery bypass grafting via left anterior mini-thoracotomy. Turk. J. Thorac. Cardiovasc. Surg. 2023, 31, 56–62. [Google Scholar] [CrossRef]
  20. Benedetto, U.; Puskas, J.; Kappetein, A.P.; Brown, W.M.; Horkay, F.; Boonstra, P.W.; Bogáts, G.; Noiseux, N.; Dressler, O.; Angelini, G.D.; et al. Off-Pump Versus On-Pump Bypass Surgery for Left Main Coronary Artery Disease. J. Am. Coll. Cardiol. 2019, 74, 729–740. [Google Scholar] [CrossRef]
  21. Ling, Y.; Bao, L.; Yang, W.; Chen, Y.; Gao, Q. Minimally invasive direct coronary artery bypass grafting with an improved rib spreader and a new-shaped cardiac stabilizer: Results of 200 consecutive cases in a single institution. BMC Cardiovasc. Disord. 2016, 16, 42. [Google Scholar] [CrossRef] [PubMed]
  22. Tian, M.; Wang, X.; Sun, H.; Feng, W.; Song, Y.; Lu, F.; Wang, L.; Wang, Y.; Xu, B.; Wang, H.; et al. No-Touch Versus Conventional Vein Harvesting Techniques at 12 Months After Coronary Artery Bypass Grafting Surgery: Multicenter Randomized, Controlled Trial. Circulation 2021, 144, 1120–1129. [Google Scholar] [CrossRef] [PubMed]
  23. Kayatta, M.O.; Halkos, M.E.; Narayan, P. Minimally invasive coronary artery bypass grafting. Indian J. Thorac. Cardiovasc. Surg. 2018, 34, 302–309. [Google Scholar] [CrossRef] [PubMed]
  24. Weimar, C.; Bilbilis, K.; Rekowski, J.; Holst, T.; Beyersdorf, F.; Breuer, M.; Dahm, M.; Diegeler, A.; Kowalski, A.; Martens, S.; et al. Safety of Simultaneous Coronary Artery Bypass Grafting and Carotid Endarterectomy Versus Isolated Coronary Artery Bypass Grafting. Stroke 2017, 48, 2769–2775. [Google Scholar] [CrossRef] [PubMed]
  25. Ruel, M.; Shariff, M.A.; Lapierre, H.; Goyal, N.; Dennie, C.; Sadel, S.M.; Sohmer, B.; McGinn, J.T. Results of the minimally invasive coronary artery bypass grafting angiographic patency study. J. Thorac. Cardiovasc. Surg. 2014, 147, 203–209. [Google Scholar] [CrossRef]
  26. Raja, S.G.; Garg, S.; Rochon, M.; Daley, S.; De Robertis, F.; Bahrami, T. Short-term clinical outcomes and long-term survival of minimally invasive direct coronary artery bypass grafting. Ann. Cardiothorac. Surg. 2018, 7, 621–627. [Google Scholar] [CrossRef]
  27. Giambruno, V.; Jones, P.; Khaliel, F.; Chu, M.W.; Teefy, P.; Sridhar, K.; Cucchietti, C.; Barnfield, R.; Kiaii, B. Hybrid Coronary Revascularization Versus On-Pump Coronary Artery Bypass Grafting. Ann. Thorac. Surg. 2018, 105, 1330–1335. [Google Scholar] [CrossRef]
  28. Lamelas, J.; Mawad, M.; Williams, R.; Weiss, U.K.; Zhang, Q.; LaPietra, A. Isolated and concomitant minimally invasive mini-thoracotomy aortic valve surgery. J. Thorac. Cardiovasc. Surg. 2018, 155, 926–936.e2. [Google Scholar] [CrossRef]
  29. Kiaii, B.; McClure, R.S.; Stitt, L.; Rayman, R.; Dobkowski, W.B.; Jablonsky, G.; Novick, R.J.; Boyd, W.D. Prospective Angiographic Comparison of Direct, Endoscopic, and Telesurgical Approaches to Harvesting the Internal Thoracic Artery. Ann. Thorac. Surg. 2006, 82, 624–628. [Google Scholar] [CrossRef]
  30. Repossini, A.; Di Bacco, L.; Nicoli, F.; Passaretti, B.; Stara, A.; Jonida, B.; Muneretto, C. Minimally invasive coronary artery bypass: Twenty-year experience. J. Thorac. Cardiovasc. Surg. 2019, 158, 127–138.e1. [Google Scholar] [CrossRef]
  31. Hecker, F.; Von Zeppelin, M.; Van Linden, A.; Scholtz, J.E.; Fichtlscherer, S.; Hlavicka, J.; Walther, T.; Holubec, T. Right-Sided Minimally Invasive Direct Coronary Artery Bypass: Clinical Experience and Perspectives. Medicina 2023, 59, 907. [Google Scholar] [CrossRef] [PubMed]
  32. Khubber, S.; Chana, R.; Meenakshisundaram, C.; Dhaliwal, K.; Gad, M.; Kaur, M.; Banerjee, K.; Verma, B.R.; Shekhar, S.; Khan, M.Z.; et al. Coronary artery aneurysms: Outcomes following medical, percutaneous interventional and surgical management. Open Heart 2021, 8, e001440. [Google Scholar] [CrossRef] [PubMed]
  33. Teman, N.R.; Hawkins, R.B.; Charles, E.J.; Mehaffey, J.H.; Speir, A.M.; Quader, M.A.; Ailawadi, G. Minimally Invasive vs Open Coronary Surgery: A Multi-Institutional Analysis of Cost and Outcomes. Ann. Thorac. Surg. 2021, 111, 1478–1484. [Google Scholar] [CrossRef] [PubMed]
  34. Liu, J.J.; Kong, Q.Y.; You, B.; Liang, L.; Xiao, W.; Ma, X.L.; Pan, F.; Chi, L.Q. Surgical Challenges in Multi-Vessel Minimally Invasive Coronary Artery Bypass Grafting. J. Interv. Cardiol. 2021, 2021, 1–8. [Google Scholar] [CrossRef] [PubMed]
  35. Kitahara, H.; Hirai, T.; McCrorey, M.; Patel, B.; Nisivaco, S.; Nathan, S.; Balkhy, H.H. Hybrid coronary revascularization: Midterm outcomes of robotic multivessel bypass and percutaneous interventions. J. Thorac. Cardiovasc. Surg. 2019, 157, 1829–1836.e1. [Google Scholar] [CrossRef]
  36. Mishra, Y.K.; Wasir, H.; Rajneesh, M.; Sharma, K.K.; Mehta, Y.; Trehan, N. Robotically enhanced coronary artery bypass surgery. J. Robot. Surg. 2007, 1, 221–226. [Google Scholar] [CrossRef]
  37. Fazlinović, S.; Wallinder, A.; Dellborg, M.; Furenäs, E.; Eriksson, P.; Synnergren, M.; Lidén, H. Outcome and survival after open heart surgery for adults with congenital heart disease—A single center experience. Scand. Cardiovasc. J. 2021, 55, 345–353. [Google Scholar] [CrossRef]
  38. Hwang, H.Y.; Paeng, J.C.; Kang, J.; Jang, M.J.; Kim, K.B. Relation between functional coronary artery stenosis and graft occlusion after coronary artery bypass grafting. J. Thorac. Cardiovasc. Surg. 2021, 161, 1010–1018.e1. [Google Scholar] [CrossRef]
  39. Gong, W.; Cai, J.; Wang, Z.; Chen, A.; Ye, X.; Li, H.; Zhao, Q. Robot-assisted coronary artery bypass grafting improves short-term outcomes compared with minimally invasive direct coronary artery bypass grafting. J. Thorac. Dis. 2016, 8, 459–468. [Google Scholar] [CrossRef]
  40. Antona, C.; Pompilio, G.; Lotto, A.A.; Di Matteo, S.; Agrifoglio, M.; Biglioli, P. Video-assisted minimally invasive coronary bypass surgery without cardiopulmonary bypass. Eur. J. Cardio-Thorac. Surg. 1998, 14, 62–67. [Google Scholar] [CrossRef]
  41. Liang, L.; Ma, X.; Kong, Q.; Xiao, W.; Liu, J.; Chi, L.; Zhu, J. Comparing patient outcomes following minimally invasive coronary artery bypass grafting surgery vs. coronary artery bypass grafting: A single-center retrospective cohort study. Cardiovasc. Diagn. Ther. 2022, 12, 378–388. [Google Scholar] [CrossRef] [PubMed]
  42. Zia, K.; Mangi, A.R.; Minhaj, S.; Tariq, K.; Rabbi, F.; Musharaf, M.; Awan, M.A.B.; Memon, R.A.; Rathore, A.R.; Chaudry, P.A. An Overview of First 100 Cardiac Surgery Cases at a Newly Developed Satellite Center in Sukkur, Pakistan. Cureus 2020, 12, e8490. [Google Scholar] [CrossRef] [PubMed]
  43. Diegeler, A.; Falk, V.; Matin, M.; Battellini, R.; Walther, T.; Autschbach, R.; Mohr, F.W. Minimally invasive coronary artery bypass grafting without cardiopulmonary bypass: Early experience and follow-up. Ann. Thorac. Surg. 1998, 66, 1022–1025. [Google Scholar] [CrossRef] [PubMed]
  44. Bugajski, P.; Greberski, K.; Kuzemczak, M.; Kalawski, R.; Jarząbek, R.; Siminiak, T. Impact of previous percutaneous coronary interventions on the course and clinical outcomes of coronary artery bypass grafting. Kardiol. Pol. 2018, 76, 953–959. [Google Scholar] [CrossRef] [PubMed]
  45. Ranjan, R.; Sales, K.M.; Adhikary, A.B. Computed Tomography-Based Angiographic Evaluation of Graft Patency Rate after Coronary Artery Bypass Graft Surgery in Bangladesh. Cureus 2022, 14, e28902. [Google Scholar] [CrossRef]
  46. Cisowski, M.; Morawski, W.; Drzewiecki, J.; Kruczak, W.; Toczek, K.; Bis, J.; Bochenek, A. Integrated minimally invasive direct coronary artery bypass grafting and angioplasty for coronary artery revascularization. Eur. J. Cardio-Thorac. Surg. 2002, 22, 261–265. [Google Scholar] [CrossRef]
  47. Balkhy, H.H.; Nisivaco, S.; Kitahara, H.; Torregrossa, G.; Patel, B.; Grady, K.; Coleman, C. Robotic off-pump totally endoscopic coronary artery bypass in the current era: Report of 544 patients. Eur. J. Cardio-Thorac. Surg. 2021, 61, 439–446. [Google Scholar] [CrossRef]
  48. Kirmani, B.; Power, S.; Zacharias, J. Long-term survival after endoscopic vein harvest for coronary artery bypass grafting. Ann. R. Coll. Surg. Engl. 2020, 102, 422–428. [Google Scholar] [CrossRef]
  49. Tekin, A.İ.; Arslan, Ü. Perioperative outcomes in minimally invasive direct coronary artery bypass versus off-pump coronary artery bypass with sternotomy. Videosurgery Other Miniinvasive Tech. 2017, 3, 285–290. [Google Scholar] [CrossRef]
  50. Ono, M.; Wolf, R.K.; Angouras, D.C.; Brown, D.A.; Goldstein, A.H.; Michler, R.E. Short- and long-term results of open heart surgery in patients with abdominal solid organ transplant. Eur. J. Cardio-Thorac. Surg. 2002, 21, 1061–1072. [Google Scholar] [CrossRef]
  51. Zhang, L.; Cui, Z.; Song, Z.; Yang, H.; Fu, Y.; Gong, Y.; Ling, Y. Minimally invasive direct coronary artery bypass for left anterior descending artery revascularization—Analysis of 300 cases. Videosurgery Other Miniinvasive Tech. 2015, 10, 548–554. [Google Scholar] [CrossRef] [PubMed]
  52. Takai, H.; Kobayashi, J.; Tagusari, O.; Bando, K.; Niwaya, K.; Nakajima, H.; Yagihara, T.; Kitamura, S. Off-Pump Coronary Artery Bypass Grafting for Acute Myocardial Infarction. Circ. J. 2006, 70, 1303–1306. [Google Scholar] [CrossRef] [PubMed]
  53. Birla, R.; Patel, P.; Aresu, G.; Asimakopoulos, G. Minimally invasive direct coronary artery bypass versus off-pump coronary surgery through sternotomy. Ann. R. Coll. Surg. Engl. 2013, 95, 481–485. [Google Scholar] [CrossRef] [PubMed]
  54. McGinn, J.T.; Usman, S.; Lapierre, H.; Pothula, V.R.; Mesana, T.G.; Ruel, M. Minimally Invasive Coronary Artery Bypass Grafting: Dual-Center Experience in 450 Consecutive Patients. Circulation 2009, 120 (Suppl. S1), S78–S84. [Google Scholar] [CrossRef]
  55. Barsoum, E.A.; Azab, B.; Shah, N.; Patel, N.; Shariff, M.A.; Lafferty, J.; Nabagiez, J.P.; McGinn, J.T. Long-term mortality in minimally invasive compared with sternotomy coronary artery bypass surgery in the geriatric population (75 years and older patients). Eur. J. Cardio-Thorac. Surg. 2014, 47, 862–867. [Google Scholar] [CrossRef]
  56. Stone, G.W.; Sabik, J.F.; Serruys, P.W.; Simonton, C.A.; Généreux, P.; Puskas, J.; Kandzari, D.E.; Morice, M.C.; Lembo, N.; Brown, W.M.; et al. Everolimus-Eluting Stents or Bypass Surgery for Left Main Coronary Artery Disease. N. Engl. J. Med. 2016, 375, 2223–2235. [Google Scholar] [CrossRef]
  57. Diegeler, A.; Matin, M.; Kayser, S.; Binner, C.H.; Autschbach, R.; Battellini, R.; Krankenberg, H.; Mohr, F.W. Angiographic results after minimally invasive coronary bypass grafting using the minimally invasive direct coronary bypass grafting (MIDCAB) approach1. Eur. J. Cardio-Thorac. Surg. 1999, 15, 680–684. [Google Scholar] [CrossRef]
  58. Li, D.; Guo, P.; Chen, L.; Wu, Y.; Wang, G.; Xiao, C. Outcomes of Surgical Patch Angioplasty of the Coronary Artery for Diffuse Coronary Artery Disease. Braz. J. Cardiovasc. Surg. 2020, 35, 706–712. [Google Scholar] [CrossRef]
  59. Sajja, L.R.; Sarkar, K.; Mannam, G.; Kodali, V.K.K.; Padmanabhan, C.; Peter, S.; Mulay, A.; Beri, P. Graft patency at 3 months after off- and on-pump coronary bypass surgery: A randomized trial. Indian J. Thorac. Cardiovasc. Surg. 2019, 36, 93–104. [Google Scholar] [CrossRef]
  60. Kim, D.K.; Yoo, K.J.; Hong, Y.S.; Chang, B.C.; Kang, M.S. Clinical Outcome of Urgent Coronary Artery Bypass Grafting. J. Korean Med. Sci. 2007, 22, 270. [Google Scholar] [CrossRef]
  61. Oktar, G.; Imren, V.; Erer, D.; Iriz, E.; Gokgoz, L.; Soncul, H. Coronary artery bypass graft surgery in the elderly patients. Open Med. 2009, 4, 218–221. [Google Scholar] [CrossRef]
  62. Raghuram, A.R.R.; Subramanyan, K.; Sivakumaran, S.; Chandrasekar, P.; Harikrishnan, S.; Arunkumar, G. Graft patency study in off-pump coronary artery bypass surgery. Indian J. Thorac. Cardiovasc. Surg. 2017, 34, 6–10. [Google Scholar] [CrossRef]
  63. Park, D.W.; Ahn, J.M.; Yun, S.C.; Yoon, Y.H.; Kang, D.Y.; Lee, P.H.; Lee, S.W.; Park, S.W.; Seung, K.B.; Gwon, H.C.; et al. 10-Year Outcomes of Stents Versus Coronary Artery Bypass Grafting for Left Main Coronary Artery Disease. J. Am. Coll. Cardiol. 2018, 72, 2813–2822. [Google Scholar] [CrossRef] [PubMed]
  64. Moussa, I.; Oetgen, M.; Subramanian, V.; Kobayashi, Y.; Patel, N.; Moses, J. Frequency of early occlusion and stenosis in bypass grafts after minimally invasive direct coronary arterial bypass surgery. Am. J. Cardiol. 2001, 88, 311–313. [Google Scholar] [CrossRef] [PubMed]
  65. Halkos, M.E.; Liberman, H.A.; Devireddy, C.; Walker, P.; Finn, A.V.; Jaber, W.; Guyton, R.A.; Puskas, J.D. Early clinical and angiographic outcomes after robotic-assisted coronary artery bypass surgery. J. Thorac. Cardiovasc. Surg. 2014, 147, 179–185. [Google Scholar] [CrossRef]
  66. Bachar, B.J.; Manna, B. Coronary Artery Bypass Graft. StatPearls—NCBI Bookshelf. Available online: https://www.ncbi.nlm.nih.gov/books/NBK507836/ (accessed on 1 January 2024).
  67. Coerkamp, C.F.; Hoogewerf, M.; Van Putte, B.P.; Appelman, Y.; Doevendans, P.A. Revascularization strategies for patients with established chronic coronary syndrome. Eur. J. Clin. Investig. 2022, 52, e13787. [Google Scholar] [CrossRef]
  68. Lin, T.H.; Wang, C.W.; Shen, C.H.; Chang, K.H.; Lai, C.H.; Liu, T.J.; Chen, K.J.; Chen, Y.W.; Lee, W.L.; Su, C.S. Clinical outcomes of multivessel coronary artery disease patients revascularized by robot-assisted vs conventional standard coronary artery bypass graft surgeries in real-world practice. Medicine 2021, 100, e23830. [Google Scholar] [CrossRef]
  69. Park, S.; Park, S.J.; Park, D.W. Percutaneous Coronary Intervention Versus Coronary Artery Bypass Grafting for Revascularization of Left Main Coronary Artery Disease. Korean Circ. J. 2023, 53, 113. [Google Scholar] [CrossRef]
  70. Gray, D.T.; Veenstra, D.L. Comparative economic analyses of minimally invasive direct coronary artery bypass surgery. J. Thorac. Cardiovasc. Surg. 2003, 125, 618–624. [Google Scholar] [CrossRef]
  71. Skeffington, K.L.; Moscarelli, M.; Abdul-Ghani, S.; Fiorentino, F.; Emanueli, C.; Reeves, B.C.; Punjabi, P.P.; Angelini, G.D.; Suleiman, M.-S. Pathology-related changes in cardiac energy metabolites, inflammatory response and reperfusion injury following cardioplegic arrest in patients undergoing open-heart surgery. Front. Cardiovasc. Med. 2022, 9, 911557. [Google Scholar] [CrossRef]
  72. Bonatti, J.; Wallner, S.; Crailsheim, I.; Grabenwöger, M.; Winkler, B. Minimally invasive and robotic coronary artery bypass grafting-a 25-year review. J. Thorac. Dis. 2021, 13, 1922–1944. [Google Scholar] [CrossRef] [PubMed]
  73. Van Praet, K.M.; Kofler, M.; Shafti, T.Z.N.; Al, A.A.E.; Van Kampen, A.; Amabile, A.; Torregrossa, G.; Kempfert, J.; Falk, V.; Balkhy, H.H.; et al. Minimally Invasive Coronary Revascularisation Surgery: A Focused Review of the Available Literature. Interv. Cardiol. Rev. Res. Resour. 2021, 16, e08. [Google Scholar] [CrossRef] [PubMed]
Figure 1. Detailed PRISMA chart used for this systematic review, outlining the many stages of this study’s selection process.
Figure 1. Detailed PRISMA chart used for this systematic review, outlining the many stages of this study’s selection process.
Clinpract 14 00147 g001
Table 1. Comparison of Outcomes Between Open and Minimally Invasive Approaches in CABG.
Table 1. Comparison of Outcomes Between Open and Minimally Invasive Approaches in CABG.
Group A
Open Approaches in CABG
AuthorsWound infection rateBleeding rateStroke rateAngina recurrence rateLength of hospital stayMortality rate
Calin Vicol [13]0%2.30%2%27%16 days4%
Piroze M [14]0.90%1.90%0.80%11%19 days0.60%
Marco A [15]3.10%5.90%5.90%8%8 days8%
Gianni D [16]25%10.60%1%4.70%38 days5%
Pierpaolo Chivasso [17]///25.60%/7%
Ming Hao Guo [18]47%///6 days4%
Group B
Minimally Invasive Approaches in CABG
AuthorsWound infection rateBleeding rateStroke rateAngina recurrence rateLength of hospital stayMortality rate
Calin Vicol [13]5%1.70%7%40%138 days0%
Piroze M [14]//////
Marco A [15]1.40%6.00%3.20%6%11 days6.40%
Gianni D [16]31%11%2%2.30%21 days10%
Pierpaolo Chivasso [17]///11.40%/5.30%
Ming Hao Guo [18]16%///5 days1.30%
Table 2. Characteristics and Outcomes of Studies Investigating Open and Minimally Invasive Approaches in Coronary Artery Bypass Grafting.
Table 2. Characteristics and Outcomes of Studies Investigating Open and Minimally Invasive Approaches in Coronary Artery Bypass Grafting.
AuthorsCountryStudy DesignOpen
CABG Patients
(N)
Minimally Invasive CABG Patients
(N)
Major ComplicationsConclusionEvidence Level
Calin Vicol [13]GermanyRetrospective Cohort4557Open CABG: recurrent angina (27%), bleeding (2.3%), mortality (4%).
Minimally Invasive CABG: wound infection (5%), recurrent angina (40%), bleeding (1.7%).
The technical complexity of MIDCAB surpasses OPCAB, so skilled surgeons are requested.III
Piroze M [14]GermanyObservational51300Open CABG: arrhythmias (19.7%), wound infection (0.9%), bleeding (1.9%), mortality (0.6%).For OPCAB, using bilateral skeletonized ITAs is safe and effective.III
Marco A [15]USARandomized trials574576Open CABG: wound infection (3.1%), recurrent angina (8%), MI (5.9%), mortality (8%).
Minimally Invasive CABG: wound infection (1.4%), recurrent angina (6%), MI (4.7%), mortality (6.4%).
In CABG surgeries, both open and minimally invasive procedures yield similar long-term outcomes, with the minimally invasive method offering a slight advantage in reducing wound infections.I
Gianni D [16]United KingdomRandomized trials201200Open CABG: wound infection (25%), bleeding (10.6%), MI (1.0%), mortality (5.0%).
Minimally Invasive CABG: wound infection (31%), bleeding (11%), MI (2.0%), mortality (10%).
OPCAB and CABG with cardiopulmonary bypass have comparable long-term health outcomes. I
Pierpaolo Chivasso [17]United KingdomMeta-analyses of RCTS47522203Open CABG: recurrent angina (25.6%), mortality (7.0%).
Minimally Invasive CABG: recurrent angina (11.4%), mortality (5.3%).
The long-term benefits of off-pump CABG versus on-pump CABG remain uncertain, with existing studies showing mixed results due to methodological issues. More robust research is needed to clarify the long-term outcomes of these methods.II
Ming Hao Guo [18]CanadaRandomized Clinical Trial64450Open CABG: None.
Minimally Invasive CABG: conversion to sternotomy (3.8%), use of cardiopulmonary bypass (7.6%), mortality (1.3%).
Sternotomy CABG has a notable effect on quality of life.
MICS-CABG is comparatively safer.
II
Barış Çaynak [19]TurkeyRetrospective study045Minimally Invasive CABG: AF (11%), pleural effusion (6.7%).The significance of employing an intraoperative flowmeter to assess the patency of the graft and the quality of the anastomosis.III
Umberto Benedetto [20]GermanyRetrospective post hoc RCT9230Open CABG: MI (58%), mortality (5.0%).OPCAB is linked to a higher risk of death within 3 years and a lower rate of revascularization in the coronary arteries that supply the inferolateral wall. III
Yunpeng Ling [21]ChinaDescriptive, non-experimental0200Minimally Invasive CABG: AF (7.2%), mortality (0.7%).Utilization of enhanced retractor and stabilizer in MIDCAB has the potential to yield positive results.III
Meice Tian [22]ChinaRandomized controlled trial26550Open CABG: wound infection (4.3%), recurrent angina (2.3%), bleeding (1.7%), MI (0.6%), mortality (1.1%).Using the no-touch technique for vein graft harvesting greatly reduced the chance of vein graft occlusion and improved the patient’s prognosis.I
Kayatta MO [23]IndiaRetrospective observational0450Minimally Invasive CABG: wound infection (0.9%), pneumothorax (3.1%), pleural effusion (9.1%), recurrent angina (1.6%), bleeding (1.1%), MI (1.1%).The success of MICS-CABG relies heavily on meticulous patient selection.III
Weimar [24]GermanyRandomized Clinical Trial1290Open CABG: MI (1%).For patients with severe CAD undergoing CABG, combining carotid endarterectomy with CABG does not appear to offer significant advantages over isolated CABG. The study’s early termination limits the findings, but the data suggest that isolated CABG may lead to better outcomes. We need further follow-up to confirm long-term effects.I
Marc Ruel [25]CanadaCohort091Minimally Invasive CABG: pleural effusion (15%), AF (17%), renal insufficiency (1.1%), wound infection (2.2%).MICS-CABG can effectively revascularize, similar to regular CABG. I
Shahzad G [26]CanadaRetrospective Cohort160668Open CABG: bleeding (2.5%), a wound infection (1.9%), mortality (2.5%).
Minimally Invasive CABG: bleeding (3.1%), wound infection (2.4%), mortality (2.0%).
The validity and effectiveness of MIDCAB as a grafting method for the LAD artery.
MIDCAB is a good alternative to traditional CABG for people with a single proximal LAD stenosis.
III
Vincenzo Giambruno [27]CanadaRetrospective comparative analysis546144Open CABG: bleeding (1.7%), MI (1.1%), stroke (2.4%), mortality (1.3%).
Minimally Invasive CABG: bleeding (2.8%), MI (1.4%), stroke (2.1%).
HCR is potentially linked to a reduction in hospital mortality rates and shorter hospital stays in comparison to on-pump CABG. III
Ali Hage [10]USARetrospective comparative analysis216147Open CABG: bleeding (1.5%), MI (0.5%), hemodialysis (0.5%), mortality (1.0%).
Minimally Invasive CABG: bleeding (3.5%), MI (1.4%).
HCR is a viable substitute for unsuitable multivessel PCI, especially in those exhibiting a low-intermediate SYNTAX score. III
Joseph Lamelas [28]USARetrospective cohort study01396Minimally Invasive CABG: bleeding (0.8%), postoperative pacemakers (3.1%), stroke (0.8%).Minimally invasive right thoracotomy aortic valve surgery, including both stand-alone and concurrent AVR surgeries, is a viable technique.III
Bob Kiaii [29]CanadaProspective cohort50100Open CABG: None.
Minimally Invasive CABG: None.
The ITA can be taken out using minimally invasive videoscopic and robotic-assisted telesurgical techniques, which are both safe and effective. II
Joshua Michael Rosenblum [7]USARetrospective cohort174110Open CABG: stroke (1.3%), AF (22.5%), pneumonia (3.8%), renal failure (3.0%), mortality (13.4%).CRV has a higher survival benefit than IRV.
MA-CABG has higher survival rates than SA-CABG.
II
Alberto Repossini [30]ItalyRetrospective analysis01060Minimally Invasive CABG: stroke (0.3%), angina (7.2%), mortality (0.8%).MIDCAB without CPB is safe when revascularizing the LAD artery. III
Florian Hecker [31]GermanyProspective study analysis011Minimally Invasive CABG: wound infection (9.1%), revascularization after surgery (18.2%).Right-sided MIDCAB in individuals diagnosed with complicated CAD specifically affecting the RCA is safe.II
Shameer Khubber [32]USARetrospective Cohort176282Open CABG: None.
Minimally Invasive CABG: None.
Clinicians should take a personalized approach because the long-term risks of MACCE are similar to treating CAAs with medicine, PCI, and surgery CABG.III
Nicholas R [33]USAPropensity-matched Regional Cohort278139Open CABG: AF (23.4%), bleeding (2.2%), and mortality (8.3%).
Minimally Invasive CABG: AF (20.1%), bleeding (2.2%), mortality (0.7%).
MICS-CABG accounted for a relatively minor proportion of the total number of CABGs conducted.
MICS-CABG was linked to reduced durations of stay in the intensive care unit and hospital.
III
Jia-Ji Liu [34]ChinaRetrospective, single-center, observational0118Minimally Invasive CABG: None.Performing off-pump MICS CABG to treat multi-vessel disease entails a significant learning curve.
The operating length, intraoperative blood loss, ICU admission, and postoperative inpatient duration may be prolonged.
III
Hiroto Kitahara [35]USARetrospective single-center057Minimally Invasive CABG: acute kidney injury (1.8%), AF (9.3%).The process of selecting patients should incorporate a collaborative decision-making approach involving both robotic cardiac surgeons and interventional cardiologists.III
Yugal K. Mishra [36]IndiaRetrospective cohort61193Open approach in CABG: bleeding (3.4%), wound infection (2%), mortality (1.7%).
Minimally Invasive CABG: bleeding (1%), wound infection (1.4%).
Using the da Vinci telemanipulation system in robotically enhanced telemanipulation surgery for MIDCAB.III
Sanin Fazlinović [37]SwedenRetrospective descriptive single-center cohort4210Open CABG: hemorrhage (5.3%), acute renal failure (4.3%), acute respiratory failure (1%), wound infection (2.8%), mortality (2.3%).The identification of acute surgeries as a risk factor for significant complications in the study underscores the importance of meticulous deliberation and prompt strategizing of surgical treatments, particularly in cases of acute nature.III
Ho Young Hwang [38]USARetrospective601300Open CABG: bleeding (4.3%).
Minimally Invasive CABG: None.
The functional importance of coronary stenosis was linked to the rates of occlusion in bypass grafts that were connected to the coronary artery five years after surgery. III
Wenhui Gong [39]ChinaRetrospective7161Open CABG: wound infection (4%), MI (2%), mortality (5%).
Minimally Invasive CABG: wound infection (1%), MI (3%), mortality (3%).
The RACAB grafts might be a good alternative for people who need a single or simple multi-vessel CABG. III
Carlo Antona [40]ItalyPreoperative study041Minimally Invasive CABG: AF (4.8%), bleeding (2%).MIDCABG, when administered to certain individuals, exhibits reliability, safety, and promising clinical outcomes in the early and mid-term.III
Lin Liang [41]ChinaRetrospective cohort study398281Open CABG: mortality (4%).
Minimally Invasive CABG: MI (0.4%), mortality (2.5%).
The rates of MACCEs, such as cardiac death, MI, or recurrent revascularization, were not significantly different between CAD patients treated with MICS or CABG. III
Zia K [42]PakistanRetrospective observational study7030Open CABG: renal dysfunction (1%), mortality (0.4%).
Minimally Invasive CABG: renal dysfunction (2.1%).
The selection between open and minimally invasive techniques in CABG should be tailored to the individual patient, considering patient-specific features, anatomical considerations, and clinical characteristics. III
Anno Diegeler [43]ItalyRandomized controlled trials0209Minimally Invasive CABG: graft failure (1.4%), bleeding (1.4%), MI (1.9%), mortality (0.4%).MIDCAB is a very good way to revascularize the arteries in people with symptomatic left anterior descending coronary artery disease.I
Paweł Bugajski [44]PolandRetrospective Cohort2110Open CABG: recurrent angina (12%), mortality (4%).Patients with a higher number of grafts have more time-consuming CABG procedures.
These entities exhibit elevated rates of long-term mortality while maintaining comparable levels of graft patency, in-hospital mortality, and morbidity.
II
Redoy Ranjan [45]LondonRetrospective Cohort3434Open CABG: bleeding (3.2%).
Minimally Invasive CABG: None.
The reliability and effectiveness of CABG surgery with an endarterectomy have been established. The procedure successfully achieves the desired surgical myocardial revascularization in people with diffuse calcified CAD who do not have any other options for achieving sufficient myocardial revascularization.III
Marek Cisowskia [46]PolandRetrospective study050Minimally Invasive CABG: bleeding (4.5%).In the context of selected individuals with double-vessel CAD, hybrid procedures have been identified as both safe and successful approaches for achieving full revascularization. III
Husam H. Balkhy [47]ChicagoRetrospective Cohort5440Open CABG: mortality (7.6%).The robotic beating-heart TECAB is now thought to be safe and effective, with good results and similar early angiographic patency to traditional CABG surgery when performed regularly by a skilled team.III
BH Kirmani [48]UKRetrospective cohort64981029Open CABG: AF (1.9%), cardiac arrest (4.7%), mortality (1.2%).
Minimally Invasive CABG: AF (2.3%), cardiac arrest (2%), mortality (0.4%).
The endoscopic harvesting of saphenous veins for CABG has the same quality as open vein harvesting when it comes to long-term survival.III
Ali İhsan Tekin [49]TurkeyRetrospective cohort2423Open CABG: None.
Minimally Invasive CABG: None.
The MIDCAB technique works better than the OPCAB technique in the first few days of treatment in hospitals for patients with a serious LAD lesion.III
Minoru Ono [50]USARetrospective cohort600Open CABG: deterioration of renal function (7%), wound infection (3%), bleeding (2%), stroke (2%), mortality (5%).Patients with functional abdominal transplants can achieve satisfactory short- and long-term outcomes with the implementation of open-heart surgery. Select patients may not require a stress-dose steroid.III
Lufeng Zhang [51]ChinaRetrospective cohort355300Open CABG: None.
Minimally Invasive CABG: bleeding (2%), mortality (0.3%).
The adoption of a chest wall lifting device and a redesigned stabilizer enhances the safety and ease of the MIDCAB technique. The feasibility and minimum invasiveness of the MIDCAB technique have been established as a viable alternative for individuals diagnosed with CAD.II
Hideaki Takai [52]JapanRetrospective cohort study430Open CABG: arrhythmia (0.2%).After an acute MI, OPCAB can be performed as a relatively low-risk procedure with a good death rate, even up to 14 days after the MI.III
R Birla [53]UKRetrospective cohort7874Open CABG: AF (1.2%), bleeding (1.3%), wound infection (2%), recurrent angina (5.1%), mortality (6.4%).
Minimally Invasive CABG: AF (1.7%), bleeding (1%), wound infection (4%), recurrent angina (1.4%), mortality (1.4%).
The study revealed prospective advantages of MIDCAB, such as decreased hospitalization duration, diminished requirement for blood transfusions, and expedited recuperation.III
Joseph T. McGinn [54]CanadaRetrospective cohort0450Minimally Invasive CABG: pleural effusion (4.1%), pneumothorax (1.4%), wound infection (1%), mortality (1.1%).MICS CABG is a safe and effective alternative to open CABG, with promising short-term outcomes and the potential to expand access to minimally invasive heart surgery.III
Emad A. Barsouma [55]USARetrospective study9861Open CABG: mortality (47.6%).
Minimally Invasive CABG: mortality (19.7%).
MICS-CABG has a statistically significantly higher long-term survival rate than sternotomy-CABG in older people, even though the two procedures had some minor differences at the start.III
G.W. Stone [56]PolandRandomized controlled trials957948Open CABG: MI (8.3%), mortality (5.9%).
Minimally Invasive CABG: MI (0.8%).
Using fluoropolymer-based cobalt-chromium everolimus-eluting stents for PCI could be a good alternative to CABG for people with left main CAD whose anatomy is not very complicated.I
A. Diegelera [57]GermanyProspective study0271Minimally Invasive CABG: MI (2.2%), bleeding (4.5%).It is important to include post-operative angiographic control as part of the treatment following MIDCAB-grafting. II
Dong Li [58]ChinaRetrospective Cohort12832Open CABG: MI (1.6%), mortality (1.6%).
Minimally Invasive CABG: None.
The treatment options for diffuse CAD include coronary artery reconstruction and surgical patch angioplasty of the coronary artery.
There was no significant difference in patient outcomes.
III
Lokeswara Rao Sajja [59]IndiaRandomized controlled trials3200Open CABG: mortality (1.8%).There was no statistically significant difference between the off-pump and on-pump CABG groups in the overall rates of graft patency at 3 months when the surgery was performed by skilled surgeons who are more likely to use the off-pump method.I
Do-Kyun Kim [60]South KoreaRetrospective Cohort1040Open CABG: MI (1.9%), mortality (17.3%).Although the surgical death rate following urgent CABG is greater at 17.3%, a positive long-term clinical outcome can be anticipated in the event of patient survival.III
Gursel Levent Oktar [61]TurkeyRetrospective Cohort7370Open CABG: AF (16.6%), mortality (0.1%).Coronary artery surgery can be conducted in elderly patients with a tolerable level of risk. III
Arani Raghavendra [62]IndiaProspective cohort1180Open CABG: bleeding (6.3%).Healthcare professionals should consider the option of on-pump CABG in cases where the preservation of graft patency is a significant issue, particularly in individuals aged 70 years and above.II
Duk-Woo Park [63]KoreaRetrospective Observational Cohort11381102Open CABG: MI (1.0%), mortality (0.5%).
Minimally Invasive CABG: MI (8.1%), mortality (0.3%).
Patients with severe left main coronary artery (LMCA) disease can achieve revascularization through either PCI or CABG.
Clinicians must consider each patient’s unique traits, preferences, and anatomical variables when deciding on the most suitable technique.
III
Issam Moussa [64]USARandomized controlled trials0365Minimally Invasive CABG: ventricular arrhythmia (2.3%), respiratory failure (1.7%), MI (0.6%), mortality (3.1%).Using the MIDCAB method has led to better operator skills and stabilizing technology, which has improved the patency rate of bypass grafts.I
Michael E. Halkos [65]USAProspective cohort0307Minimally Invasive CABG: stroke (0.3%), bleeding (2.3%), MI (1.6%), AF (15.3%), wound infection (2%), renal failure (2%), mortality (1.3%).Robotic-assisted CABG is not recommended for hemodynamically unstable people who have intra-aortic balloon pumps or are having an MI that is becoming worse.
There were relative contraindications for patients with a distal target vessel that was not working well or at all, who had a previous sternotomy or thoracotomy, who had a body mass index (BMI) of 40 or more, or who had a serious lung disease that made it impossible for them to maintain single-lung ventilation.
II
Abbreviations: CABG: Coronary Artery Bypass Grafting, MIDCAB: Minimally Invasive Direct Coronary Artery Bypass, OPCAB: Off-Pump Coronary Artery Bypass, ITAs: Internal Thoracic Arteries, MI: Myocardial infarction, MICS-CABG: Minimally Invasive Coronary Artery Bypass Grafting, AF: Atrial fibrillation, LAD: Left anterior descending, PCI: Percutaneous coronary intervention, HCR: Hybrid Coronary Revascularization, SYNTAX: Synergy Between PCI With Taxus and Cardiac Surgery, AVR: Aortic Valve Replacement, CRV: Complete revascularization, IRV: Incomplete revascularization, MA-CABG: Multiple arterial coronary artery bypass grafting, SA-CABG: Single-arterial coronary artery bypass grafting, CPB: Cardiopulmonary bypass, CAD: Coronary artery disease, RCA: Right coronary artery, MACCE: Major cardiovascular and cerebrovascular events, CAAs: Coronary artery aneurysms, ICU: Intensive Care Unit, RACAB: Robot-assisted coronary artery bypass grafts, TECAB: Transcatheter endoscopic aortic aneurysm bypass grafting.
Disclaimer/Publisher’s Note: The statements, opinions and data contained in all publications are solely those of the individual author(s) and contributor(s) and not of MDPI and/or the editor(s). MDPI and/or the editor(s) disclaim responsibility for any injury to people or property resulting from any ideas, methods, instructions or products referred to in the content.

Share and Cite

MDPI and ACS Style

Alsharif, A.; Alsharif, A.; Alshamrani, G.; Abu Alsoud, A.; Abdullah, R.; Aljohani, S.; Alahmadi, H.; Fuadah, S.; Mohammed, A.; Hassan, F.E. Comparing the Effectiveness of Open and Minimally Invasive Approaches in Coronary Artery Bypass Grafting: A Systematic Review. Clin. Pract. 2024, 14, 1842-1868. https://doi.org/10.3390/clinpract14050147

AMA Style

Alsharif A, Alsharif A, Alshamrani G, Abu Alsoud A, Abdullah R, Aljohani S, Alahmadi H, Fuadah S, Mohammed A, Hassan FE. Comparing the Effectiveness of Open and Minimally Invasive Approaches in Coronary Artery Bypass Grafting: A Systematic Review. Clinics and Practice. 2024; 14(5):1842-1868. https://doi.org/10.3390/clinpract14050147

Chicago/Turabian Style

Alsharif, Arwa, Abdulaziz Alsharif, Ghadah Alshamrani, Abdulhameed Abu Alsoud, Rowaida Abdullah, Sarah Aljohani, Hawazen Alahmadi, Samratul Fuadah, Atheer Mohammed, and Fatma E. Hassan. 2024. "Comparing the Effectiveness of Open and Minimally Invasive Approaches in Coronary Artery Bypass Grafting: A Systematic Review" Clinics and Practice 14, no. 5: 1842-1868. https://doi.org/10.3390/clinpract14050147

Article Metrics

Back to TopTop
